Pollard 111 Assembly Instructions

www.pollardbros.com

Includes:

(2) or (3) Bench Legs (1) Formed Channel Stringer (1) Formed Shelf
2
x
1/4" Lock Washer
2
x
1/4" Hex Nut
2
1/4" x 5/8" Round Head
Machine Screw

Steps:

1
Stand legs upright and face as shown. Note: 6'
benches and under come with two legs, and 8'
benches and over come with three legs.
2
Attach stringer to the back leg uprights using (4)
3/8" x 3/4" Hex Head Machine Screws, 3/8" hex
nuts, and 3/8" washers. HAND TIGHTEN ONLY.
111 & 141 - Open Leg Bench
Assembly Instructions

Tools Needed:

wrench at head screwdriver
10
x
phillips head screwdriver
(1) Formed Back Plate (2) End Plates (1) Hard or Maple Top
x
#12- 3/4" Wood Screw
8
x
3/8" x 3/4" Hex Head
Machine Screw
6
x
3/8" x 2 1/2" Flat Head Machine Screw
power drill
8
x
3/8" Lock Washer
14
x
3/8" Hex Nut
