USER MANUAL
Refrigerator
T2000 series

Advertisement

Table of Contents
loading

Related Manuals for Thetford T2000 Series

Summary of Contents for Thetford T2000 Series

  • Page 1 USER MANUAL Refrigerator T2000 series...

  • Page 2: Table Of Contents

    1. Introduction General This is the user manual for your Thetford T2000 series refrigerator. Read the safety instructions and information on use and maintenance of the refrigerator carefully before continuing. This will enable you to use the refrigerator safely and efficiently.

  • Page 3: Safety

    Note. Additional information. Video. Additional instruction video available. 2. Safety Children an vulnerable people This appliance may be used by children aged 8 years or older and persons with reduced physical, sensory or mental capabilities and/or lack of experience and knowledge only if they are supervised or have been given instructions on the safe use of this appliance and understand the potential hazards.
  • Page 4 The appliance is suitable for camping use. Opening the door for long periods can cause a significant increase of the temperature in the compartments of the appliance. Store consumables in suitable containers or wrapping in the refrigerator to avoid direct contact with interior Two-star frozen-food compartments are suitable for storing pre-frozen food, storing or making ice-cream and making ice cubes.
  • Page 5 Never open or damage the refrigerant circuit of the cooling system at the back or on the inside of your appliance. The cooling system is pressurised and contains flammable substances. Electricity When positioning the appliance, ensure the supply cord is not trapped or damaged.

  • Page 6: Overview

    3. Overview T2090C / T2090E 1. Refrigerator door 2. Control panel T2090C 3. Control panel T2090E (Se- parate) 4. Frozen food compartment door 5. Storage shelves 6. Shelf food retainer 7. Vegetable bins 8. Door bins 9. Bottle retainer T2090C 1.
  • Page 7 T2095 1. Refrigerator door 2. Control panel 3. Top shelf 4. Frozen food compartment door 5. Drawer divider 6. Drawer 7. Ventilation for cooling system 8. Bottle and vegetable bin 9. Drawer divider 10. Door bin 1. On/off button 2. Temperature settings - fresh food compartment 3.
  • Page 8 T2138 1. Frozen food compartment door 2. Control panel 3. Slide-out box 4. Shelf food retainer 5. Storage shelves 6. Drawer divider 7. Bottle and vegetable bin 8. Ventilation for cooling system 9. Door bins 10. Refrigerator door 1. On/off button 2.
  • Page 9 T2152 1. Refrigerator door 2. Control panel 3. Frozen food compartment door 4. Slide-out box 5. Shelf food retainer 6. Storage shelves 7. Drawer divider 8. Bottle and vegetable bin 9. Door bins 1. On/off button 2. Temperature settings - fresh food compartment 3.
  • Page 10 T2156 1. Fresh food compartment door 2. Control panel 3. Storage shelves 4. Shelf food retainer 5. Vegetable bins 6. Drawer 7. Frozen food compartment door 8. Door bins 1. On/off button 2. Temperature settings - fresh food compartment 3. Temperature settings - frozen food compartment 4.

  • Page 11: Before Use

    T2160 / T2175 / T2208 1. Control panel 2. Shelf food retainer 3. Slide-out box 4. Storage shelves (amount may vary depending on model) 5. Vegetable bin 6. Frozen food compartment 7. Ventilation for cooling system (including filter) 8. Frozen food compartment door 9.

  • Page 12: Use

    5. Use Read the applicable instructions in chapter Safety first. Switching on To switch on the refrigerator: T2090E / T2095 ■ Push the on/off button and hold it until the indicator lights up. After a few seconds the control panel will change to stand-by and locked mode. The blue on/off indicator light stays lit, indicating the refrigerator is still in function.
  • Page 13 For optimal performance, switch on the refrigerator 4 hours before placing food. To switch off the refrigerator, push and hold the on/off button for a few seconds. Selecting cooling level fresh food compartment Select one of five levels to set the desired level of cooling of the fresh food compartment. To select the desired cooling level: T2090E / T2095 ■...
  • Page 14 Always look at the packaging instructions of your food products for preservation level. Thetford advises to set the frozen food compartment on the highest setting. A lower setting is only needed to reduce the energy consumption. The T2090 has no option to regulate the temperature.
  • Page 15 Low: Temperature in the frozen food compartment is around -6°C. This setting is suited for making ice cubes and keeping products frozen for a short period of time. This setting saves energy compared to the higher settings. Medium: Temperature in the frozen food compartment is around -12°C. This setting is suited for keeping products frozen for an average period of time.
  • Page 16 After a few seconds, the control panel will save the settings and go to the locked stand-by mode. When the display is locked, the icons will turn off, only on/off and night mode will stay illuminated. Selecting night mode The refrigerator will select the lowest noise setting where possible. When the refrigerator needs to run harder (due to higher ambient temperatures and/or warm products), it may result in an increase of noise.
  • Page 17 Use night mode only when temperatures in the vehicle are below 30ºC. The night mode will switch off automatically after 12 hours. When switching off the night mode manually, it will go to automatic temperature control. Switch off/on blue indication light (T2095 only) Model T2095 is equipped with an exterior light behind the vent to indicate the refrigerator is running.
  • Page 18 Ensure that the door can still be closed after reorganizing shelves and bins. To reposition an unsecured storage shelf: ■ Turn the plastic clamp of the storage shelf upwards. ■ Lift the left side a bit. ■ Move the storage shelf to the desired position. ■...

  • Page 19: Maintenance And Cleaning

    6. Maintenance and cleaning Read the applicable instructions in chapter Safety first. Thetford recommends an annual inspection service by an approved service centre. Clean the refrigerator on a regular basis. ■ Always remove any spills or contamination immediately with a mild household cleaner and soft cloth.
  • Page 20 Therefore, frequently remove all dust from this area, e.g. using a vacuum cleaner. Thetford recommends to clean the cooling system once every 2 years or when you suspect bad performance or too high energy consumption.
  • Page 21 ■ Remove the storage shelf. To replace the secured storage shelf after maintenance: ■ Place right side (side without clamp) of the storage shelf in the refrigerator wall. ■ Place the other side (with the clamp) in the corresponding groove. ■...
  • Page 22 ■ Clean the slide-out box and slide out box system. ■ After cleaning, place the system back in reverse order. Make sure the slide-out box system snaps into place. Remove a drawer T2095 To remove the drawer: ■ Open the door. ■...
  • Page 23 The door with drawer is one part. Preferably perform this procedure with two people. T2138 / T2152 To remove the drawer: ■ Completely open the refrigerator door and pull the drawer until the stop. ■ Then lift the drawer at the front, as illustrated. ■...
  • Page 24 T2160 / T2175 / T2208 To remove the drawer: ■ Pull the drawer until the stop and push it a little bit back. ■ Then push the guide locks backwards, as illustrated. ■ Pull the drawer further to the front and lift the wheels over the curves. ■...
  • Page 25 Empty the drip tray (T2090C / T2090E only) During use, water will collect on the back wall of the refrigerator. If the external drainage option is not used, the condensation will collect in the drip tray. To empty the drip tray: ■...
  • Page 26 Do not use storage lock while driving. To use the refrigerator after storage: ■ Pull the storage lock out of the hole in the sidewall. ■ Rotate the storage lock back to its original position. ■ Push the storage lock back into the bottle and vegetable bin. ■...

  • Page 27: Disposal

    Defrosting Ice can build up in the frozen food compartment and on the back surface of the refrigerator compartment. When more than 3mm of ice has built up in any location of either compartment, the refrigerator needs to be defrosted. Failure to do this may damage the cooling system.

  • Page 28: Technical Specifications

    8. Technical specifications Refrigerator specifications Model Display Total Volume Energy con- Climate Climate volume frozen sumption class class night food (kWh/24h)* mode comp. (L) T2090C Capacitive 0.34 ST (16-38°C) N (16-32°C) touchscreen T2090E Display led 0.34 ST (16-38°C) N (16-32°C) push but- tons T2095...

  • Page 29: Service & Questions

    9. Service & questions Read the applicable instructions in chapter Safety first. Service Before any service work is started, disconnect the appliance from electrical supplies. Troubleshooting Problem Possible-cause Solution Battery voltage too low Recharge battery Start delay of 1 minute (no Wait 1 minute issue) Refrigerator is not cooling,...
  • Page 30 A low temperature setting is selected For more troubleshooting look on the website www.thetford.com Questions If you have questions about your product, parts, accessories or authorised services visit www.thetford.com. If you contact an authorised local Service Centre in your country, provide the details of the model and serial number plus the date of purchase.
  • Page 31 Warranty For our warranty clause, please refer to the conditions mentioned on www.thetford.com. Declaration of Conformity Thetford hereby declares that this product is in compliance with the essential requirements and other relevant provisions of the applicable Directives and Standards. A...
  • Page 32 T +61 3 9358 0700 T +86 755 8627 1393 T +46 31 336 35 80 F not available F +86 755 8627 1673 F not available E infoaus@thetford.com.au E info@thetford.cn E infos@thetford.eu www.thetford.com.au www.thetford.cn Copyright 2017-2023 Thetford B.V. All rights reserved. 692278/1023-V05...
