Clas Ohlson S5034 Manual

Indoor Thermometer/
Hygrometer
Art.no 36-8993 Model S5034
Please read the entire instruction manual before using
the product and then save it for future reference.
We reserve the right for any errors in text or images
and any necessary changes made to technical data.
In the event of technical problems or other queries,
please contact our Customer Services.
Safety
Warning:
• The product contains a button cell battery. Never
put batteries in your mouth and always handle them
with care. There is a risk of serious injury. Keep new
and used batteries out of the reach of children.
• Never use the product if the battery compartment
is damaged.
• If you suspect that a battery has been swallowed or
otherwise entered the body, seek medical attention
immediately.
• The thermometer must not be dismantled or
modified in any way.
• The thermometer is only intended for indoor use.
Do not expose it to moisture.
• The thermometer is not intended to be used as
a reference thermometer and Clas Ohlson will not
be held liable for any damage which may result from
inaccurate readings.
• The battery should be removed from the thermo-
meter if it is not to be used for an extended period,
otherwise the battery might leak and damage
the thermometer. Never leave a discharged battery
in the battery compartment.
• The thermometer must never be subjected to
shocks or impacts.
Specifications
Temperature (indoor) −10 to 50 ºC (14 to 122 ºF)
Relative humidity
5 to 99% RH
(indoor)
Battery 1 × CR2032 (included)
Size 45 × 58 × 13 mm
Weight 31 g
Buttons and functions
88 1 2 3 4 5 6
1. Indoor temperature
2. Comfort level indicator
3. Trend indicator
4. [ C/F ] For selecting temperature unit, °C or °F
5. Humidity
6. Battery cover
7. Table stand
8. Magnet (not visible, located underneath rear panel)
9. Hanging slot
Installation
1. Slide the battery cover (6) down to access
the battery compartment.
2. Insert 1 × CR2032 battery (included) observing
the polarity markings in the battery compartment.
3. Click the battery cover back into place.
4. Choose where the thermometer is to be placed:
- Standing on a flat surface using the table stand (7).
- Hanging on a wall using the hanging slot (9).
- Attached to a magnetic surface such as a fridge
door using the internal magnet (8).
Operating instructions
Select the units, Celsius or Fahrenheit, using the [ C/F ]
button (4). The display will continuously show the current:
• Temperature
• Humidity
• Comfort level
Comfort level
The comfort level symbol (2) gives a visual indication
9
of the comfort level, i.e. how the body perceives
the current humidity.
8
Humidity lower than < 35 %
Humidity between 35 and 65%
Humidity higher than 65%
Trend indicator
7
The symbol (3) shows the humidity trend.
Rising humidity
Unchanged humidity
Decreasing humidity
• After changing the battery, it takes about one hour
for the trend indicator to appear.
• The rising/falling symbol appears if the humidity
increases/decreases by at least 5% within one hour.
Care and maintenance
Clean the product using a lightly moistened cloth.
Use only mild cleaning agents, never solvents or
corrosive chemicals.
Responsible disposal
This symbol indicates that this product
should not be disposed of with general
household waste. This applies throughout
the entire EU. In order to prevent any
harm to the environment or health hazards
caused by incorrect waste disposal,
the product must be handed in for recycling
so that the material can be disposed of in a responsible
manner. When recycling your product, take it to your
local collection facility or contact the place of purchase.
They will ensure that the product is disposed of in
an environmentally sound manner.
English
