Pollard 140 Assembly Instructions

www.pollardbros.com
Includes:
(2) Side Plates (Left & Right) (1) Back Plate
(2) Top Support Angles (2) Cabinet Doors (1) Maple Top
4
x
3/8" x 3/4" Hex Head
Machine Screw
10
x
3/8" Hex Nut
4
x
3/8" Lock Washer
4
x
2" x 2" Butt Hinges
Steps:
1
Determine which are the Front and which are the
Rear Uprights. The Front Uprights have four extra
holes for the hinges. Both Front and Rear Uprights
are made as left and rights.
140 Enclosed Work Bench
Assembly Instructions
Tools Needed:
wrench at head screwdriver
(2) Rear Uprights(Left & Right) (2) Front Uprights
60
x
1/4" x 5/8" Round Head
Machine Screw
60
x
1/4" Hex Nut
60
x
1/4" Lock Washer
6
x
3/8" x 2 1/2" Flat Head Machine Screw
10
x
phillips head screwdriver power drill
6
6
6
#12- 3/4"
Wood Screw
(1) Top Front Cross Angle
x
5/16" x 3/4" Flat
Head Machine Screw
x
5/16" Hex Nut
x
5/16" Lock Washer
1
x
Cylinder Lock
Front Upright
Rear Upright
