Rego-fix toolVibe Tablet Assembly And Operating Manual

Hide thumbs Also See for toolVibe Tablet:
Table of Contents

Advertisement

Quick Links

Download this manual
toolVibe
Tablet
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the toolVibe Tablet and is the answer not in the manual?

Questions and answers

Related Manuals for Rego-fix toolVibe Tablet

Summary of Contents for Rego-fix toolVibe Tablet

  • Page 1 toolVibe Tablet ®...
  • Page 3 Assembly and Operating manual REGO-FIX toolVibe Tablet ® Operating manual REGO-FIX toolVibe Tablet ®...
  • Page 4 Imprint Name: REGO-FIX toolVibe Tablet ® Manufacturer: REGO-FIX AG, Obermattweg 60, CH-4456 Tenniken, Switzerland Phone +41 61 976 14 66, info@rego-fix.com Technical changes: We reserve the right to make alterations for the purpose of technical improvement. Item number: 6000.12420 This instruction manual must be kept for as long as the device is in use. Please read the operating manual in full and keep it close to the product.

  • Page 5: Table Of Contents

    Table of contents General toolVibe power plug ® 1.1 About this manual 4.1 Technical data 1.2 Warranty 4.2 Design, description and operation 1.3 Scope of delivery toolVibe charger ® Basic safety notes 5.1 Technical data 2.1 Product safety 5.2 Design and description 2.2 Intended use 5.3 Using the toolVibe charger ®...

  • Page 6: General

    7] are applicable. NOTE: The illustrations in this manual are intended to provide a basic understanding and may deviate from the actual version. 1.1.1 Definition of Terms In this manual, “product” replaces the product designation on the title page and refers to the complete system with all the individual components. 1.1.2 Presentation of Warning Labels To make risks clear, the following signal words and symbols are used for safety notes. DANGER Dangers for persons! Non-observance will inevitably cause irreversible injury or death. WARNING Dangers for persons! Non-observance can lead to irreversible injury and even death. CAUTION Dangers for persons! Non-observance can cause minor injuries. ATTENTION Material damage! Information about avoiding material damage. Operating manual REGO-FIX toolVibe Tablet ®...

  • Page 7: Warranty

    Tablet ® 1 toolVibe Charger (Item no. 7589.00000) ® 1 toolVibe Power Plug ® 1 toolVibe Tablet Charger ® 1 toolVibe Case ® 1 Assembly and Operating Manual (Item no. 6000.12420) 2. Basic safety notes Product safety The product represents the state of the art and the recognized safety rules. However, the product can pose hazards if, for example: The product is not used as intended. The product is not installed, maintained, stored or transported properly. The safety and installation instructions in this manual are not followed. Avoid any manner of working that could interfere with the function and operational safety of the product. Operating manual REGO-FIX toolVibe Tablet ®...

  • Page 8: Intended Use

    The information in the technical data is not observed when using and operating the product. The product is operated in corrosive media. The maintenance and storage specifications are not complied with. Constructional changes Implementation of structural changes By conversions, changes, and reworking, e.g. additional threads, holes, or safety devices can impair the functioning or safety of the product or damage it. Structural changes should only be made with the written approval of REGO-FIX. Spare parts Use of unauthorized spare parts Using unauthorized spare parts can endanger personnel and damage the product or cause it to malfunction. Use only original spare parts or spares authorized by REGO-FIX. Environmental and operating conditions Required ambient conditions and operating conditions Incorrect ambient and operating conditions can make the product unsafe, leading to the risk of serious i njuries, considerable material damage and/or a significant reduction to the product’s life span. Operating manual REGO-FIX toolVibe Tablet ®...

  • Page 9: Personnel Qualification

    Due to its technical training, knowledge and experience, service personnel of the manufacturer is able to perform the delegated tasks and to recognize and avoid possible dangers. Obligations of the operator The operator must ensure that: The product is only used as intended. The product is only operated in a perfect and fully functional status. The correct functioning of the product is checked regularly. The operating manual is always kept in a complete and legible condition close to the product. The product may only be operated and maintained by sufficiently qualified and authorized personnel. The personnel is familiar with the contents of the operating manual, in particular the safety notes c ontained therein. The personnel are regularly instructed in occupational safety and environmental protection. Personal protective equipment Use of personal protective equipment Personal protective equipment serves to protect staff against danger which may interfere with their health or safety at work. When working on and with the product, observe the occupational health and safety regulations and wear the required personal protective equipment. Observe the valid safety and accident prevention regulations. Wear protective gloves to guard against sharp edges and corners or rough surfaces. Wear heat-resistant protective gloves when handling hot surfaces. Wear protective gloves and safety goggles when handling hazardous substances. Wear close-fitting protective clothing and also wear long hair in a hairnet when dealing with moving components. Operating manual REGO-FIX toolVibe Tablet ®...

  • Page 10: Notes On Safe Operation

    Incorrect handling during transport may impair the product’s safety and cause serious injuries and c onsiderable material damage. When handling heavy weights, use lifting equipment to lift the product and transport it by appropriate means. Secure the product against falling during transportation and handling. Stand clear of suspended loads. To prevent damage to the product during transport, the following must be observed: Protect the product from penetrating humidity (e.g. with suitable packaging). The ambient conditions specified in the technical data must be observed. The product must be protected from vibrations and impacts. All cable connections must be disconnected before transport. Stow product components and accessories in the recesses provided. The latches of the case must be locked. 2.12 Disassembly, removal and storage To prevent damage to the product during disassembly, removal and storage, the following must be observed: The tablet must be charged to at least 80% and then shut down before packing. 2.13 Malfunctions Behavior in case of malfunctions Immediately remove the product from operation and report the malfunction to the responsible departments/persons. Order appropriately trained personnel to rectify the malfunction. Do not recommission the product until the malfunction has been rectified. Test the product after a malfunction to establish whether it still functions properly and no increased risks have arisen. Operating manual REGO-FIX toolVibe Tablet ®...

  • Page 11: Maintenance

    2.14 Maintenance For trouble-free, long-lasting use, clean, maintain and check the functionality of the product regularly. Repair work may only be carried out by REGO-FIX! If you have any questions regarding maintenance and servicing, our technical customer service is available during our business hours: Service-Telefon: +41 61 976 1466 pm@rego-fix.com The specified maintenance intervals are based on practical experience gathered by REGO-FIX and are r ecommended. Depending on the ambient and operating conditions, as well as the clamping frequency of the product, the maintenance intervals must be adapted and noted accordingly. For maintenance intervals with two or more specifications, the valid specification is the one that applies first. After completing essential maintenance work, any required settings and functional tests must be carried out again. 2.15 Disposal Handling of disposal The incorrect handling of disposal may impair the product’s safety and cause serious injuries as well as considerable material and environmental harm. Follow local regulations on dispatching product components for recycling or proper disposal. In accordance with the Waste Electrical and Electronic Equipment (WEEE) Directive, the following must be observed during disposal: This product may not be disposed of in household waste. It must be taken to a collection point for m aterial recovery and recycling.

  • Page 12: Toolvibe Tablet Complete System

    Ambient conditions and operating conditions Value Operating temperature range + 20 °C bis + 50 °C Transport temperature range + 20 °C bis + 50 °C Storage temperature range + 20 °C ± 10 °C 3.1.3 Compatible devices toolVibe toolholder ® toolVibe magnetic holder ® IMPORTANT! The product may only be connected to compatible devices! Operating manual REGO-FIX toolVibe Tablet ®...

  • Page 13: Design And Description

    Design and description 3.2.1 Design toolVibe tablet charger ® toolVibe charger ® toolVibe power plug ® toolVibe case ® toolVibe tablet ® Operating manual REGO-FIX toolVibe Tablet ®...

  • Page 14: Functional Description

    Risk of possible damage to the product. Incorrect transport can damage the product and limit its functionality. Avoid impacts during transport. Store individual product components safely in the toolVibe case. ® Close the toolVibe case. ® Use the carrying handle to transport the toolVibe case. ® Storage When storing the toolVibe Tablet complete system for a longer period of time, the following points ® must be observed: Store the toolVibe Tablet complete system in dry rooms only. ® Protect the toolVibe Tablet complete system from major temperature fluctuations. ® Comply with the storage temperature specified in the technical data. Operating manual REGO-FIX toolVibe Tablet ®...

  • Page 15: Toolvibe Power Plug

    Item number 7589.00000 Weight 0.05 kg Power consumption max 0.45 A USB-A Cable length 1.5 m 5.1.2 Ambient conditions and operating conditions Ambient conditions and operating conditions Value Operating temperature range + 18 °C bis + 25 °C Maximum product temperature + 35 °C Expansion rate monitoring test temperature + 23 °C ± 2 °C Storage temperature + 20 °C ± 10 °C Operating manual REGO-FIX toolVibe Tablet ®...

  • Page 16: Design And Description

    Magnets Charging pins LED display charging status toolVibe ® a) LED does not light up: no charging process b) LED lights up orange: charging process c) LED lights up green: toolVibe fully charged ® 5.2.2 Functional description The toolVibe charger serves as a connecting element between the toolVibe power plug and the toolVibe ® ® ® This can be used to charge the battery of the toolVibe . An LED display integrated in the toolVibe charger ® ® provides information about the current charging status of the toolVibe ® Operating manual REGO-FIX toolVibe Tablet ®...

  • Page 17: Using The Toolvibe Charger

    IMPORTANT! There is a risk of a short circuit if there are metal chips or other conductive materials on the charging pins! Connect the toolVibe charger to the toolVibe power plug via the USB-A connection. ® ® Attach the electrical connection of the toolVibe charger to the charging contact of the toolVibe ® ® via the magnets.  The toolVibe charger snaps into place and the LED display charging status lights up orange. ® NOTE: If the LED does not light up, there is no sufficient contact between the toolVibe charging ® cable and toolVibe ® Operating manual REGO-FIX toolVibe Tablet ®...

  • Page 18: Maintenance

    Risk of injury from electric shock due to contact with live parts! Touching live parts can lead to an electric shock and cause serious injuries. Disconnect the toolVibe charger from the voltage supply. ® Do not touch the charging pins. Check the toolVibe charger regularly for damage. ® Wear suitable protective equipment. CAUTION Injury of the eyes by dirt particles! When cleaning with compressed air, the eyes may be injured by flying dirt particles. Wear suitable protective equipment, particularly protective goggles. Disconnect the toolVibe charger from the voltage supply. ® Remove chips and contamination with compressed air. Use a suitable tool to carefully remove any persistent dirt. Clean the charging pins with a cleaning agent that contains alcohol. Dry the charging pins with a clean cloth. Check the charging pins and the toolVibe charger for damage or wear. ® NOTE: Damage or wear can compromise the functioning of the product. If non-replaceable parts of the product are worn or damaged, return the product to REGO-FIX for inspection. Operating manual REGO-FIX toolVibe Tablet ®...

  • Page 19: Disassembly

    Technical data 6.1.1 Product data General technical data Value Item number 5540.91550 Dimensions 255 x 165 x 28 mm Weight 0.7 kg Power consumption max. 450 mA USB-C Cable length connection cable Wireless transmission range 2.4 GHz For further information on the toolVibe tablet, please refer to the manufacturer’s operating manual. ® NOTE: The operating manual is included in the toolVibe case. ® Operating manual REGO-FIX toolVibe Tablet ®...

  • Page 20: Design And Description Of The Toolvibe ® Tablet

    Possible transmission errors of the sensor data. Obstacles or electromagnetic interference from the environment can cause t ransmission errors during the transmission of sensor data. Correct interpretation of the sensor data is the responsibility of the user. ATTENTION Possible material damage due to humidity. Penetrating humidity can damage the toolVibe tablet and impair its functionality. ® Protect the toolVibe tablet from humidity. ® Information regarding the warnings and risks of using the toolVibe tablet can be found in the tablet ® m anufacturer’s “Quick start” manual. The “Quick start” manual is included in the toolVibe case. ® Operating manual REGO-FIX toolVibe Tablet ®...

  • Page 21: Configuring The Toolvibe ® Tablet And Toolvibe ® App

    ® ® Open the settings of the toolVibe tablet. To do this, either swipe down from the top of the screen (1) ® or swipe up from the bottom of the screen (2). Then tap the gear icon (3). To set it up, make the following settings: The Bluetooth and Wi-Fi connection can be activated in this area. Activation of the Bluetooth connection is mandatory NOTE: Without a Bluetooth connection, no connection with the toolVibe can be established. ® Activation of the Wi-Fi connection is not mandatory. It can be used to transfer data, for example. ATTENTION Security risk due to Bluetooth connection. Activating Bluetooth creates a security risk. It is possible for unauthorized third parties to access the toolVibe tablet. ® Activate Bluetooth only when actively using the toolVibe tablet. ® Operating manual REGO-FIX toolVibe Tablet ®...
  • Page 22 The display settings can be managed in this area. We recommend the following settings: Font size: Level 4 Screen zoom: Level 2 Screen timeout: approx. 30 minutes The location settings can be managed in this area. Activation of the location access is mandatory. NOTE: Without location access, the toolVibe app will not work correctly. ® All installed apps are displayed in this area. The permissions of an app can be managed by tapping on an app. Tap the toolVibe ® Allow location access for the toolVibe app via permissions. ® NOTE: Without location access, the toolVibe app will not work correctly. ® Operating manual REGO-FIX toolVibe Tablet ®...

  • Page 23: Operating The Toolvibe ® Tablet And Toolvibe ® App

    ® ® NOTE If the tablet no longer responds to inputs, a restart can be forced. To do this, press the “ON/OFF” button and the «Volume down» button simultaneously for 7 seconds. 6.5.1 Design and description of the toolVibe ® Einstellungen Lizenzen Über toolVibe selection About ® Project selection Live display Process selection Trend display Battery charge level Recordings Configuration area Alarm display Settings Manage process Licenses Sensor Operating manual REGO-FIX toolVibe Tablet ®...
  • Page 24 Opening and closing the toolVibe ® Opening the toolVibe ® Press the On/Off button on the toolVibe tablet and swipe up to unlock it. ® NOTE: If the toolVibe tablet does not start, press the On/Off button for 5 seconds to start it. ® If it is still not s tarting, connect the toolVibe tablet to the toolVibe tablet charger. ® ® Tap the toolVibe app icon ® Operating manual REGO-FIX toolVibe Tablet ®...
  • Page 25 The toolVibe app opens.  ® Closing/minimizing the toolVibe ® To close the toolVibe app, tap on the symbol with the 3 lines (1) and either: ®  Close all apps by tapping “Close all” (a), or  c lose only the toolVibe app by swiping up on the toolVibe app (b). ® ® 2. To minimize the toolVibe app, tap the square icon at the bottom (2) ® The toolVibe app is still active in the background.  ® Operating manual REGO-FIX toolVibe Tablet ®...
  • Page 26 ® SCANNING… ITN-TH-HSK-A63 DISCONNECTED Connecting toolVibe ® Make sure that the Bluetooth connection is enabled on the toolVibe tablet  6.4 [ 21]. ® Start the toolVibe  6.5.2 [ 24]. ® Start the scan process by tapping the “ITN-TH-DEMO” button (1).  A list of sensors where a connection is possible appears. NOTE: If the desired sensor does not appear, connect the toolVibe to the toolVibe ® ® charger and try again later. Operating manual REGO-FIX toolVibe Tablet ®...
  • Page 27  6.5.2 [ 24]. ® Tap the “Projects…” button (1).  T he “Projects…” submenu opens. Tap the “Add project…” button. Enter the project name. Tap the “OK” button to save the project.  T he project is displayed in the “Projects…” submenu. Creating a process Ensure that the associated project has been created. Tap the “Processes…” button (2).  T he “Processes…” submenu opens. Tap the “Add process…” button. Enter the process name. Tap the “OK” button to save the process.  T he process is displayed in the “Processes…” submenu. NOTE: In the “Manage process” display mode, projects and processes can be renamed, changed, moved or copied  Manage process display mode [ 37]. Operating manual REGO-FIX toolVibe Tablet ®...

  • Page 28: Creating Screenshots

    Creating screenshots There are two ways of creating screenshots in the toolVibe app: ® Briefly press the On/Off button and the Volume down button simultaneously (1). NOTE: This allows screenshots to also be created outside of the toolVibe app. ®  S creenshot is saved in the gallery. tap the camera button in the toolVibe app (2). ® NOTE: This function is only available in the Live, Trend and Recordings display modes.  S creenshot is saved in the gallery. Accessing the screenshots Screenshots are saved in the gallery. Press the square icon in the center at the bottom of the screen to open the toolVibe tablet start screen. ® Tap the gallery button.  T he gallery opens, and the screenshots can be accessed. Operating manual REGO-FIX toolVibe Tablet ®...
  • Page 29 Display modes of the toolVibe ® There are different display modes that can be selected by tapping the corresponding button. Live display mode In the Live display mode, the toolVibe can be selected. The detected vibration data from the sensor is ® d isplayed in the central diagram. Data from other sensors that have been connected to the toolVibe ® app in the last 4 hours can also be displayed in the central diagram. Sensors selection Project selection Process selection Camera button Settings menu automatic recordings Settings menu alarm limit Time range selection button Stop the display Activate/stop manual recording button Manual zoom (X-axis) Manual zoom (Y-axis) Activate/stop automatic recording button Reset view Settings menu scale parameters of the Y-axis Operating manual REGO-FIX toolVibe Tablet ®...

  • Page 30: Project Selection

    NOTE: T he background is not colored blue in the manual recording. Manual recordings are only available in Recording mode and not in the Trend mode. Manual zoom (X-axis) Allows arbitrary zooming in or out of the diagram view from the X-axis (time) by expanding or contracting the fingers. Manual zoom (Y-axis) Allows arbitrary zooming in or out of the diagram view from the Y-axis (chatter index) by expanding or c ontracting the fingers. Activate/stop automatic recording button Button for activating (blue) or stopping (red) the automatic recording. If the automatic recording is activated, it will be started depending on the parameters set in the automatic recording settings menu. When a recording is taking place, the background is colored blue. NOTE: The background is only colored blue in automatic recordings. Reset view Allows the settings of the scale parameters to be reset for the axes and the manual zoom in the live diagram. Settings menu scale parameters of the Y-axis Allows the settings of the scale parameters to be set and reset for the Y-axis of the central diagram. Operating manual REGO-FIX toolVibe Tablet ®...
  • Page 31 Bar-specific information Reset view Settings menu scale parameters of the Y-axis Allows the settings of the scale parameters to be set and reset for the Y-axis of the central diagram. Camera button Allows screenshots of the central diagram to be taken  6.5.5 [ 28]. The screenshots are saved in the gallery. Settings menu trend limits Allows trend limits to be set. Trend upper limit and trend lower limit values are displayed as colored lines in the central diagram. When a trend alarm is triggered, it is listed in the Alarm display mode  Alarm display mode [ 36]. Number of bars shown button Allows the number of bars to be selected for the data to be displayed in the central diagram. Operating manual REGO-FIX toolVibe Tablet ®...
  • Page 32 Activate/stop automatic recording button Button for activating (blue) or stopping (red) the automatic recording. If the automatic recording is activated, it will be started depending on the parameters set in the automatic recording settings menu. Manual zoom (X-axis) Allows arbitrary zooming in or out of the diagram view from the X-axis (number of bars) by expanding or contracting the fingers. Manual zoom (Y-axis) Allows arbitrary zooming in or out of the diagram view from the Y-axis (chatter index) by expanding or contracting the fingers. Bar-specific information Tapping the bars displays information about the individual recordings. Reset view Allows the settings of the scale parameters to be reset for the axes and for manual zoom in the trend diagram. Display mode recordings In the Recordings display mode, all manual and automatic recordings of processes are listed. If required, the different recordings can be displayed as different colored lines in the central diagram. NOTE: The legend to the right of the central diagram assigns a recording to each colored line. Settings menu scale parameters of the Y-axis Camera button Overview of recorded processes Manual zoom (Y-axis) Manual zoom (X-axis) Operating manual REGO-FIX toolVibe Tablet ®...
  • Page 33 33] (d) NOTE: The decimal separator in the CSV file can be changed in the settings (point or comma)  6.5.1 [ 23]. Deleting the selected recordings (e) Manual zoom (Y-axis) Allows arbitrary zooming in or out of the diagram view from the Y-axis (chatter index) by expanding or c ontracting the fingers. Manual zoom (X-axis) Allows arbitrary zooming in or out of the diagram view from the X-axis (time) by expanding or contracting the fingers. Exporting recordings / managing exported recordings Exporting recordings In the Recordings display mode, data can be exported in CSV file format. To do this proceed as follows. NOTE: T he decimal separator in the CSV file can be changed in the settings (point or comma)  6.5.1 [ 23]. Operating manual REGO-FIX toolVibe Tablet ®...
  • Page 34 Open the overview of recorded processes by tapping the button. Select the recording whose data is to be exported. Tap the “EXPORT” button to specify the storage location of the data.  A destination folder for saving can be set (a) or newly created (b). Adjust the name of the exported data as needed. NOTE: The extension .csv is determined by the file format and must not be changed. Tap the “Save” button to export the data. Finding exported recordings To access the exported data open the “My Files” button. Current files Search Documents Downloads Current files Under “Current files” you can see the last saved files. Search Under “Search” files can be searched for by their file name. Documents An overview of all folders appears under “Documents”. Here you can open the desired file. Downloads Under “Downloads” you can see all recently downloaded files. Operating manual REGO-FIX toolVibe Tablet ®...
  • Page 35 Managing exported recordings Open the appropriate folder with the desired file. Tap and hold the file with your finger for a few seconds.  A selection bar (a) opens in which the file can be released (b) or, for example, renamed (c). Tap the file to open it. To open the file with a special program, tap and hold the file with your finger for a few seconds, then tap “More” and “Open with” in the selection bar (a). Operating manual REGO-FIX toolVibe Tablet ®...
  • Page 36 Alarm display mode In the Alarm display mode, all alarms that have occurred recently are displayed. To delete an individual alarm, the “X” button must be tapped (1). To delete all alarms, the “Delete all alarms” button must be tapped (2). There are 3 different types of alarms: Alarm from the Trend display for the lower exact limit Alarm from the Live display when the exact limit is exceeded Alarm from the trend display for the upper exact limit For more detailed information on an alarm, tap the corresponding alarm. Tapping an alarm opens the Trend display or the Recording display and selects the corresponding recording of the alarm. NOTE: The respective trend exact limits can be set in the Trend display mode  Trend display mode [ 31]. Operating manual REGO-FIX toolVibe Tablet ®...
  • Page 37 NOTE: If not all areas are visible, you can scroll down or adjust the font size of the tablet. Project settings area In this area you can change the project name or delete the project. Button to save the new project name (i) Button to delete the project (h). IMPORTANT! If a project is deleted, all processes contained in it are also deleted! Process settings area In this area the selected process can be renamed, commented on or deleted. Change the process name or write a comment (a). NOTE: A process name is always required. Area for setting the automatic recordings (b). Area for setting the alarm from the Live display mode (c). Area for setting the alarm from the Trend display mode (d). Button to save the changes (e). Button to move (with recordings) or copy (without recordings) the process to another project (f). Button to delete the process (g). Operating manual REGO-FIX toolVibe Tablet ®...
  • Page 38 Settings for sensor area In this area, the name and number of the sensor can be set and changed. The new settings will only be displayed after disconnecting and reconnecting  6.5.3 [ 26] with the toolVibe ® Button to save the changed settings (h). Button to reset the settings (g). NOTE: The name of the sensor is reset to the serial number (c) of the corresponding toolVibe ® Information about sensor area Information about the sensor is displayed in this area. NOTE: The information in this area cannot be changed by the customer. Product designation (b). Material number (b). Serial number of the toolVibe (c). ® Software version (d). Electronic serial number (e). Hardware version (f). Operating manual REGO-FIX toolVibe Tablet ®...
  • Page 39 ® 2. Select the “Sensor” area  Sensor display mode [ 38]. The software version of the toolVibe sensor is displayed in the “Information about sensor” area.  ® Activating raw data recording Open the configuration area of the toolVibe  6.5.1 [ 23]. ® Select the “Settings” area. Tap slider “toolVibe Tablet Raw Data”. ®  The slider moves to the right and turns blue.  In the Live display mode, the “Start raw signal recording” button appears.  The Raw Data display mode appears in the sidebar. Operating manual REGO-FIX toolVibe Tablet ®...
  • Page 40 Recording raw data Start raw signal recording button Starts raw data recording 1. Select Live display mode  6.5.1 [ 23]. Select the blue button “Stop raw signal recording”.  Starts recording of raw data.  Start raw signal recording” button turns red. NOTE: Raw data acquisition can be active parallel to manual or automatic recording. However, recordings can only be started if a project and a process are selected. Stopping raw data recording 1. Select Live display mode  6.5.1 [ 23]. Select the red button “Stop raw signal recording”.  Recording of raw data is stopped.  Start raw signal recording” button turns blue. Operating manual REGO-FIX toolVibe Tablet ®...

  • Page 41: Charging The Toolvibe Tablet

    ® ® ® IMPORTANT! Do not charge the toolVibe tablet for more than one week, otherwise ® there is a risk of overcharging the battery. For further information on charging the toolVibe tablet, ® please refer to the tablet manufacturer’s operating manual. NOTE: The operating manual is included in the toolVibe case. ® Operating manual REGO-FIX toolVibe Tablet ®...

  • Page 42: Cleaning The Toolvibe ® Tablet

    ® ® For cleaning, use a soft cloth or sponge slightly moistened with a mild detergent. Do not use a cloth or sponge that could scratch the surface. Clean the touch display with a soft, clean, cloth or sponge sprayed with window or glass cleaner. Never spray the cleaning agent directly onto the touchscreen. Do not use alcohol (methyl, ethyl or i sopropyl alcohol), thinners, benzines or other abrasive cleaners. Note the following for cleaning the USB-C charging connection: Do not use any liquids or chemicals to clean the charging connection. Only clean the charging connection very carefully with a suitable tool. Storage When storing the toolVibe tablet, the following points must be observed: ® Store the toolVibe tablet in a suitable transport container. ® Store the toolVibe tablet in dry rooms only. ® Protect the toolVibe tablet from major temperature fluctuations. ® Comply with the storage temperature specified in the technical data. Operating manual REGO-FIX toolVibe Tablet ®...

  • Page 43: Troubleshooting

    7. Troubleshooting Repair work may only be carried out by REGO-FIX! If you have any questions regarding maintenance and servicing, our technical customer service is available during our business hours: Service-Telefon: +41 61 976 1466 pm@rego-fix.com Possible malfunction /occurring errors Possible causes Remedial measures toolVibe does not connect toolVibe is not charged Charge the toolVibe ® ® ® Incorrect toolVibe (name) Check the selected name ®...

  • Page 44: Disposal

    Check socket Plug connection, loose USB Check plug connection cable toolVibe tablet charger Return the toolVibe tablet charger ® ® damaged to REGO-FIX toolVibe power plug Return the toolVibe power plug ® ® damaged to REGO-FIX 8. Disposal This product may not be disposed of in household waste. It must be taken to a collection point for material recovery and recycling. Follow local regulations on dispatching product components for recycling or proper disposal. Alternatively, you can return the product to REGO-FIX for correct disposal. Operating manual REGO-FIX toolVibe Tablet ®...

  • Page 45: Eu Declaration Of Conformity

    2.4 GHz band – Harmonized standard for radio frequency usage Additionally, the product is declared to conform with the following standards and EU directives: DIN EN ISO 12100 Safety of the machines 2014/30/EU EMV Directive 2014/53/EU Radio Equipment Directive 2011/65/EU RoHS Directive Authorised representative for compiling the technical documentation: Herr Roman Ackeret REGO-FIX AG Obermattweg 60 CH-4456 Tenniken Tenniken, 12.03.2025 Richard Weber, CEO Pascal Forrer, Designated CEO Operating manual REGO-FIX toolVibe Tablet ®...
  • Page 46 Operating manual REGO-FIX toolVibe Tablet ®...
