Summary of Contents for Asko DWC6432BIXXLSU
- Page 1 USER MANUAL DWC6432BIXXLSU Dishwasher Read all instructions before using the appliance.
-
Page 2: Table Of Contents
The best drying results ........ Service after expiration of limited warranty ... Unloading the dishwasher ......Number of cycles ........Program chart ..........Technical information ........ ASKO Connect Pro & ConnectLife ... Technical data ..........ASKO Connect Pro ........Electrical connection ........ -
Page 3: Your Dishwasher
Install the dishwasher; see the chapter Installation instructions. Then open the door and press "Welcome to your new ASKO dishwasher. This is a first time setup." is shown on the display the first time the dishwasher is switched on. It is important that you choose the right settings to ensure good dishwashing results. -
Page 4: Important Safety Instructions
Important safety instructions SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE WARNING! When using your dishwasher, follow basic precautions, including the following: • Read all instructions before using the dishwasher. • Use the dishwasher only for its intended purpose. • Use only detergents or rinse agents recommended for use in a dishwasher and keep them out of the reach of children. -
Page 5: Child Safety
Important safety instructions WARNING! Only Sanitize NSF cycles have been designed to meet the requirements of NSF/ANSI 184 for soil removal and sanitization efficacy. There is no assurance, either directly or indirectly, that all cycles on a certified machine have passed the sanitization performance test. WARNING! PROPOSITION 65 FOR CALIFORNIA RESIDENTS Cancer and Reproductive Harm... -
Page 6: Packing Material
Important safety instructions Center. (To avoid water leakage outside the dishwasher, do not remove the plug from the power outlet until the water supply valve has been turned off!) Packing material The outer packaging protects the product during transport. The packaging material is recyclable. Separate the different packaging materials to help reduce raw material use and waste. -
Page 7: Before Washing For The First Time
5°dH (9°fH / 6°eH / 0.9 mmol/l / 5.9 gr/gal). Basic settings Open the door. Press "Welcome to your new ASKO dishwasher. This is a first time setup." is shown on the display. It is important that you choose the right settings to ensure good dishwashing results. - Page 8 Before washing for the first time Select setting with or . Confirm selected setting with Settings Language Select the language to be shown on the display. Power 15 A/20 A This dishwasher has been designed to be able to be connected to an electrical supply network with fuses for 15 A Default: 20 A or 20 A.
- Page 9 Before washing for the first time Settings QR code (it can be found on the appliance’s serial number plate). • Select Add device. Remove all devices Select Remove all devices to remove all connected devices/users. WiFi factory reset Select WiFi factory reset to restore the default factory settings.
-
Page 10: Add Rinse Aid
Before washing for the first time Add rinse aid Add rinse aid to the container for rinse aid (if the dishwasher has not been connected to a system for the automatic dosing of rinse aid). Fill up the rinse aid compartment with rinse aid if you have selected Rinse aid 1 - 5. Press to open Press to close 1. -
Page 11: Automatic Dosing
Before washing for the first time WARNING! In order to avoid rust stains, a dishwashing program must be started immediately after adding salt. Never pour dishwasher detergent into the salt compartment. This destroys the water softener! Automatic dosing The dishwasher can be connected to one or more systems for the automatic dosing of commercial detergent and rinse aid, which simplifies everyday operation and reduces the risk of overdosing. -
Page 12: Greener Dishwashing
Greener dishwashing Save energy and water When using a dishwasher in a residential setting, less energy and water are generally used compared to washing the dishes by hand. Do not rinse under running water Do not rinse the dishes under running water as this will lead to increased energy and water consumption. -
Page 13: Loading The Dishwasher
Loading the dishwasher Fragile dishes Some cookware is not dishwasher safe. This can be for several reasons. Some materials cannot withstand high temperatures, others can be damaged by dishwasher detergent. Use caution with, for example, handmade items, China, crystal/glassware, silver, copper, tin, aluminum, wood, and plastic. -
Page 14: Top Cutlery Tray
Loading the dishwasher The basket appearance may differ depending on the configuration. Top cutlery tray The top cutlery tray accommodates cutlery, ladles, whisks, and other utensils. Avoid placing tall objects in the top cutlery tray. They can block the top spray arm. Raising the top cutlery tray 1. -
Page 15: Upper Basket
Loading the dishwasher Upper basket Place glasses, cups, bowls, side plates, and saucers in the upper basket. Place all soiled surfaces face down. Place wine glasses on the wine glass shelf. Place knives in the knife stand on the right. Knife stand Raising the upper basket 1. -
Page 16: Lower Basket
Loading the dishwasher Lower basket Place plates, side plates, serving dishes, pots, and cutlery (in the cutlery basket) in the lower basket. Place pots and pans in the rear of the lower basket to best utilize dishwashing performance from the two spray nozzles. Adjustable plate supports The adjustable plate supports can be adjusted to suit the dishes. -
Page 17: Cutlery Basket
Loading the dishwasher Vase and bottle holder Install the vase and bottle holder above the left spray nozzle. (Found in the enclosed plastic bag.) Washing large plates You can adjust the lower basket for plates with a diameter of 9 3/4-15 1/3" (25-39 cm) by moving the adjustable plate supports and their fixtures to increase the distance between the tine rows. -
Page 18: Typical Load
Loading the dishwasher Typical load Recommended for daily, regular, or typical use. Upper basket Lower basket... -
Page 19: Using The Dishwasher
Using the dishwasher Add detergent Add detergent to the detergent compartment (if the dishwasher has not been connected to a system for the automatic dosing of commercial detergent). Follow the instructions on the detergent packaging. This dishwasher is fitted with a water softener, so use detergent and rinse aid doses suitable for soft water. -
Page 20: On/Standby Mode
Using the dishwasher Select a pre-selected program Start/Stop On/Standby mode Navigation buttons for selecting from more programs On/Standby mode Open the door and press . Also turn on the water supply valve if it is turned off. Select program To select a program, press , or . You can also select a program by pressing or until the desired program is shown on the display. - Page 21 Using the dishwasher Sanitize NSF A hygiene program that ensures good dishwashing results for dishes with dried-on food residue. The temperature of the main wash is 158 °F / 70 °C. The final rinse is 158 °F / 70 °C. The program meets the requirements of the NSF/ANSI 184 standard.
-
Page 22: Start/Stop
If the dishwasher is not started or the door is not closed within 2 minutes of the last time the control panel was pressed, the machine switches off. To remote start the dishwasher, see the chapter ASKO Connect Pro & ConnectLife. Cancel or changing a program If you want to change program after starting the dishwasher, open the door then press and hold for three seconds. -
Page 23: Power Failure
Using the dishwasher Power failure If the dishwasher is turned off due to a power failure when a dishwashing program is running, the program continues when power is restored. If the power is lost during drying, the program is interrupted. If the dishwashing program was remote started and has not ended, the program will continue once the power is restored. -
Page 24: Unloading The Dishwasher
Using the dishwasher • Activate the Automatic door opening option. • Activate the Automatic door opening setting. • Allow the dishes to cool before unloading the dishwasher. Unloading the dishwasher Hot porcelain is more fragile. Leave the dishes to cool in the dishwasher before unloading them. Unload the lower basket first to avoid any water drops from the upper basket falling onto the dishes in the lower basket. -
Page 25: Program Chart
Program chart... -
Page 26: Asko Connect Pro & Connectlife
ASKO Connect Pro is a web-based platform that enables you to organize, manage and monitor all your professional ASKO appliances regardless of where they are installed. Once you have connected a professional appliance in the ConnectLife app, a link to ASKO Connect Pro is shown. For more information, please see https://us.asko.com/professional. - Page 27 ASKO Connect Pro & ConnectLife NOTE! The dishwasher can always be used without the app. When the dishwasher's control panel is pressed, commands from the ConnectLife app are blocked for 10 seconds. If you have any questions, please visit us at www.connectlife.io.
-
Page 28: Settings
Settings Press To open the Settings, press Select setting Confirm current setting Settings Alternatives Lock On/Off To prevent children or persons with reduced mental capabilities from starting the dishwasher, the Lock setting can be activated. To temporarily deactivate or activate the Lock setting, press and hold for three seconds. - Page 29 Settings Settings Alternatives Auto dose Detergent: Activate this setting if you want Off, 3-8 tsp to connect an automatic dosing system for detergent. This dishwasher is fitted with a water softener, so use detergent and rinse aid doses suitable for soft water.
- Page 30 Settings To open the Advanced settings, press until Advanced settings is shown on the display and confirm your selection with Press: , , , Advanced settings Alternatives Language You can choose the language used for the display. WiFi The current WiFi status is shown on the display. WiFi status Connect the dishwasher to your wireless network to be able to remote control the dishwasher using the ConnectLife app.
- Page 31 Settings Advanced settings Alternatives Display Brightness 1/2/3/4 For adjusting the brightness of the display. Notification volume 0/1/2/3 The buzzer indicates when a dishwashing program has ended. Error messages are always indicated by a loud buzzer. Rinse aid 0/1/2/3/4/5 Setting for rinse aid dosage. The rinse aid dispenser can be adjusted between 0 (Off) and 5 (High dosage).
- Page 32 Settings Advanced settings Alternatives Power 15 A/20 A This dishwasher has been designed to be able to be connected to an electrical supply network with fuses for 15 A or 20 A. The water in the dishwasher will be heated more quickly, and the dishwashing program will run more quickly, if you select 20 A.
-
Page 33: Care And Maintenance Instructions
Care and maintenance instructions Add rinse aid When the rinse aid needs topping up, the symbol lights up on the display. See the chapter Before washing for the first time. Add salt When the salt needs topping up, the symbol lights on the display. (You can run 3 programs before the compartment is completely empty.) See the chapter Before washing for the first time. - Page 34 Care and maintenance instructions Fine filter Debris that collects on the fine filter is automatically rinsed away during each wash. Clean the fine filter when necessary. It should be cleaned at regular intervals depending on how often the dishwasher is used. Fine filter 1.
-
Page 35: Cleaning The Spray Arms
Care and maintenance instructions Cleaning the spray arms Holes and bearings can become blocked. Remove debris using a needle or similar item. The spray arms have holes on the bottom. Spray arms can be removed for cleaning. Remember to put them firmly back into place afterward. Top spray arm •... -
Page 36: Clean The Outside Of The Dishwasher
Care and maintenance instructions Clean the outside of the dishwasher Door and door seal Open the door. Clean the sides of the door and the door seal regularly with a slightly damp cloth. Clean the door seal at the lower front edge of the dishwasher with a cleaning brush. Control panel Keep the control panel clean. -
Page 37: Winter Storage/Transport
Care and maintenance instructions 5. Turn the pump wheel located behind the drain pump stop by hand. Carefully remove any sharp items, such as glass. 6. Reinstall the drain pump stop along with the fine and coarse filters. 7. Plug the machine in again. Drain pump stop NOTE! Do not forget to reinstall the drain pump stop. -
Page 38: Troubleshooting
Troubleshooting Error messages Action Overfilling water 1 Unblocking the drain pump. See the chapter Care and maintenance instructions. If the problem persists, contact your nearest Customer Care Center. Water outlet fault See "Water remains in the dishwasher above the filters" under "Problem"... -
Page 39: General
Troubleshooting General Problem Possible causes Action The control panel does not react You have pressed the control Wait a moment then try again. when pressed. panel too soon after opening the door. Lock is activated. See the chapter Important safety instructions. - Page 40 Troubleshooting Problem Possible causes Action The dishwasher does not start. has not been pressed. Press until the display shows "Program started, Close door within 4 sec". The door is not closed properly Close the door within four or was not closed immediately seconds, otherwise the dishwasher will not start.
- Page 41 Troubleshooting Problem Possible causes Action The dishes are not clean. The spray arms are not rotating Check that the dishes are not freely. blocking the spray arms. Spray arm holes or bearings Clean the spray arms. See the blocked. chapter Care and maintenance instructions.
- Page 42 Troubleshooting Problem Possible causes Action Spots or films on the dishes. Incorrect rinse aid dosage See the chapter Settings. setting. The TAB setting is activated and Switch all-in-one detergents or all-in-one detergent with deactivate the TAB setting and insufficient drying effect is being fill up with salt and separate used.
- Page 43 Troubleshooting Problem Possible causes Action "Program paused" is shown on The dishwasher door has been If you want the dishwashing the display. opened while a program is in program to continue, press progress. and close the door within four seconds. If you want to cancel the dishwashing program, press and hold...
- Page 44 Troubleshooting Problem Possible causes Action Water remains in the dishwasher The filters are clogged. Clean the coarse and fine filters. above the filters. The filters are not fitted correctly. Check that the filters are fitted correctly. See the chapter Care and maintenance instructions.
- Page 45 Troubleshooting Problem Possible causes Action The dishes are not dry enough. The Automatic door opening Activate the Automatic door setting has not been activated. opening setting. The dishwasher is not fully Fully load the dishwasher. loaded. Rinse aid needs filling up or Fill up the rinse aid compartment dosage is set too low.
-
Page 46: Wifi
Connect the dishwasher to your connected to your wireless wireless network. See the symbol does not appear on network. chapter ASKO Connect Pro & the display. ConnectLife. WiFi connection is deactivated. Activate WiFi connection. See WiFi connection On/Off in the chapter Settings. - Page 47 Troubleshooting Problem Possible causes Action Software update failed. The network connection was lost Make sure that the power supply or the dishwasher lost power is not interrupted and that the due to a power failure. network connection is stable before trying again. If the problem persists, contact your nearest Customer Care Center.
-
Page 48: Installation Instructions
Installation instructions *Remove lock nuts for an installed height of 34 3/16 - 34 5/16'' (869-871 mm) . If European widths of 23 5/8'' (600 mm) is required, remove the trim kit. Connection to an automatic dosing system Inches (mm) Nominal dimensions. Actual measurements may vary. Important safety instructions •... -
Page 49: Transport Protection For The Door
Installation instructions NOTE! A integrated door panel must not be fitted to the dishwasher. Transport protection for the door Do not forget to remove the transport protection for the door when unpacking the dishwasher. Trim kit The dishwasher is equipped with a trim kit to fit the 24'' (609 mm) cutout standard. If a European width of 23 5/8'' (600 mm) is required, remove the trim kit. -
Page 50: Placing The Dishwasher
Installation instructions Placing the dishwasher The dishwasher is intended to be built-in under a countertop. Make sure that the edges of the hole are even and will not damage the drainage and inlet hoses or the supply cord. Inches (mm) The electrical and water supplies should enter through the area... -
Page 51: Connection To An Automatic Dosing System
Installation instructions NOTE! The surface to which the protective film is fitted must be clean and dry. Connection to an automatic dosing system The dishwasher can be connected to one or more systems for the automatic dosing of commercial detergent and rinse aid, which simplifies everyday operation and reduces the risk of overdosing. Connection to a system for automated dosage must be performed by the supplier of the system or by somebody with an equivalent professional qualification. - Page 52 Installation instructions 2. Connect the external cables for detergent to the auto dose connector. A Ground connection B Connection for level sensor C Connection for impulse of detergent (120 V) 3. Connect the external cables for rinse aid to the auto dose connector. A Ground connection B Connection for level sensor C Connection for impulse of rinse aid...
- Page 53 Installation instructions 2. Attach the nipple and connect the hose for detergent. Connection for detergent (hose diameter 1/4'' (6 mm)). 3. Attach the nipple and connect the hose for rinse aid. Connection for rinse aid (hose diameter 3/16'' (4 mm)). • Activate Auto dose. See the chapter Settings. •...
-
Page 54: Adjust The Height And Slide The Dishwasher Into Place
Installation instructions Adjust the height and slide the dishwasher into place 1. Start by measuring the height from the floor to the bottom edge of the countertop. 2. Measure the height from the floor to the top edge of the dishwasher. 3. -
Page 55: Drain Connection
Installation instructions • Check that the machine is installed such that the door opens freely, otherwise door lock functionality may be disrupted. 7. Make any final adjustments to the feet and tighten the lock nuts on the front feet. Drain connection This dishwasher is suitable for installing in a raised recess (to obtain an ergonomic working height). -
Page 56: Connection To Water Supply
Installation instructions Attach the drain hose with a hose clamp. Ensure that the drain hose has no kinks. No external air gap is necessary, as the dishwasher is already equipped with an internal air gap. Connection to water supply The dishwasher can be connected to hot (max. 160 °F (70 °C)) and/or cold water. The dishwasher adjusts automatically to the connected water in order to achieve the best dishwashing result. -
Page 57: Electrical Connection
Replacing the power cord All work on the electrical connection must be performed by a qualified service technician. If replacing the power cord, use only original ASKO replacement parts. For technical data, see the wiring and conversion diagram supplied with the machine. -
Page 58: Fastening The Dishwasher
Installation instructions Fastening the dishwasher After fastening the dishwasher, check that the front feet still touch the floor. Screw into the countertop Alternatively, the dishwasher can be screwed into the underside of the countertop. -
Page 59: Dishwasher Toe Kick
Installation instructions Dishwasher toe kick The dishwasher is supplied with a toe kick. Fit the sound insulation (only certain models) Fit the toe kick... -
Page 60: Service And Warranty
2. Service calls to correct the installation of the ASKO Product, to instruct you on how to use the ASKO Product, to replace or repair house fuses, or to correct house wiring or plumbing. -
Page 61: Disclaimer
THAN ACTUAL DAMAGES AND IN NO EVENT FOR DAMAGES IN EXCESS OF THE PRICE PAID FOR THE ASKO PRODUCT AS TO WHICH A CLAIM IS MADE. Some jurisdictions do not allow the exclusion or limitation of incidental, consequential or other damages, so these limitations and exclusions may not apply to you. -
Page 62: Technical Information
1.5 kW All work on the electrical connection must be performed by a qualified service technician. If replacing the power cord, use only original ASKO replacement parts. For technical data, see the wiring and conversion diagram supplied with the machine. - Page 63 US.ASKO.COM • CA.ASKO.COM • ASKO.COM/MX 940818 Translation of the original instructions. We reserve the right to make changes.
