Fora TD-3500A Operation Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Part no.
Product name
Spec
Writer
Color
311-0099100-050
機器說明書/NO LOGO/英文/.標準品/
L297*W210mm/模造紙 80P/黑/共 36
頁/騎馬釘
Beryl
█ K: 100

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TD-3500A and is the answer not in the manual?

Questions and answers

Related Manuals for Fora TD-3500A

Summary of Contents for Fora TD-3500A

  • Page 1 Part no. 311-0099100-050 機器說明書/NO LOGO/英文/.標準品/ Product name L297*W210mm/模造紙 80P/黑/共 36 Spec 頁/騎馬釘 Writer Beryl █ K: 100 Color...
  • Page 2 TD-3500A Automatic Blood Pressure Monitor Operation Instruction...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Dear 3500A Owner _________________________________________ 5   Intended Use ______________________________________________________________ 5  Test Principle ______________________________________________________________ 5  Important Safety Precautions _______________________________ 6   Components of the Product _________________________________ 7   Component _______________________________________________________________ 7  Meter Overview ____________________________________________________________ 9  Main unit ____________________________________________________________ 9  REAR ______________________________________________________________ 10 ...
  • Page 4 Remove the cuff cover _________________________________________________ 21  Attach the cuff cover __________________________________________________ 23  Cleaning and Disinfecting ___________________________________________________ 24  Disposal _________________________________________________________________ 24  Detailed Information ______________________________________ 25   Reference Value __________________________________________________________ 25  Calibration ______________________________________________ 25   System Troubleshooting __________________________________ 26   Error Message ____________________________________________________________ 26  Trouble Shooting __________________________________________________________ 27 ...
  • Page 5 Version 1.0 2021/10 311-0099100-050...

  • Page 6: Dear 3500A Owner

    Before using this product, please read the following contents thoroughly and carefully. This TD-3500A Automatic Blood Pressure Monitor can reduce risks of operator errors and allow one hand operation through simple steps. If you have other questions regarding this product, please contact the place of purchase.

  • Page 7: Important Safety Precautions

    Important Safety Precautions READ BEFORE USE 1. Use this device ONLY for the intended use described in this manual. 2. Do NOT use accessories which are not specified by the manufacturer. Other cables and accessories may negatively affect EMC performance. 3.

  • Page 8: Components Of The Product

    Components of the Product Component 1. Main unit 2. Armrest 3. Cuff cover (attach to the monitor) 4. Power cord 5. WiFi antenna 6. SD memory card (attach to the monitor) 7. Printer paper (one roll) 8. Printer key 9. Operation instruction...
  • Page 9 Options (sold separately) 1. Instruction panel 2. Cuff cover 3. Printer paper...

  • Page 10: Meter Overview

    Meter Overview Main unit 1. Display 2.  ▼▲ Switch 3. Mode switch Press to set up the monitor 4. Start/Stop button (L) Press to start or stop measurement 5. Smart card reader Enables transmission of individual information from card to the monitor 6.

  • Page 11: Rear

    REAR 1. AC port 2. Power switch 3. SD card slot An SD memory card can be inserted in this slot 4. RS232 port* Enables connection to a computer 5. USB port* Enables connection to a computer 6. WiFi antenna NOTE: *The RS232 port and USB port are for the manufacturer for internal production use, without any function for the lay user.

  • Page 12: Before You Begin

    Before You Begin Install the Monitor 1. Place the monitor on the desk. Place the front side of the monitor aligned with the desk edge. WARNING: Do NOT place the monitor on the ground. 2. Attach the armrest. 3. Attach the instruction panel (optional).

  • Page 13: Connect To The Power Source

    Connect to the power source 1. Connect the power cord to AC port of the monitor. 2. Plug the power cord into an electrical outlet. 3. Turn the power switch on. The power light will light up. 4. Wait for a while, the monitor will undergo several self-tests to verify its functionality and get ready for further operations.

  • Page 14: Load Printer Paper

    Load Printer Paper 1. Press the power button of the printer. The printer power light will light up. 2. Insert the printer key into keyhole of the printer. Turn the key in clockwise direction to open the printer cover. 3. Insert the printer paper in orientation shown and pull out about 10 cm.
  • Page 15 4. Firmly close the printer cover. The printer paper will be cut automatically. NOTE: A red line will appear when the paper has 1 meter left. Load a new roll of printer paper.  When printer error light lights up, turn the printer off and on to restart it. ...

  • Page 16: Set Up The Monitor

    Set up the Monitor Press Mode button for 3 seconds and release to get into setting mode. Press ▼ and ▲ to switch between different functions. Press Mode to get into each section. Select OK at the bottom to exit setting mode. This monitor provides following setting functions: Language: Select the on-screen menu language.

  • Page 17: Smart Card Reader: Turn On/Off The Function Of Smart Card Reader

    Smart Card Reader: Turn on/off the function of smart card reader. Contact Card - Press mode to set up. Press ▲ and ▼ to switch between ON and OFF then press mode to confirm. Test Mode: Check the function of this monitor. In Test Mode, you can check the operating system of BP / Smart Card / Printer / WiFi.

  • Page 18: Start Measurement

    Start Measurement Before measurement Avoid caffeine, tea, alcohol and tobacco for at least 30 minutes before measurement.  Wait 30 minutes after exercising or bathing before measurement.  Sit or lie down for at least 10 minutes before measurement.  Do NOT measure when feeling anxious or tense.

  • Page 19: Take Blood Pressure

    Take Blood Pressure 1. Press start/stop button to start measurement. NOTE: The start/stop button on the right side of monitor is available for measurement with left arm. 2. The cuff start inflating. Relax and remain quiet. 3. Remove the arm when finish. The cuff will automatically expand when the measurement is finished.

  • Page 20: Data Transmission

    NOTE: Take the printed paper only after it cut by the printer. Do NOT pull it out during printing process. It may cause a paper jam. Data Transmission You can transmit your measuring results from the monitor to your devices (e.g. PC) via WiFi/Bluetooth.
  • Page 21 3. Connected indicates successful connection. If you want to disable the connection with connected WiFi access point, select Disconnect at the bottom right corner. Select OK to exit WiFi & BL. Bluetooth Transmission - Pairing this monitor with management system via Bluetooth. Press mode to set up.

  • Page 22: Maintenance

    Maintenance Monitor To avoid the meter attracting dirt, dust or other contaminants, wash and dry the hands thoroughly before use. Monitor storage Storage condition: -25°C to 70°C (-13°F to 158°F), 10% to 95% relative humidity.  Avoid dropping or heavy impact. ...
  • Page 23 3. Pull the cuff cover at upper back and remove it from the groove of the cuff. 4. Pull out the cuff cover from the cuff.

  • Page 24: Attach The Cuff Cover

    Attach the cuff cover 1. Insert the cuff cover to the cuff from the front, and pull the cover ring to the back. 2. Gently insert the back of cover ring into the groove. 3. Attach the front part of cuff enclosure back on the cuff and tighten the screw.

  • Page 25: Cleaning And Disinfecting

    4. Make sure the cover rings are completely inserted and the seam of cuff cover is at the bottom. NOTE: Do NOT pull out the inner cuff cover which is fixed in the cuff.  Make sure the power button is switched off when replacing the cuff cover. ...

  • Page 26: Detailed Information

    Detailed Information Reference Value Human blood pressure naturally increases after reaching middle age. This symptom is a result of continuous ageing of the blood vessels. Further causes include diabetes, lack of exercise and cholesterol (LDL) adhering to the blood vessels. Rising blood pressure accelerates hardening of the arteries, and the body becomes more susceptible to apoplexy and coronary infarction.

  • Page 27: System Troubleshooting

    System Troubleshooting If you follow the recommended action but the problem persists, or error messages other than the ones below appear, please call your local customer service. Do NOT attempt to repair by yourself and never try to disassemble the meter under any circumstances. Error Message MESSAGE CAUSE...

  • Page 28: Trouble Shooting

    Trouble Shooting If nothing appears after switching on power button. POSSIBLE CAUSE WHAT TO DO Insert the power cord into electrical outlet The power cord is not connect properly. correctly. If the monitor does not inflate after pressing start/stop button. POSSIBLE CAUSE WHAT TO DO Select OK from setting mode to finish setting.

  • Page 29: Specification

    Specification System performance Model No.: TD-3500A Power Supplier: AC 100~240V, 47/63Hz, 0.7-1.3A Power Consumption: 64W Size of Meter w/o Cuff: 295 (L) x 440 (W) x 282 (H)mm, 5.5 kg Cuff Size: 17~42 cm Display: 7 inch TFT panel Firmware version: TD3500A-2022041200 Card Reader(Optional): External Powered 5V±5% ,500mA...

  • Page 30: Symbol Information

    Accuracy of Pressure: ±3 mmHg or ±2% of reading Accuracy of Pulse rate: ±4% of reading NIBP Measuring method: Oscillometrics during deflation Inflation method: Auto inflation by pump Measurement Unit: Fixed mmHg This device has been tested to meet the electrical and safety requirements of: IEC/EN 60601-1, IEC/EN 60601-1-2, EN 301 489-17, EN 301 489-1, EN 300 328.

  • Page 31: Electromagnetic Compatibility (Emc) Information

    Electromagnetic Compatibility (EMC) Information Manufacturer’s declaration-electromagnetic emissions The device is intended for use in the electromagnetic environment specified below. The customer or the user of the device should assure that it is used in such an environment. Emission test Compliance Electromagnetic environment-guidance RF emissions CISPR 11 Group 1...
  • Page 32 Manufacturer’s declaration-electromagnetic immunity The device is intended for use in the electromagnetic environment (for professional healthcare) specified below. The customer or the user of the device should assure that it is used in such an environment. Immunity test IEC 60601 test level Compliance level Electromagnetic environment- guidance...
  • Page 33 Manufacturer’s declaration-electromagnetic immunity The device is intended for use in the electromagnetic environment (for professional healthcare) specified below. The customer or the user of the device should assure that it is used in such and environment. Immunity test IEC 60601 test level Compliance level Electromagnetic environment-guidance Conducted RF...
  • Page 34 Recommended separation distance between portable and mobile RF communications equipment and the device The device is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the device can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the device as recommended below, according to the maximum output power of the communications equipment.
  • Page 35 Manufacturer’s declaration-electromagnetic immunity Test specifications for ENCLOSURE PORT IMMUNITY to RF wireless communications equipment The device is intended for use in the electromagnetic environment (for professional healthcare) specified below. The customer or the user of the device should assure that it is used in such an environment. Maximum IMMUNITY TEST Compliance LEVEL...

  • Page 36: Federal Communications Commission Statement

    FEDERAL COMMUNICATIONS COMMISSION STATEMENT 15.21 You are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment. 15.105(a) Federal Communications Commission (FCC) Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
  • Page 37 TaiDoc Technology Corporation B1-7F, No.127, Wugong 2nd Rd., Wugu Dist., 24888 New Taipei City, Taiwan www.taidoc.com MedNet EC-REP GmbH Borkstraβe 10, 48163 Mϋnster, Germany Imported by: XXXX (Address)
