Summary of Contents for VIEWEG VC 1100
- Page 1 VIEWEG Dosier- und Mischtechnik User Manual Rotary valve controller VC 1100...
-
Page 2: Table Of Contents
VIEWEG User Manual Rotary Valve Controller VC1100 1. Table of contents 1. Table of contents ......02 2. -
Page 3: Designated Use
If the VC1100 is used for other functions as in this manual described, it could come to personal or material damage. Use the VC1100 controller only to the functions, which are explained in this user manual. VIEWEG GmbH is not responsible for personal or material damages, which happen because of incorrect using and no designated use. -
Page 4: Technical Data
VIEWEG User Manual Rotary Valve Controller VC1100 4. TECHNICAL DATA Measurements : 235 x 210 x 70mm Weight : 1,45kg Powersupply: : 85 – 264V AC 50/60Hz Internal Voltage : 24V DC Voltage Rotary Valve : 0 ... 24V DC (PWM) Dispensetime : 0,01 ... -
Page 5: Shipment
VIEWEG User Manual Rotary Valve Controller VC1100 [Rückseite] Rotary valve Footswitch Power switch Air outlet Air outlet 0-24V DC (PWM) continuous pulsed I/O-Port Fuse 2A T Power inlet Air inlet 0 – 7 bar 5. SHIPMENT: • VC1100 Controller •... -
Page 6: Operation
VIEWEG User Manual Rotary Valve Controller VC1100 • Switch the VC1100 on. The display shows the initialisation and the installed software version. After 5 sec, the display switches automatically to the standard screen and is ready for operation • Check the pressure input (e.g. P-IN: 5.6 bar) in the display to be sure, that the air input pressure is connected. -
Page 7: Operation Keys
VIEWEG User Manual Rotary Valve Controller VC1100 7.3 Operating keys : PROG => switches to the next program PROG SAVE => saves the actual parameters. Press the SAVE key for 2 sec. and select the wanted program with the UP SAVE / DOWN keys and press SAVE again to store the parameters. -
Page 8: Parameter
VIEWEG User Manual Rotary Valve Controller VC1100 8. PARAMETER: • Select mode Pressing the PROG key switches to the next program and to manual mode Manual: In this mode, the dispense time get not saved and the rotary valve dispenses as long as the dispense signal is actived on one of the following possibilities: footswitch / purge key / I/O-start. - Page 9 VIEWEG User Manual Rotary Valve Controller VC1100 • Rotation Direction: The rotation direction of the rotary valve be selected in both directions. The selected direction is shown in the display: CW: Clockwise => spindle moves clockwise CCW: Counter clockwise => spindle moves counter clockwise The rotation direction can be selected in the SERVICE MENU (see chapt.
-
Page 10: Service Menu
VIEWEG User Manual Rotary Valve Controller VC1100 9. SERVICE MENU: (press UP + DOWN keys during initialisation) 9.1 Display: 9.2 Settings: • Language: Pressing UP / DOWN keys switches between english and german language. • Direction: Pressing UP / DOWN keys switches between CW / CWW rotating direction for the rotary... -
Page 11: Electrical Connections
VIEWEG User Manual Rotary Valve Controller VC1100 10. Electrical Connections 10.1 Rotary Valve: type: LEMO conntector female 2-pol: EGG.00.302.CLL pins: Pin 1 (red) 0-24V rotary valve Pin 2 0V (GND) rotary valve mating connector: LEMO connnector 2-pol. FGG.00.302.CLAD35 10.2 Footswitch:... -
Page 12: Wiring Diagrams
VIEWEG User Manual Rotary Valve Controller VC1100 10.4 Wiring Diagrams: Digital Inputs: A digital input is active, if the opto coupler is ON. If the opto coupler is connected to GND, the input is activated: Digital Outputs: if the digital output is active, the opto coupler is electroconductive. -
Page 13: Maintenance And Cleaning
VIEWEG User Manual Rotary Valve Controller VC1100 11. Maintenance and cleaning The VC1100 is maintenance free Repairs should only be done by the manufacturer. Clean the VC1100 controller only with a clean, smooth and dry cloth. Do not use disolvent material to clean the VC1100 controller. The foil at the front- or backplate or the housing paintings can be destroyed. -
Page 14: Declaration Of Conformity
We, as manufacturer declare under our sole responsibility that the following pro- duct to which this declaration relates is in conformity with the follwoing EG / EC directives: Rotary valve controller Product: VC 1100 Series Type: Manufacturer: VIEWEG Dosier- und Mischtechnik Gewerbepark 13... - Page 15 VIEWEG Vieweg GmbH Dosier- und Mischtechnik Gewerbepark 13 85402 Kranzberg Tel. +49 (0) 81 66 / 67 84 - 0 Fax +49 (0) 81 66 / 67 84 - 20 info@dosieren.de www.dosieren.de...
