- Page 1 Installation Manual models Thetford Australia Pty. Ltd. 130-132 Freight Drive Somerton VIC 3062 Australia Website: www.thetford.com.au Part No. 04/2021...
-
Page 2: Table Of Contents
Table of Contents Safety Awareness ....................................2 Safety Instructions ....................................2 Assemble the Enclosure ..................................4 Ventilation Requirements..................................4 Key Refrigerator Dimensions..................................5 Installation Options ....................................6 Reverse the door swing …………………………............................6 Install the Refrigerator .................................... .7 Connect the Electrical Components ............................... .8 Electrical current necessary ................................ - Page 3 Safety Instructions CAUTION - In order to prevent the risk of fire in the event of uncontrolled leakage of the refrigerant system, make sure that the refrigerant charge per net room volume does not exceed 8 g/mᵌ. Net room volume is defined as the gross room volume minus the volume of any product, equipment, or objects located in the living area.
-
Page 4: Assemble The Enclosure
Assemble the Enclosure - For models – high x wide x deep. ART 02756 Ventilation Requirements This refrigerator is made for a built-in installation. Correct ventilation is necessary for the correct operation of the refrigerator and to increase the life of the refrigerator cooling system. Ventilation allows the natural air flow that is necessary for good refrigeration. -
Page 5: Key Refrigerator Dimensions
Key Refrigerator Dimensions Refrigerator cabinet width: 592 mm + installation frame: 614 mm..............1 Refrigerator cabinet height: 1521 mm + installation frame: 1534 mm..............2 Refrigerator top to control top: 53 mm..............3 Enclosure depth: 610 mm..............4 Refrigerator bottom feet to middle handles 1034 mm............... -
Page 6: Installation Options
Installation Options Reverse the door swing This refrigerator has door hinges that allow you to change the direction that the door opens by moving the hinges to the opposite corner. 1. Remove the refrigerator from the enclosure, to allow access to the bottom hinges. -
Page 7: Install The Refrigerator
Install the Refrigerator 1. Fasten the refrigerator into the enclosure. (See Art 02736): - Push the refrigerator fully into the enclosure opening - Install shims between enclosure wall and refrigerator to prevent excessive bowing of refrigerator cabinet walls when installin mounting screws. -
Page 8: Connect The Electrical Components
- Alternatively, the connector may be cut off and the connection can be wired via closed-end connectors (bell cap) or crimp connectors. If the factory connector is cut off, proper care should be taken by the OEM to assure that the connection is made properly. Thetford is not responsible for damage caused by improper capped or crimped connections. (RED) - As the distance from the power source to the refrigerator increases, the correct AWG wire size also increases. - Page 9 Connect the Electrical Components 1. Select Wire Size: Assuming a minimum voltage of 12V is supplied by the vehicle battery, AWG wire size should be selected so WARNING that the voltage drop from the vehicle battery s no more than 0.3V. - Recommend Wire Size - - If the distance is 0 - 3 m, use 4mm min.
-
Page 10: Controls
Connect the Electrical Components Controls: Touch and release the ON/OFF [1] button to turn the refrigerator on.(ART02735) - If the indicator light, below the button, glows solid blue, it means the refrigerator is operating correctly. The frozen food compartment and cabinet work independent of each other and both must be adjusted to their NOTICE desired temperature setting.
