- Page 1 ET Series Digital Platform Scales ET-30KAM / ET-60KAL ET-150KAL / ET-300KAX ADA-02/2024...
- Page 2 ET Series Platform Scales Instruction Manual Contents 1. PRECAUTIONS -------------------------------------------------------------------------------------------------------------------- - 1 - 2. PRODUCT DESCRIPTION ------------------------------------------------------------------------------------------------------ - 2 - 2.1 General ----------------------------------------------------------------------------------------------------------------------- - 2 - 2.2 Overall View ----------------------------------------------------------------------------------------------------------------- - 2 - 3. INSTALLATION -------------------------------------------------------------------------------------------------------------------- - 3 - 3.1 Unpacking ------------------------------------------------------------------------------------------------------------------- - 3 - 3.2 Installing the platform ----------------------------------------------------------------------------------------------------- - 3 -...
- Page 3 ET Series Platform Scales Instruction Manual 1. PRECAUTIONS WARNING DISCONNECT ALL POWER TO THIS UNIT BEFORE INSTALLING, CLEANING, OR SERVICING. FAILURE TO DO SO COULD RESULT IN BODILY HARM OR DAMAGE THE UNIT. CAUTION • Permit only qualified persons to service the instrument.
- Page 4 2. PRODUCT DESCRIPTION 2.1 General ➢ The ET series platform scale amplifies signals from a load cell, converts them to digital data and then displays them as a mass value. ➢ It is suitable for general weighing or more specialised applications such as check weighing, counting, motion weighing and accumulation applications.
- Page 5 ET Series Platform Scales Instruction Manual 3. INSTALLATION 3.1 Unpacking When you receive the scale, inspect it to make sure that it is not damaged and that all are parts are included: • Remove the scale from the carton. •...
- Page 6 ET Series Platform Scales Instruction Manual 3.3 Leveling The scale is equipped with a level indicator located on the back of the scale on the base bracket. Use the adjustable leveling feet located on the bottom of the scale until the bubble appears in the center of the indicator.
- Page 7 ET Series Platform Scales Instruction Manual Pull the display cable all the way through the pole so no slack is under the platform. Place the column on the base bracket and ensure the holes to be aligned. Secure the column with the bolts by using a hexagon wrench.
- Page 8 ET Series Platform Scales Instruction Manual Connect the load cell cable into the indicator load cell connector. Load cell connector is located on the rear of the indicator. Tilt display to desired position with adjustment knob. 3.6 Power Connection •...
- Page 9 ET Series Platform Scales Instruction Manual 3.7.2 Battery maintenance • Do not use any other type of power adaptor than the one supplied with the scale. • Rechargeable battery should be charged every three months when not in use. • If the scale is not used for an extended period of time, remove the battery from the battery compartment to avoid leakage.
- Page 10 ET Series Platform Scales Instruction Manual 1) Accumulation switch. Used to enter and show accumulated weights in the memory. 2) Memory recall switch. Show the stored values from the memory. 3) Enter switch. Used to enter the selected menu, sub-menu and setting.
- Page 11 ET Series Platform Scales Instruction Manual 5. OPERATION Initial Start-up Allow the scale to warm up for 15 minutes to stabilize the measured values after switching on. 5.1 Switching on/off • Switch on the indicator by pressing switch. The display will show the scale version and will start after self checking.
- Page 12 ET Series Platform Scales Instruction Manual Clearing tare • To clear the tare value, remove the load from the platform. • Press switch. Zero is displayed, the NET indicator light and tare weight is cleared. 5.4 Select Weighing Unit The default weighing unit is kg, to change weighing units please enter function menu.
- Page 13 ET Series Platform Scales Instruction Manual Check Mode Description The weight is within the limits. The alarm will sound and the OK indicator will be illuminated. INSIDE The weight is below the lower limit. UNDER indicator will be illuminated. The weight exceeds the upper limit. OVER indicator will be illuminated.
- Page 14 ET Series Platform Scales Instruction Manual 5.5.3 Setting limits for target quantity • Press switch to enter counting mode. The display will show 0 • Press and hold switch for 3 seconds in counting mode. The display will show INSIDE.
- Page 15 ET Series Platform Scales Instruction Manual 5.6 Accumulation The scale can be set to accumulate manually by pressing the switch. Before operation the scale should be stable and returned to zero. Accumulation is available only when the weight is more than 20d.
- Page 16 ET Series Platform Scales Instruction Manual 5.7.2 Counting Mode Operation • Press the switch to change the parts quantity. The display will show C00000 • Change the parts quantity as you need by using the switch to move the digits to the right and using the switch to change the value.
- Page 17 ET Series Platform Scales Instruction Manual Auto sleep function This will allow the scale to enter into auto sleep mode for conserving power. Operation: • Press and hold switch for 3 seconds to enter menu setting in the normal weighing mode. The display will show u kg •...
- Page 18 ET Series Platform Scales Instruction Manual 5.11 Internal Counts Checking • Press switch to turn on the scale. • Press and hold switch for 3 seconds during self-checking to check the internal counts. • Press switch to back to normal weighing mode.
- Page 19 ET Series Platform Scales Instruction Manual Select the Sub Menu • Press switch to choose the sub menu block one by one. Return to Weighing Mode • Press switch to exit the menu and return to the weighing mode. 6.2 Function List...
- Page 20 ET Series Platform Scales Instruction Manual 7. CALIBRATION Turn off the indicator. Press and hold switch for 10 seconds and then press the switch together to turn on the scale. Hold the switch while the scale goes through set-up and until it displays d XX 4) Press switch to select the division (1/2/5/10/20/50) as you need.
- Page 21 ET Series Platform Scales Instruction Manual A&D Australasia Pty Ltd Head Office & Warehouse A&D New South Wales Office A&D Victorian Office 32 Dew Street, Unit 4, 14 Abbott Road, Unit 38, 326 Settlement Road Thebarton SA 5031 Seven Hills NSW 2147...
