- Page 1 Teison DC Split TS-EDH240-1040...
- Page 2 Product overview Overall features Parameter Instructions Operating Instructions Installation instructions Teison profile Factory history...
-
Page 3: Product Overview
Product overview Group Charger Logo Indicator Emergency button Equipment lock OCPP J-son WIFI... - Page 4 Product overview Charging Terminal Logo Indicator LCD screen RFID card Emergency button Charging Connector Output cable OCPP RFID RFID J-son WIFI...
-
Page 5: Overall Features
Overall features Multiple standard charging port combinations to choose from CCS2、 CCS1、 CHAdeMO and GB/T can be combined and customized. Diverse power range Multiple power options are available, ranging from 240 kW to 1040 kW with customizability. Dynamic power module management Dynamically optimized power module management that adapts to maximum e ciency output in various power output states. - Page 6 Parameter Instructions Split Type DC Charger Model TS-EDH1040 TS-EDH960 TS-EDH880 TS-EDH800 Output power 1040kW 960kW 880kW 800kW Output voltage 200-1000V Input voltage 400V±10%(Three phase five wire） Input current 3*1580A 3*1459A 3*1337A 3*1216A Working frequency 50/60Hz Output e ciency ≥94%（More than half of the load）...
- Page 7 Split Type DC Charger Model TS-EDH720 TS-EDH680 TS-EDH600 TS-EDH520 Output power 720kW 680kW 600kW 520kW Output voltage 200-1000V Input voltage 400V±10%(Three phase five wire） Input current 3*1152A 3*1034A 3*912A 3*790A Working frequency 50/60Hz Output e ciency ≥94%（More than half of the load） Power factor ≥0.99 Standby wear and tear...
- Page 8 Split Type DC Charger Model TS-EDH480 TS-EDH400 TS-EDH320 TS-EDH240 Output power 480kW 400kW 320kW 240kW Output voltage 200-1000V Input voltage 400V±10%(Three phase five wire） Input current 3*730A 3*608A 3*487A 3*345A 50/60Hz Working frequency ≥94%（More than half of the load） Output e ciency ≥0.99 Power factor ≤0.1%...
- Page 9 Operating Instruction Group Charger Interface 1. Log in using username and password. 2. The interface of the group charger is displayed as follows Host working status DC contactor status Module working status...
- Page 10 Charging Terminal Operating Procedure 1. After powering on, please check if the communication is normal and whether pressing the emergency stop button displays as follows. If the emergency stop status is not shown, it indicates a communication abnormality between the screen and the main control board. Please contact technical support for assistance.
- Page 11 3. To change the charging mode, you need to access the settings interface. The user password for the settings interface is initially set to 'No Password'. 4. The settings accessible to the user include General Settings, Network Settings, OCPP Settings, Device Information, and Records.
- Page 12 5. General Settings are divided into System Settings, User Preferences, Charging Station Configuration, and Charging connector Configuration. System Settings include Brightness Adjustment, Full-Screen Display, and Language Configuration, as shown in the following image. User Preferences include Password Settings and four charging modes (where POS Machine is a non-standard option).
- Page 13 Charging Station Configuration includes Plug-and-Charge. Charging connector Configuration allows you to set the maximum power, maximum voltage, minimum voltage, QR code, whether to enable Base64 encoding for QR code, and the billing price per kWh.
- Page 14 6. OCPP Settings include OCPP Start Button, OCPP Platform ID, Charging Station ID, and whether to enable Basic Authentication. After completing the settings, click the OCPP Start Button. Return to the main interface to check whether there is a cloud icon displayed.
- Page 15 7. Device Information allows you to view the current software version of the device. 8. Record Information allows you to view charging information and logs (which may require contacting technical support or obtaining them through OCPP). Deleting records will remove all charging history.
- Page 16 Charging Mode and Method RFID prepaid charging mode 1. Confirm that the device is in normal 2. Insert the charging gun into the vehicle. standby mode as shown below. 3. Click the start button on the display screen, and the screen will show a swipe signal. Once this interface appears, place the card at the card reader.
- Page 17 Unverified startup charging 1. Ensure that the device has enabled the unauthenticated mode. Setting steps: ① Click the setting button in the upper right corner to enter the setting interface in user mode; ② Click on General Setting; ③ Click on User Preference and then select No Authentication. 2.
- Page 18 3. Insert the charging gun into the vehicle. 4. Click the start button on the display screen. 5. Open the My Teison app and enable the scanning function 6. After scanning the code successfully, wait for the device to connect.
-
Page 19: Installation Instructions
Installation instructions 1. Scope This manual is specifically for Teison DC model products. Before using the product, please read this manual carefully and ensure that the installation and operation are carried out according to the instructions. Please keep the installation instructions in a safe place for maintenance or reference during operation. -
Page 20: Handling Method
If the site conditions permit, it is recommended to leave more space between the machine and the surrounding device or walls for heat dissipation and maintenance to ensure the stable and e cient operation of the charging station. 3. Handling method The charging station can be handled with a forklift. - Page 21 4. Unboxing Step 1: Check if the appearance of the device packaging is intact and if there is any transportation damage. If there is any damage, please notify the carrier immediately. Step 2: Transport the device to the designated location. To prevent the device from tipping over during transportation, when using an electric forklift or a manual forklift for transportation, insert it from the front of the wooden pallet, as shown in the figure below.
-
Page 22: Installation Steps
Step 4: Check equipment integrity. Inspect the appearance of the machine and check for any transport damage. If any da- mage is found, please notify the carrier immediately. Check the model and completeness of the random accessories against the packing list. If any accessory is found to be missing or the model is incorrect, please make a record on-site in a timely manner and contact the company or local o ce immediately. - Page 23 78.5 4-15 Figure 2：Charging Terminal Installation dimension (Size of cement base :500mm*300mm*200mm） Step 3: Drive 4PCS M14*80 expansion bolts into the cement base. Step 4: Use a forklift to move the DC charger from the wooden bracket to the ground, align the mounting holes of the DC charger with the expansion bolts on base, put on 0-12 flat pads and spring pads, then lock.
-
Page 24: Electrical Connection
A Rotating eye bolts or lifting ring bolts B Lifting equipment C Charger Step 6: Connect the corresponding incoming cables to complete the installation. 6. Electrical Connection 6.1 Selection of Incoming Line Group Charger Main cable specification: Power of group charger Cross section area 240KW wdz-yjv22-0.6/1kv-3×120mm²... - Page 26 If it is a hard cable, the cable connector used is the DT model, which is a tubular cable connector. This model is marked by the square of the wire, and the size of the wire nose is selected according to the cross-sectional area of the wire. For example, the wire nose model of a 70mm2 cable should be DT-70.
- Page 27 6.3. Electrical Connection Split Type DC Charger Wiring diagram Terminal Wiring diagram...
- Page 28 As a smart charging expert, Teison products are sold globally and has established distribution points in over 50 countries.Teison prioritizes safety and ensures product quality as a crucial guarantee for safety. We strive to create aesthetically pleasing, high-quality, and safety-friendly charging solutions for users.
- Page 29 Factory history Teison brand established， committed to creating the most reliable charging solution for 2018 global customers. 2019 1. Built R&D team 2. Developed LVD+EMC TUV-certified OCPP full-featured charging station 1. Established a new 4000m production facility 2020 2. Developed full-featured OCPP for AC series 3.
