- Page 1 Install / Use & Care MANUAL Professional Undercounter Ice Machine FIUI5152D...
-
Page 2: Table Of Contents
CONTENTS Important Safety Instructions Contents: Warnings and safety instructions appearing in this Important Safety Instructions ..........2 guide are not meant to cover all possible conditions and Unpacking Your Appliance ..........3 situations that may occur. Common sense, caution, and Installing Your Appliance .............4 care must be exercised when installing, maintaining, or Door Reversal ..............6 operating this appliance. -
Page 3: Unpacking Your Appliance
If there is damage, the packaging will be needed as proof of damage in transit. Afterwards please dispose of all items responsibly. VIKING RANGE, LLC GREENWOOD, MS 38930 WARNING XXXXXXXXXXXX... -
Page 4: Installing Your Appliance
Viking Range, LLC does not recom- Raise or lower the legs to the required dimension by turning mend the use of a custom made grille as air fl ow may be the legs. -
Page 5: Electrical Shock Hazard
INSTALLING YOUR APPLIANCE WARNING Electrical Shock Hazard Do not remove • Do not use an extension cord with this appliance. ground prong They can be hazardous and can degrade product performance. • This appliance should not, under any circumstanc- es, be installed to an un-grounded electrical supply. •... -
Page 6: Door Reversal
DOOR REVERSAL Door Reversing Instructions 1. Open door. 2. Loosen screw #1 and #2 using a Philips Screwdriver on top and bottom hinge. Slide door and remove the door from the unit. Figure 7 3. Once door is removed, using a Philips Screwdriver remove screws from magnet actuator located on inside and bottom of door. -
Page 7: Installing The Drain Plumbing
INSTALLING THE DRAIN PLUMBING CAUTION CAUTION Failure to use an adequate drainage system, will result in Observe and follow all local building codes Water when installing this ice machine and drain surrounding water damage and/or poor ice production. supply lines. inlet ⁄... - Page 8 Uncoil, route to an appropriate drain and cut to length. CAUTION This drain pump is designed to be installed in Viking ice machines only and approved for use with water only. WARNING Drain pump vent tube.
-
Page 9: Installing The Water Supply
INSTALLING THE WATER SUPPLY Water Supply CAUTION Observe and follow all local building codes when installing this appliance. This ice machine must be connected to a potable cold water supply line. delivering water pressure between a minimum of 20 psi and a maximum of 120 psi. ⁄... -
Page 10: Drain System Test
DRAIN SYSTEM TEST CAUTION Procedure for Testing Drain System (both gravity and drain pump models) Drain pump models have a safety feature that will interrupt power to the unit if a high-limit condition occurs to prevent flooding. This safety feature can be initiated by a restriction in the drain system and will continue until high-limit condition is corrected, at which time power will be restored to the unit. -
Page 11: Operation Of The Ice Machine
OPERATION OF THE ICE MACHINE The Ice Making Process When the ice slab reaches the correct thickness, the ice Your ice machine is unique in how it forms ice with fraction- sheet is released and slides onto the grid cutter (see al freezing to form a slab of ice that is clear and has less Figure 18). - Page 12 OPERATION OF THE ICE MACHINE Ice Production The ice machine will keep producing ice until the ice machine’s bin is full and will restart automatically when In normal mode the ice machine will produce up to 39 ice needs to be replenished in the bin. The ice bin is pounds (17.7 kg) of clear ice in a 24-hour period when not refrigerated, and some melting will occur by design installed in a 72°F ambient with a 55°F water supply.
-
Page 13: Cutout & Product Dimensions
CUTOUT AND PRODUCT DIMENSIONS ROUGH-IN OPENING DIMENSIONS CABINET DIMENSIONS “A” “B” “C” “D” “E” “F” “G” “H” “J” 15” 34” to 35” 24” 14 7/8” 33 3/4” to 34 3/4” 22 7/8” 38 7/8” (38.1 cm) (86.4 cm to 88.9 cm) (61 cm) (37.8 cm) (85.7 cm to 88.3 cm) - Page 14 CUTOUT AND PRODUCT DIMENSIONS PRODUCT DATA ELECTRICAL PRODUCT REQUITEMENTS # WEIGHT 105 lbs 115V/60Hz/15A (47.6 kg) “H” “D” “F” “E” 21 1/2” Figure 24 3 1/2” (8.9 cm) (54.6 cm) Minimum Minimum rough-in opening is required to be larger than the adjusted height of the cabinet.
-
Page 15: Integrated Panel Dimensions
INTEGRATED PANEL DIMENSIONS Clearance Clearance for hinge for hinge at top and at top and bottom bottom Figure 25 Figure 26 Right Hand Hinged Door Left Hand Hinged Door 15" (38.1 cm) wide appliance 15" (38.1 cm) wide appliance Figure 27 Figure 28 ⁄... -
Page 16: Integrated Panel Installation
INTEGRATED PANEL INSTALLATION Integrated door panel installation: If you purchased an integrated panel model, your unit is equipped with articulated hinges to allow fully integrated built-in installations. Custom panel thicknesses of ⁄ " (15 mm) and ⁄ " (18 mm) are accommodated. CAUTION It is important to use the factory provided grille that came with the product to assure proper air flow is maintained... - Page 17 INTEGRATED PANEL INSTALLATION WARNING Use extreme caution with the articulated hinges. The hinge is self closing and many pinch points exist prior to built-in installation. Do not remove the cabinet "Z" bracket from the top of the cabinet. Integrated Step 2: Remove the door gasket panel flush With the door laying on a flat surface and starting at a with top and...
- Page 18 INTEGRATED PANEL INSTALLATION CAUTION Weight of integrated door panel must not exceed 15 pounds (6.8 kg) for a solid door model or 10 pounds (4.5 kg) for a glass door model. Figure 31a #10 x ⁄ " screw Material Type #10 Wood Screw Hardwood ⁄...
-
Page 19: Step 5: Install The Door
INTEGRATED DOOR PANEL INSTALLATION INTEGRATED PANEL INSTALLATION Step 5: Install the door Carefully open the top and bottom hinges on the door being careful as there are many pinch points. Place the hinges over the 4 screws in the cabinet, 2 at the top and 2 at the bottom and slide the door into position. -
Page 20: Using Your Electronic Control
USING YOUR ELECTRONIC CONTROLS Control Function Guide Function Command Notes ON/OFF Press and release. Unit will immediately turn ON or OFF. Option Open Door Closed Door White White Hold and press and release . Press Adjust light color to scroll through lighting options. BrightShield BrightShield White... - Page 21 USING YOUR ELECTRONIC CONTROLS BrightShield™ This model includes BrightShield™ with Vyv™ Antimicrobial Light Technology. BrightShield™ • Kills* and prevents the growth of viruses, bacteria, fungi, yeasts, mold, and mildew • Provides continuous antimicrobial action to keep surfaces clean • Is approved for continuous use around people, pets, & plants •...
-
Page 22: Clean Reminder
Forcing ice through the grid cutter will break the grid cutter wires. Remove all ice from the evaporator plate and grid cutter area that is not embedded in wires CAUTION Use only Viking approved ice machine cleaner and follow all label warnings and directions. Incorrect chemical warranty. - Page 23 CARE AND CLEANING Remove ice from bin. Pull plug from the reservoir. Once reservoir is empty, replace plug. Hold the button for 10 seconds to show "CL" on the display. Lift Fascia door to access evaporator plate. Lift or remove splash shield to expose evaporator plate.
- Page 24 CARE AND CLEANING Front Grille Be sure that nothing obstructs the required air fl ow open- ings in front of the cabinet. At least once or twice a year, brush or vacuum lint and dirt from the front grille area (see page 4).
-
Page 25: Troubleshooting
TROUBLESHOOTING Before You Call for Service WARNING If the appliance appears to be malfunctioning, read through this manual first. If the problem persists, check the trouble- shooting guide below. Locate the problem in the guide and Electrocution Hazard refer to the cause and its remedy before calling for service. •... - Page 26 TROUBLESHOOTING Ice Quality Troubleshooting the Drain Pump Odor, grey color, or off taste in the ice Is there mineral scale build up on the evaporator NOTE plate? The ice machine needs cleaning. See “Cleaning the Ice Machine”. If the drain pump reservoir (not the ice machine bin) reaches overfill condition, the power to the ice machine will Is there a high mineral content in the water? The water may need to be filtered.
-
Page 27: Service Information
Clearly describe the problem that you are having. If you are unable to obtain the name of an authorized service agency, or if you continue to have service problems, contact Viking Range, LLC at (888) 845-4641 or write to: VIKING RANGE, LLC... -
Page 28: Warranty
Any sealed refrigeration system component, as listed below, is warranted to be free from defective materials or workmanship in normal household use during the third through the sixth year from the date of original retail purchase. Viking Range, LLC, warranter, agrees to repair or replace, at its option, any part which fails or is found to be defective during the warranty period. - Page 30 Viking Range, LLC 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, call 1-888-(845-4641) or visit our web site at vikingrange.com in the US or brigade.ca in Canada 30740 (110824)
