USER MANUAL
DWC67422BIW
Dishwasher
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DWC67422BIW and is the answer not in the manual?

Questions and answers

Related Manuals for Asko DWC67422BIW

Summary of Contents for Asko DWC67422BIW

  • Page 1 USER MANUAL DWC67422BIW Dishwasher...

  • Page 2: Table Of Contents

    Number of cycles ........Unloading the dishwasher ......Technical data and energy labelling ..Program chart ..........Technical data ..........ASKO Connect Pro & ConnectLife ... Information for consumers ......ASKO Connect Pro ........Information for test institute ......ConnectLife ..........

  • Page 3: Your Dishwasher

    Install the dishwasher, see the chapter Installation. Then open the door and press "Welcome to your new ASKO dishwasher. This is a first time setup." is shown on the display the first time the dishwasher is switched on. It is important that you choose the right settings to ensure good dishwashing results.

  • Page 4: Safety Instructions

    Safety instructions Read the user manual and keep it in a safe place! Number of standard place settings: 13 Never use the dishwasher for any purpose other than that specified in these operating instructions. Do not load the dishwasher door or dishwasher baskets with anything other than dishes.

  • Page 5: Sani Lock

    Safety instructions WARNING! Knives and other pointed items must be placed with the points down in the cutlery basket or horizontally in other baskets. WARNING! Children must be supervised – dishwasher detergent is corrosive! Sani lock To prevent the risk of burn injuries, the door cannot be opened while the dishwasher temperature exceeds 65 °C.

  • Page 6: Symbols On The Appliance

    Safety instructions Contact your local authority for information about where and how your dishwasher should be correctly recycled. Symbols on the appliance Read the user manual. Recycle as electrical waste. Approved in accordance with the relevant EU directives. Approved in accordance with the relevant UK legal requirements.

  • Page 7: Before Washing For The First Time

    Before washing for the first time Water hardness In order to achieve good dishwashing results, the dishwasher needs soft water (water with low mineral content). Hard water leaves a white coating on dishes and the dishwasher. Checking water hardness Water hardness is specified using German degrees of water hardness (°dH), French degrees of water hardness (°fH), English degrees of water hardness (°eH) or millimoles per litre (mmol/l).

  • Page 8: Basic Settings

    Basic settings Open the door. Press "Welcome to your new ASKO dishwasher. This is a first time setup." is shown on the display. It is important that you choose the right settings to ensure good dishwashing results. Select setting with or .
  • Page 9 Before washing for the first time Settings plate of the appliance; you can also enter the AUID/SN number manually). Select Connection setup. Add device Pair more devices/users with the dishwasher. In the ConnectLife application, go to the »Add devices« menu and select the appropriate type of device. Then scan the QR code (it can be found on the serial number plate of the appliance;...

  • Page 10: Top Up Rinse Aid

    Before washing for the first time Top up rinse aid Top up the rinse aid compartment with rinse aid if you have selected Rinse aid 1 - 5. Press to open Press to close 1. Open the rinse aid compartment lid. 2.

  • Page 11: Greener Dishwashing

    Greener dishwashing Save energy and water When using a dishwasher in a residential setting, less energy and water are generally used compared to washing the dishes by hand. Do not rinse under running water Do not rinse the dishes under running water as this will lead to increased energy and water consumption.

  • Page 12: Loading The Dishwasher

    Loading the dishwasher Fragile dishes Some cookware is not dishwasher safe. This can be for several reasons. Some materials cannot withstand high heat, others can be damaged by dishwasher detergent. Exercise caution with, for example, handmade items, fragile decoration, crystal/glassware, silver, copper, tin, aluminium, wood and plastic.

  • Page 13: Upper Basket

    Loading the dishwasher The appearance of the baskets may differ depending on the dishwasher setup. Upper basket Place glasses, cups, bowls, side plates and saucers in the upper basket. All dirty surfaces should face inwards and downwards! Wine glasses are placed on the wine glass shelf and knives are placed in the knife stand on the right.

  • Page 14: Lower Basket

    Loading the dishwasher Lower basket Place plates, side plates, serving dishes, pots and cutlery (in the cutlery basket) in the lower basket. Accessory Buy a wine glass shelf with space for six tall wine glasses. The wine glass shelf is designed to ensure optimal washing and drying results with tall wine glasses.

  • Page 15: Cutlery Basket

    Loading the dishwasher Cutlery basket Place cutlery with the handles facing down, except for knives, and spread them out as much as possible. Ensure that spoons do not stack inside each other. The cutlery basket is best placed in the middle at the front of the lower basket to best utilise dishwashing performance from the unique spray zone intended for the cutlery basket.
  • Page 16 Loading the dishwasher Accessory Buy a mini cutlery basket. The extra cutlery basket is flexible and can be dismantled and attached to the lower basket or the large cutlery basket to make an extra large cutlery basket. This accessory is available where you bought the dishwasher.

  • Page 17: Using The Dishwasher

    Using the dishwasher Add detergent Follow the instructions on the detergent packaging. This dishwasher is fitted with a water softener, so use detergent and rinse aid doses suitable for soft water. Choose a detergent intended for professional dishwashers to ensure optimal dishwashing results. Too much detergent can result in less effective dishwashing and also entails greater environmental impact.

  • Page 18: On/Off

    Using the dishwasher Select a pre-selected program Start/Stop On/Off Navigation buttons for selecting from more programs On/Off Open the door and press . Also turn on the water tap if it is turned off. Select program Eco is always pre-selected. To select another program, press , or . You can also select a program by pressing until the desired program is shown on the display.

  • Page 19: Start/Stop

    If the dishwasher is not started or the door is not closed within 2 minutes of the last time the control panel was pressed, the machine switches off. To remote start the dishwasher, see the chapter ASKO Connect Pro & ConnectLife. Stopping or changing a program If you want to change program after starting the dishwasher, open the door then press and hold for three seconds.

  • Page 20: If You Want To Load More Dishes

    Using the dishwasher This may differ somewhat from time to time depending on the temperature of the water supply, the amount of dishes, the ambient temperature and other factors. During the first run of each program, the remaining time displayed can be slightly misleading, as the dishwasher is estimating the time.

  • Page 21: Once The Program Has Finished

    Using the dishwasher Once the program has finished Once the program has finished, "Program done" appears on the display. At the end of the program one short signal will sound. Chapter Settings describes how to change this function. The dishwasher switches off automatically after the program ends. Shut off the water tap after each use (if required by your insurance company).

  • Page 22: Program Chart

    Program chart...

  • Page 23: Asko Connect Pro & Connectlife

    ASKO Connect Pro is a web-based platform that enables you to organise, manage and monitor all your professional ASKO appliances regardless of where they are installed. Once you have connected a professional appliance in the ConnectLife app, a link to ASKO Connect Pro is shown. For more information, please see https://professional.asko.com/.
  • Page 24 ASKO Connect Pro & ConnectLife NOTE! The dishwasher can always be used without the app. When the dishwasher's control panel is pressed, commands from the ConnectLife app are blocked for 10 seconds. If you have any questions, please visit us at www.connectlife.io.

  • Page 25: Settings

    Settings Press To open the Settings, press until Settings is shown on the display and confirm your selection with Select setting Confirm current setting Settings Alternatives Lock On/Off To prevent children or persons with reduced mental capabilities from starting the dishwasher, the Lock setting can be activated.
  • Page 26 Settings Settings Alternatives On/Off Activate this setting when using an all-in-one detergent that (All-in-one detergent) contains rinse aid. This setting reduces the rinse aid dosage and affects how often the dishwasher's built-in softener is regenerated. Feedback volume 0/1/2/3 A beep confirms that the control panel has been pressed.
  • Page 27 Settings To open the Advanced Settings, press until Advanced Settings is shown on the display and confirm your selection with Press: , , , Advanced Settings Alternatives Language You can choose the language used for the display. WiFi The current WiFi status is shown on the display. WiFi status Connect the dishwasher to your wireless network to be able to remote control the dishwasher using the ConnectLife app.
  • Page 28 Settings Advanced Settings Alternatives Display Logotype On/Off Setting to hide the logo shown on the display. Display Brightness 1/2/3/4 For adjusting the brightness of the display. Notification volume 0/1/2/3 The buzzer indicates when a dishwashing program has ended. Error messages are always indicated by a loud buzzer.
  • Page 29 Settings Advanced Settings Alternatives Interior light at power off On/Off Select whether the interior light is to be switched on when the dishwasher is turned off and the door is opened. (If is turned on, the interior light is always switched on when the door is opened.) Failure readout...

  • Page 30: Care And Cleaning

    Care and cleaning Top up rinse aid When the rinse aid needs topping up, the symbol lights on the display. See the chapter Before washing for the first time. Top up salt When the salt needs topping up, the symbol lights on the display. See the chapter Before washing for the first time.
  • Page 31 Care and cleaning Fine filter Debris that collects on the fine filter is automatically rinsed away during each wash. Clean the fine filter when necessary. It should be cleaned at regular intervals depending on how often the dishwasher is used. Fine filter 1.

  • Page 32: Cleaning The Spray Arms

    Care and cleaning Cleaning the spray arms Holes and bearings can sometimes become blocked. Remove any debris using a pin or the like. The spray arms also have holes underneath. To facilitate cleaning you can remove the spray arms. Remember to fit them firmly back into place afterwards.

  • Page 33: Clean The Outside Of The Dishwasher

    Care and cleaning Clean the outside of the dishwasher Door and door seal Open the door. Clean the sides of the door and the door seal regularly with a slightly damp cloth. Clean the door seal at the lower front edge of the dishwasher with a washing-up brush. Control panel Keep the control panel clean.

  • Page 34: Winter Storage/Transport

    Care and cleaning Drainage pump stop NOTE! Do not forget to refit the drainage pump stop. Unblocking the inlet hose filter If the water supply contains small particles, the outer filter on the inlet hose may become blocked, which results in the Water inlet fault error message. 1.

  • Page 35: Troubleshooting

    Troubleshooting Error messages Action Overfilling water 1 Unblocking the drainage pump. See the chapter Care and cleaning. If the problem persists, contact your nearest service centre. Water outlet fault See "Water remains in the dishwasher" under "Problem" in the table below. If the problem persists, contact your nearest service centre.

  • Page 36: General

    Troubleshooting General Problem Possible causes Action The control panel does not react You have pressed the control Wait a moment then try again. when pressed. panel too soon after opening the door. Lock is activated. See the chapter Safety instructions. Dirt on the control panel.
  • Page 37 Troubleshooting Problem Possible causes Action The dishwasher does not start. has not been pressed. Press until the display shows "Program started, close door". The door is not properly closed. Check. Salt compartment empty. Top up with salt. See the chapter Care and cleaning. The dishwasher has been Close the door and wait.
  • Page 38 Troubleshooting Problem Possible causes Action The dishes are not clean. The spray arms are not rotating Check that the dishes are not freely. blocking the spray arms. Spray arm holes or bearings Clean the spray arms. See the blocked. chapter Care and cleaning. Unsuitable dishwashing Select a program with a high program.
  • Page 39 Troubleshooting Problem Possible causes Action Spots or films on the dishes. Incorrect rinse aid dosage See the chapter Settings. setting. The setting TAB is activated and Switch all-in-one detergents or all-in-one detergent with deactivate the setting TAB and insufficient drying effect is being top up with salt and separate used.
  • Page 40 Troubleshooting Problem Possible causes Action "Block start when softener is Salt compartment empty. Top up with salt. See the empty" is shown on the display. chapter Care and cleaning. (The setting to prevent a dishwashing program from starting when the salt compartment is empty can be deactivated.
  • Page 41 Troubleshooting Problem Possible causes Action The dishes are not dry enough. The Automatic door opening Activate the Automatic door option is not activated. opening option. The dishwasher is not fully Fully load the dishwasher. loaded. Rinse aid needs topping up or Top up with rinse aid or increase dosage is set too low.

  • Page 42: Wifi

    Connect the dishwasher to your connected to your wireless wireless network. See the symbol does not appear on network. chapter ASKO Connect Pro & the display. ConnectLife. WiFi connection is deactivated. Activate WiFi connection. See WiFi connection On/Off in the chapter Settings.

  • Page 43: Installation

    Installation [mm] *Remove the locking nuts when installing in a recess measuring 820-821 mm. Nominal dimensions. Actual measurements may vary. Safety instructions Connections to electricity, water and drainage must be performed by a qualified professional. Always follow applicable regulations for water, drainage and electricity. Take care during installation! Wear protective gloves! There must always be two people! Place a drip tray on the floor beneath the dishwasher to prevent damage from any water leaks.

  • Page 44: Transport Protection For The Door

    Installation Transport protection for the door Do not forget to remove the transport protection for the door when unpacking the dishwasher. Placing the dishwasher The dishwasher is intended to be built-in under a worktop. The built-in measurements are shown in the illustration.

  • Page 45: Adjust The Height And Slide The Dishwasher Into Place

    Installation NOTE! The surface to which the protective film is affixed must be clean and dry. Adjust the height and slide the dishwasher into place 1. Start by measuring the height from the floor to the bottom edge of the worktop. 2.

  • Page 46: Drainage Connection

    Installation Check that the drainage hose has no kinks or sharp bends. Also check that there is nothing that can damage the hoses. Check that the machine is installed such that the door opens freely, otherwise door lock functionality may be disrupted. 7.

  • Page 47: Connection To Water Supply

    Installation Max. 950 mm The drainage hose can also be connected to a connection nipple on the sink unit's water trap. The connection nipple must have an internal diameter of at least 14 mm. The drainage hose may be extended by a maximum of 2.5 m (the total length of the drainage hose must not exceed 4.5 m).

  • Page 48: Screwing The Dishwasher Into Place

    Installation The electric wall socket must be placed outside of the installation area to be easily accessible after installing the dishwasher. Do not use an extension cord! The dishwasher must be connected to residual current devices as per the relevant safety regulations. Screwing the dishwasher into place After fastening the machine, check that the front feet still touch the floor.

  • Page 49: Dishwasher Toe Kick

    Installation Dishwasher toe kick The dishwasher is supplied with a toe kick. Fit the sound insulation (only certain models) Fit the toe kick...

  • Page 50: Service

    Read the chapter Troubleshooting before contacting the service centre. If you have encountered a problem that you cannot resolve, please contact your nearest service centre for professional help, see www.asko.com. Our website also has information about spare part availability and what you can repair yourself.

  • Page 51: Technical Data And Energy Labelling

    In accordance with the EN 60436 standard. Information for consumers Information about your appliance can be found at https://global.asko.com/energy-label. You can also find information in the EU Product Registration database for Energy Labelling, EPREL. Scan the QR code on the energy label supplied with the dishwasher (or go to https://eprel.ec.europa.eu and search for the model name).
  • Page 52 WWW.ASKO.COM 937685 We reserve the right to make changes.
