www.pollardbros.com
Includes:
• (2) Box Encaps • (1) Formed Shelf • (2) 9" Braces
8
x
1/4" x 5/8" Hex Head
Machine Screw
4
x
3/8" x 3/4" Hex Head
Machine Screw
Steps:
1
Stand Box Endcaps on end about 8' apart and
face as shown.
Tools Needed:
wrench
216 - Riser Shelf
Assembly Instructions
8
x
1/4" Hex Nut
4
x
3/8" Hex Nut
8
x
1/4" Lock Washer
4
x
3/8" Lock Washer
Advertisement
Related Manuals for Pollard 216
Summary of Contents for Pollard 216
- Page 1 216 - Riser Shelf Assembly Instructions www.pollardbros.com Tools Needed: wrench Includes: • (2) Box Encaps • (1) Formed Shelf • (2) 9” Braces 1/4” x 5/8” Hex Head 1/4” Hex Nut 1/4” Lock Washer Machine Screw 3/8” x 3/4” Hex Head 3/8”...
- Page 2 Screws, ⁄ “ Lock Washers, and ⁄ “ Hex Nuts. After top is in place, make sure bench is square and then, tighten all bolts, starting with the stringer and tie rods. Pollard Brothers Manufacturing 5504 N. Northwest Highway Chicago IL 60630 (773)763-6868 (773)763-4466...
