Sony INZONE H3, YY2961 Manual

Specifications

Headset
Power source:
USB bus power compliant (5 V, 100 mA)
Operating temperature:
0°C to 40°C

Headphones
Type:
Closed, dynamic
Driver unit:
40 mm, dome type (CCAW Voice Coil)
Power handling capacity:
1 500 mW (IEC¹⁾)
Impedance:
36 Ω (1 kHz)
Sensitivity:
92 dB/mW
Frequency response:
10 Hz - 20 000 Hz (JEITA)
Cable:
Approx. 1.2 m, 4-pole mini plug
Mass:
Approx. 299 g without cable

Microphone
Type:
Electret condenser
Directivity:
Uni directional
Effective frequency range:
100 Hz - 8 000 Hz
Included items: Gaming Headset (1)
USB Audio Box (1)

¹⁾ IEC = International Electrotechnical Commission

Design and specifications are subject to change without notice.

Recommended Personal Computer OS version
Windows®: Windows 10 or later Mac: macOS 11 or later

Safety

Do not install the product in a confined space, such as a bookcase or built-in cabinet.
This unit has been tested and found to comply with the limits set out in the EMC regulation using a connection cable shorter than 3 m. High volume may adversely affect your hearing. Do not use the unit while walking, driving, or cycling. Doing so may cause traffic accidents. Do not use in hazardous areas unless the surrounding sound can be heard. The unit is not waterproof. If water or foreign matter enters the unit, it may result in fire or electric shock. If water or foreign matter enters the unit, stop use immediately and consult your nearest Sony dealer. In particular, be careful in the following cases.

When using the unit near a sink or liquid container Be careful that the unit does not fall into a sink or container filled with water.
When using the unit in the rain or snow, or in humid locations
When using the unit while you are perspiring If you touch the unit with wet hands, or put the unit in the pocket of a damp article of clothing, the unit may get wet.

This product (including accessories) has magnet(s) which may interfere with pacemakers, programmable shunt valves for hydrocephalus treatment, or other medical devices. Do not place this product close to persons who use such medical devices. Consult your doctor before using this product if you use any such medical device.

Note about static electricity
If you use the unit when the air is dry, you may experience discomfort due to static electricity accumulated on your body. This is not a malfunction of the unit. You can reduce the effect by wearing clothes made of natural materials that do not easily generate static electricity.

Precautions

The two-dimensional code or the URL on the cover will help you access the help guide that describes useful notes or procedures in details.

Notes on wearing the unit

After use, remove the headphones slowly.
Because the headphones achieve a tight seal over the ears, forcibly pressing them against your ears or quickly pulling them off can result in eardrum damage.
Pressing the headphones against your ears may cause the speaker diaphragm to produce a click sound. This is not a malfunction.

Other notes

Do not apply weight or pressure to the unit for long periods, including when it is stored, as it may cause deformation.
If you experience discomfort while using the unit, stop using it immediately.
Be careful that the boom microphone does not hit your eyes while wearing, removing, and using the unit.
If you have any questions or problems concerning this unit that are not covered in this manual, please consult your nearest Sony dealer.
