Page 3: Product Overview
Product overview A charger comes with high-integrated smart board and communication function, the wallbox designed meet IP55, can be used indoor and outdoor. It support OCPP 1.6J protocol, and RFID. Owners can collect all data in platform and manage the charger, master all the status of the charger. To realize the real smart charging. -
Page 4: Product Features
Product features Sturdy metal casing Meet IP55 & IK10 standard by lab test 5 inch HD touch screen Easiest user interaction and real-time status view Indicator light Showing real time wallbox status RFID Sensor Identification & payment solution Waterproof port For the best security Emergency button Press to cut off the power immediately... - Page 5 Designed for future smart charging network Timeless and classic design fits in urban space and architecture. Compatible with full smart functions under OCPP 1.6 J-SON Authorization for use on a mobile application or a cloud platform to monitor the charger operation remotely Connecting to the network by 4G,WIFI and Ethernet Independent Access hole, wiring entrance and rail-mounted components for most effective installation and maintenance.
- Page 6 Parameter Specification TS-EVC07-002C-002S TS-EVC11-002C-002S TS-EVC22-002C-002S Model Electrical Properties Voltage 230V AC ±10% 400V AC ±10% 400V AC ±10% Max Output Current 2*32A 2*16A 2*32A Frequency 50/60HZ 50/60HZ 50/60HZ Max Output Power 2*7kW 2*11kW 2*22kW Residual current protection 30mA AC+ DC 6mA Design Emergency Stop Button Display...
-
Page 7: Product Size
Product size 360mm 200mm 460mm 300mm Socket Type 460mm 400mm Base size... -
Page 8: Installation
Installation Incoming Cable Size 2x7kW 2x3x16mm 2x11kW 2x5x10mm 2x22kW 2x5x16mm 1、Begin by constructing a concrete foundation of approximately 600x600mm. Since the EV charger receives the power supply from the bottom, the construction of the concrete foundation needs to include a pre-allocated channel for wiring. Then, install the EV charger on top of the foundation and secure it using expansion screws. - Page 9 L1 N single-phases three-phases 2.Open the rear door of the EV charger, and you will find a cable entry hole at the bottom. The main AC power supply enters from this point. Then, connect the lower end of the circuit breaker. From left to right, they are labeled as L1, L2, L3, N, and PE.
-
Page 10: Charging Instruction
Charging instruction Follow the prompt operation and simply tap on the touch screen. The process can be summarized as follows Touch the screen to enter the Starting page. Select the corresponding connector and connect it to the vehicle car. Scan QR code or swipe card for verification After swipe card, the screen shows the result. - Page 11 APP charge Register your information and login Scan the code when charging Choose charging mode to charge Charging status Check your account and bill information...
- Page 12 Europe, the Middle East, South America, and Southeast Asia to provide users with e cient and fast technical support. As a safety charging expert, Teison insists on putting safety first, and product quality is the essential guarantee of safety. It creates aesthetically designed, high-quality, and safety-friendly charging scenes...
- Page 13 Factory history Teison brand established， committed to creating the most reliable charging solution for 2018 global customers. 1. Built R&D team 2019 2. Developed LVD+EMC TUV-certified OCPP full-featured charging station 1. Established a new 4000m production facility 2020 2. Developed full-featured OCPP for AC series 3.
