Pollard 121 Assembly Instructions

www.pollardbros.com

Includes:

(2) or (3) Bench Legs (1) Formed Channel Stringer (1) Formed Shelf
6
x
1/4" Lock Washer
6
x
1/4" Hex Nut
6
x
1/4" x 5/8" Round Head
Machine Screw

Steps:

1
Stand legs upright and face as shown. Note: 6'
benches and under come with two legs, and 8'
benches and over come with three legs.
2
Attach stringer to the back leg uprights using (4)
3/8" x 3/4" Hex Head Machine Screws, 3/8" hex
nuts, and 3/8" washers. HAND TIGHTEN ONLY.
121 - Open Leg Bench
Assembly Instructions

Tools Needed:

wrench at head screwdriver
(1) Formed Back Plate (2) End Plates
6
x
5/16" Lock Washer
6
x
5/16" Hex Nut
6
x
5/16" x 3/4" Flat Head
Machine Screw
(1) Steel Top
8
x
3/8" Lock Washer
8
x
3/8" Hex Nut
8
x
3/8" x 3/4" Hex Head
Machine Screw
