- Page 1 Teison DC Vision 60-240kW TS-EDC60AA TS-EDC150AA TS-EDC90AA TS-EDC180AA TS-EDC120AA TS-EDC240AA...
- Page 2 Product overview Overall features Parameter Instructions Operating Instructions Installation instructions Teison profile Factory history...
-
Page 3: Product Overview
Product overview Indicator RFID card LCD screen Emergency button LED advertising screen Electricity meter display Charging Connector Output cable Logo OCPP RFID J-son RFID WIFI... -
Page 4: Overall Features
Overall features Multiple standard charging port combinations to choose from CCS2, CHAdeMO, GB/T, and CCS1 can be combined and customized. Diverse power range Multiple power options are available, ranging from 60 KW to 240 KW with customizability. High voltage output The maximum output voltage can reach 1000V, meeting the needs of the vast majority of electric vehicles on the market. - Page 5 Parameter Instructions Specification Model TS-EDC60AA TS-EDC90AA TS-EDC120AA Electrical Properties Input Rating AC400V(±10%) 3ph AC Input Connection 3P+N+PE Rate Input Current 3 92A 3 137A 3 183A AC Input Frequency 50/60Hz Power Factor ≥0.99 E ciency ≥95% Output Voltage Range 200V-1000V Max.Output Current(system)
- Page 6 Specification Model TS-EDC150AA TS-EDC180AA TS-EDC240AA Electrical Properties Input Rating AC400V(±10%) 3ph 3P+N+PE AC Input Connection Rate Input Current 3Ф228A 3Ф274A 3Ф365A AC Input Frequency 50/60Hz ≥0.99 Power Factor E ciency ≥95% Output Voltage Range 200V-1000V 500A Max.Output Current(system) 600A 800A 200A 200A 250A...
- Page 7 Advertising screen specifications Screen size 43” Display area 940.896(H) × 529.254(V) mm Display scale 16: 9 Resolving power 1920 * 1080 Brightness 2000cd/㎡ Display Contrast ratio screen 1200:1 Viewing angle 178(H)*178(V) MP4、AVI、DIVXXVIDVOBDAT、MPGRM、RMVBMKB、MOV、HDMOVM4V、PMP、 Support video formats AVC、FLV5 Support image formatsz JPEG、BMP、GIF、PNG Processor RK3568 Memory...
- Page 8 Operating Instructions Charging Station Instruction 1. After powering on, please check if the communication is normal and whether pressing the emergency stop button displays as follows. If the emergency stop status is not shown, it indicates a communication abnormality between the screen and the main control board. Please contact technical support for assistance.
- Page 9 3. To change the charging mode, you need to access the settings interface. The user password for the settings interface is initially set to 'No Password'. 4. The settings accessible to the user include General Settings, Network Settings, OCPP Settings, Device Information, and Records.
- Page 10 5. General Settings are divided into System Settings, User Preferences, Charging Station Configuration, and Charging connector Configuration. System settings include brightness adjustment, full screen display, language configuration, time zone setting, and screen restart. As shown in the following figure. User preferences include password settings and four charging modes (with POS machines being a non-standard option).
- Page 11 The charging station configuration includes "advertising playback" and "plug and charge" functions (plug and charge function is a customized function). A. The "advertisement playback" function requires: （1）. Activate the local playback button （2）. Import the video that needs to be played （3）.
- Page 12 Charging connector Configuration allows you to set the maximum power, maximum voltage, minimum voltage, QR code, whether to enable Base64 encoding for QR code, and the billing price per kWh. 6. OCPP settings include: charging station ID number, UL1 OCPP platform connection address, UL2 OCPP platform connection address, basic identity verification, and offline recording function.
- Page 13 A.Cloud platform connection supports dual platform simultaneous connection. UL1 has functions such as remote control of charging stations, access to charging logs, charging data, charging status, and remote firmware upgrades; UL2 only supports remote firmware upgrade, access to charging logs, and access to charging status. (UL2 connection platform function, UL1 platform must be turned on to work) B.After completing the settings, click the OCPP Start Button.
- Page 14 8. Charging records: The device stores charging records and logs A. Support querying the charging date, charging time, charging power, and charging amount for each order. B. Support querying charging logs for charging stations and exporting them locally using a USB drive.
- Page 15 Charging Mode and Method RFID prepaid charging mode 1. Confirm that the device is in normal 2. Insert the charging gun into the vehicle. standby mode as shown below. 3. Click the start button on the display screen, and the screen will show a swipe signal. Once this interface appears, place the card at the card reader.
- Page 16 Unverified startup charging 1. Ensure that the device has enabled the unauthenticated mode. Setting steps: ① Click the setting button in the upper right corner to enter the setting interface in user mode; ② Click on General Setting; ③ Click on User Preference and then select No Authentication. 2.
- Page 17 3. Insert the charging gun into the vehicle. 4. Click the start button on the display screen. 5. Open the My Teison app and enable the scanning function 6. After scanning the code successfully, wait for the device to connect.
- Page 18 Advertising screen playback method Local advertising playback uses USB interface for file copying and transfer。 The screen can automatically recognize the content of the USB drive and play it auto- mati- cally. Step 1: Insert the USB drive into the USB interface of the screen, and the screen will auto- matically create a folder inside the USB drive Single player program Step 2: Put the video files to be played into the designated folder...
-
Page 19: Installation Instructions
Installation instructions 1. Scope This manual is specifically for Teison DC model products. Before using the product, please read this manual carefully and ensure that the installation and operation are carried out according to the instructions. Please keep the installation instructions in a safe place for maintenance or reference during operation. -
Page 20: Handling Method
If the site conditions permit, it is recommended to leave more space between the machine and the surrounding device or walls for heat dissipation and maintenance to ensure the stable and e cient operation of the charging station. 3. Handling method The charging station can be handled with a forklift. - Page 21 4. Unboxing Step 1: Check if the appearance of the device packaging is intact and if there is any transportation damage. If there is any damage, please notify the carrier immediately. Step 2: Transport the device to the designated location. To prevent the device from tipping over during transportation, when using an electric forklift or a manual forklift for transportation, insert it from the front of the wooden pallet, as shown in the figure below.
-
Page 22: Installation Steps
Step 4: Check equipment integrity. Inspect the appearance of the machine and check for any transport damage. If any da- mage is found, please notify the carrier immediately. Check the model and completeness of the random accessories against the packing list. If any accessory is found to be missing or the model is incorrect, please make a record on-site in a timely manner and contact the company or local o ce immediately. - Page 23 M12*80 1000 Figure 2 ：Size of cement base Step 3: Drive 4PCS M12*80 expansion bolts into the cement base. Step 4: Use a forklift to move the DC charger from the wooden bracket to the ground, align the mounting holes of the DC charger with the expansion bolts on base, put on 0-12 flat pads and spring pads, then lock.
-
Page 24: Electrical Connection
6. Electrical Connection 6.1 Selection of Incoming Line Common selection of incoming line: Power of charger Cross section area 60KW wdz-yjv22-0.6/1kv-3×35mm² + 2×25mm² 90KW wdz-yjv22-0.6/1kv-3×50mm² + 2×35mm² 120KW wdz-yjv22-0.6/1kv-3×70mm² + 2×50mm² 150/160KW wdz-yjv22-0.6/1kv-3×95mm² + 2×70mm² 180KW wdz-yjv22-0.6/1kv-3×120mm²+2×90mm² 200KW wdz-yjv22-0.6/1kv-3×150mm²+2×120mm² 240KW wdz-yjv22-0.6/1kv-3×185mm²+2×150mm²... - Page 26 If it is a hard cable, the cable connector used is the DT model, which is a tubular cable connector. This model is marked by the square of the wire, and the size of the wire nose is selected according to the cross-sectional area of the wire. For example, the wire nose model of a 70mm2 cable should be DT-70.
- Page 27 6.3. Wiring Steps Step 1: Use the key to unlock the charging station door lock, the lock position is shown in the following figure. Lock Step 2: Open the charging station door panel and thread the mains input cable out of the trench, and connect them respectively to the L1/L2/L3/N phase below the AC circuit breaker.
- Page 28 Step 3: Pull the ground wire out of the incoming cable trench and connect it to the grounding copper busbar. The position of the grounding copperbusbar is shown in the following figure. Make sure that the ground wire is connected to the ground wire in the area, and ensure good grounding, and ensure that all ground wires and grounding devices are reliably grounded to avoid electrification of the cabinet shell.
- Page 29 As a smart charging expert, Teison products are sold globally and has established distribution points in over 50 countries.Teison prioritizes safety and ensures product quality as a crucial guarantee for safety. We strive to create aesthetically pleasing, high-quality, and safety-friendly charging solutions for users.
- Page 30 Factory history Teison brand established， committed to creating the most reliable charging solution for 2018 global customers. 2019 1. Built R&D team 2. Developed LVD+EMC TUV-certified OCPP full-featured charging station 1. Established a new 4000m production facility 2020 2. Developed full-featured OCPP for AC series 3.
