- Page 1 Install / Use & Care MANUAL Professional Undercounter Ice Machine FIUI5152DADA...
-
Page 2: Table Of Contents
CONTENTS Important Safety Instructions Contents: Warnings and safety instructions appearing in this Important Safety Instructions ..........2 guide are not meant to cover all possible conditions and Unpacking Your Appliance ..........3 situations that may occur. Common sense, caution, and Installing Your Appliance .............4 care must be exercised when installing, maintaining, or Door Reversal ..............6 operating this appliance. -
Page 3: Unpacking Your Appliance
If there is damage, the packaging will be needed as proof of damage in transit. Afterwards please dispose of all items responsibly. VIKING RANGE, LLC GREENWOOD, MS 38930 WARNING XXXXXXXXXXXX... -
Page 4: Installing Your Appliance
Viking Range, LLC does not recom- Raise or lower the legs to the required dimension by turning mend the use of a custom made grille as air fl ow may be the legs. -
Page 5: Electrical Shock Hazard
INSTALLING YOUR APPLIANCE WARNING Electrical Shock Hazard Do not remove • Do not use an extension cord with this appliance. ground prong They can be hazardous and can degrade product performance. • This appliance should not, under any circumstanc- es, be installed to an un-grounded electrical supply. •... -
Page 6: Door Reversal
DOOR REVERSAL Door Reversing Instructions Tools Needed: • 1/8” Hex Key • 5/32” Hex Key • Phillips Screwdriver Open door and remove Hinge Pin from the Upper Hinge using a 1/8” Hex Key tool making sure to steady the Using a Phillips Screwdriver, remove the 6 screws from both the Upper and Lower Hinges and save for later steps Once the Hinges are removed from the unit, using a Phillips Screwdriver, remove the Bushing Screw and Hinge Pin Screw and save for later steps On the Bottom Hinge, reattach the Bushing Screw and Hinge Pin Screw to the opposite side... - Page 7 DOOR REVERSAL 6. Remove the door switch actuator tab from the door and attach it to the opposite side Door switch actuator tab 7. Reattach the Upper and Lower Hinges, and Hinge Brackets to opposite sides. Then install the door.
-
Page 8: Installing The Drain Plumbing
INSTALLING THE DRAIN PLUMBING CAUTION CAUTION Failure to use an adequate drainage system, will result in Observe and follow all local building codes Water when installing this ice machine and drain surrounding water damage and/or poor ice production. supply lines. inlet ⁄... - Page 9 Uncoil, route to an appropriate drain and cut to length. CAUTION This drain pump is designed to be installed in Viking ice machines only and approved for use with water only. WARNING Drain pump vent tube.
-
Page 10: Installing The Water Supply
INSTALLING THE WATER SUPPLY Water Supply CAUTION Observe and follow all local building codes when installing this appliance. This ice machine must be connected to a potable cold water supply line. delivering water pressure between a minimum of 20 psi and a maximum of 120 psi. ⁄... -
Page 11: Drain System Test
DRAIN SYSTEM TEST CAUTION Procedure for Testing Drain System (both gravity and drain pump models) Drain pump models have a safety feature that will interrupt power to the unit if a high-limit condition occurs to prevent flooding. This safety feature can be initiated by a restriction in the drain system and will continue until high-limit condition is corrected, at which time power will be restored to the unit. -
Page 12: Operation Of The Ice Machine
OPERATION OF THE ICE MACHINE The Ice Making Process When the ice slab reaches the correct thickness, the ice Your ice machine is unique in how it forms ice with fraction- sheet is released and slides onto the grid cutter. Here, the al freezing to form a slab of ice that is clear and has less ice slab is cut into squares by the grid cut-ter’s heated dissolved solids than the water it is produced from. - Page 13 OPERATION OF THE ICE MACHINE Ice Production The ice machine will keep producing ice until the ice machine’s bin is full and will restart automatically when In normal mode the ice machine will produce up to 39 ice needs to be replenished in the bin. The ice bin is pounds (17.7 kg) of clear ice in a 24-hour period when not refrigerated, and some melting will occur by design installed in a 72°F ambient with a 55°F water supply.
-
Page 14: Cutout & Product Dimensions
CUTOUT AND PRODUCT DIMENSIONS ROUGH-IN OPENING DIMENSIONS CABINET DIMENSIONS "A" "B" "C" "D" "E" "F" "G" "H" "J" 15" 31 1/4” to 32 1/4" 24" 14 7/8" 31” to 32" 22 7/8" 37 3/8" 14 1/4" (38.1 cm) (79.4 cm to 81.9 cm) (61 cm) (37.8 cm) (78.7 cm to 81.2 cm) - Page 15 CUTOUT AND PRODUCT DIMENSIONS PRODUCT DATA ELECTRICAL PRODUCT REQUIREMENTS # WEIGHT 105 lbs 115V/60Hz/15A (47.6 kg) "J" "H" "D" "G" "E" " (54.6 cm) "F" Glass Door Shown Minimum rough-in opening required is to be larger than the adjusted height of the cabinet. A grounded 15 amp dedicated circuit is required.
-
Page 16: Integrated Panel Dimensions
INTEGRATED PANEL DIMENSIONS NOTE Panel thickness may be 5/8" or 3/4" Center the unit in the 24" opening If the hinge side of the product is pressed against the adjacent cabinet, use a 5/8" thick panel The window cutout is for glass door models only Do not use a solid door panel on a glass door model 15"... -
Page 17: Integrated Panel Installation
INTEGRATED PANEL INSTALLATION Step 2: Remove the Door Gasket Cut and prepare panels according to the information provided in the Integrated Panel Dimensions section. With the door laying on a flat surface and starting at a corner of the door, remove the magnetic door gasket from the interior side of the door. -
Page 18: Step 4: Install The Door
INTEGRATED PANEL INSTALLATION Step 4: Install the Door If reversing the door swing, reinstall hinges per Door Reversal Instructions. Carefully slide lower hinge bushing over bottom hinge pin. Install the new upper hinge bushing into adaptor plate. Align hinge bushing with top hinge and reinstall upper hinge pin using 1/8”... -
Page 19: Using Your Electronic Control
USING YOUR ELECTRONIC CONTROL USING YOUR ELECTRONIC CONTROLS Control Function Guide Function Command Notes ON/OFF Press and release. Unit will immediately turn ON or OFF. Option Open Door Closed Door White White Hold and press and release . Press Adjust light color to scroll through lighting options. - Page 20 USING YOUR ELECTRONIC CONTROLS BrightShield™ This model includes BrightShield™ with Vyv™ Antimicrobial Light Technology. BrightShield™ • Kills* and prevents the growth of viruses, bacteria, fungi, yeasts, mold, and mildew • Provides continuous antimicrobial action to keep surfaces clean • Is approved for continuous use around people, pets, & plants •...
-
Page 21: Clean Reminder
Forcing ice through the grid cutter will break the grid cutter wires. Remove all ice from the evaporator plate and grid cutter area that is not embedded in wires CAUTION Use only Viking approved ice machine cleaner and follow all label warnings and directions. Incorrect chemical warranty. - Page 22 CARE AND CLEANING Remove ice from bin. Pull plug from the reservoir. Once reservoir is empty, replace plug. Hold the button for 10 seconds to show "CL" on the display. Lift Fascia door to access evaporator plate. Lift or remove splash shield to expose evaporator plate.
- Page 23 CARE AND CLEANING Front Grille Be sure that nothing obstructs the required air fl ow open- ings in front of the cabinet. At least once or twice a year, brush or vacuum lint and dirt from the front grille area (see page 4).
-
Page 24: Troubleshooting
TROUBLESHOOTING Before You Call for Service WARNING If the appliance appears to be malfunctioning, read through this manual first. If the problem persists, check the trouble- shooting guide below. Locate the problem in the guide and Electrocution Hazard refer to the cause and its remedy before calling for service. •... - Page 25 TROUBLESHOOTING Ice Quality Troubleshooting the Drain Pump Odor, grey color, or off taste in the ice Is there mineral scale build up on the evaporator NOTE plate? The ice machine needs cleaning. See “Cleaning the Ice Machine”. If the drain pump reservoir (not the ice machine bin) reaches overfill condition, the power to the ice machine will Is there a high mineral content in the water? The water may need to be filtered.
-
Page 26: Service Information
Clearly describe the problem that you are having. If you are unable to obtain the name of an authorized service agency, or if you continue to have service problems, contact Viking Range, LLC at (888) 845-4641 or write to: VIKING RANGE, LLC... -
Page 27: Warranty
Any sealed refrigeration system component, as listed below, is warranted to be free from defective materials or workmanship in normal household use during the third through the sixth year from the date of original retail purchase. Viking Range, LLC, warranter, agrees to repair or replace, at its option, any part which fails or is found to be defective during the warranty period. - Page 28 Viking Range, LLC 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, call 1-888-(845-4641) or visit our web site at vikingrange.com in the US or brigade.ca in Canada 30741 (110824)
