P30/P30 Plus

Dear

System Owner:

Thank you for purchasing the FORA P30/P30 Plus Multi-mode

Blood Pressure Monitoring System. This manual provides impor-

tant information to help you operate this system correctly. Before

using this product, please read the following contents thoroughly

and carefully.

With the compact size and easy operation of this FORA P30/P30

Plus Multi-mode Blood Pressure Monitoring System, you can easily

monitor your blood pressure by yourself at any time or place. In ad-

dition, this system can help you and your healthcare professionals

to monitor and adjust your treatment plans, and keep your blood

pressure under control.

If you have other questions regarding this product, please contact

the place of purchase.

Version 2.0 2011/07

311-3129000-004

Need help?

Do you have a question about the P30 and is the answer not in the manual?

Questions and answers

Summary of Contents for Fora P30

Page 1 With the compact size and easy operation of this FORA P30/P30 Plus Multi-mode Blood Pressure Monitoring System, you can easily monitor your blood pressure by yourself at any time or place. In ad-...
Page 2 IMPORTANT SAFETY INSTRUCTIONS READ THIS BEFORE USE 1. Use this device ONLY for the intended use described in this manual. 2. Do NOT use accessories which are not speciﬁed by the manufacturer. 3. Do NOT use the device if it is not working properly or damaged.
Page 3 TABLE OF CONTENTS BEFORE YOU BEGIN Intended Use Test Principle Contents of System Monitor Overview Display Screen SETTING THE MONITOR TESTING YOUR BLOOD PRESSURE Before Measurement Taking Measurements MONITOR MEMORY Reviewing Test Results Reviewing Day Average Results MAINTENANCE Battery Using AC Adapter Caring for Your Monitor SYSTEM TROUBLESHOOTING Error Messages...
Page 4 BEFORE YOU BEGIN Intended Use The FORA P30/P30 Plus Multi-mode Blood Pressure Monitoring Sys- tem is intended to be used to measure the systolic and diastolic blood pressure and pulse rate by using a non-invasive technique in which an inﬂatable cuff is wrapped on the upper arm. Do not use this system on babies, young children or persons who cannot express their consent.
Page 5 Contents of System Your new FORA P30/P30 Plus system kit includes: Monitor Warranty Card Owner ’ s Manual 4 x 1.5V AA alkaline batteries Wide Range Cuff (24-43cm) Protective Wallet NOTE All items can be purchased separately and some accessories may not be included in the kit.
Page 6 Screen Display M Button Enter the monitor memory ON/OFF Button Pressure Cuff AVG/S Button (For FORA P30 Plus model) Air Tube Assist you with blood pressure average mode / Enter and conﬁrm the monitor settings Air Plug S Button (For FORA P30 model) Connect to air jack Enter and conﬁrm the monitor settings...
Page 7 Display Screen Date Day- / Night-Time Symbol Time Day Average Symbol Systolic Pressure Symbol Units for Blood Pressure Systolic Pressure Value Memory Mode Symbol Low Battery Symbol Pulse Rate Symbol Diastolic Pressure Symbol Pulse Rate Diastolic Pressure Value...
Page 8 ► Entering the Setting Mode Start with the monitor off. For FORA P30 Plus press and ﬁrmly hold for 3 seconds until the monitor turns on. By FORA P30 for this and further steps use instead of Step 1 Setting the date.
Page 9 Step 2 Setting the time. With the hour ﬂashing, pres until the correct hour appears. Press set. With the minute ﬂashing, press until the correct minute appears. Press to set. Step 3 Setting the time. Press to select the desired time format --- 12h or 24h.
Page 10 Step 4 Delete the memory. While “ dEL ” and a ﬂashing “ ” symbol appears on the display, if you do not wish to delete the saved results, press to skip this step. twice. “ CLr ” and “ ”...
Page 11 Select from the operations below: • Single measurement Perform an individual blood pressure measurement. • Averaging measurement (For FORA P30 Plus only) Automatically performs three (3) consecutive blood pressure mea- surements and displays the average result in the end.
Page 12 ► Fitting the Cuff Correctly Step 1 Connect the air plug of the tubing to the air jack of the monitor. Step 2 Assemble the cuff as shown on the right. The smooth surface should be inside the cuff loop and the metal D-ring should not touch your skin.
Page 13 Step 5 Press the hook material ﬁrmly against the pile material. The top and bottom RED LINESHOULD BE AT THE INSID edges of the cuff should be tightened evenly around your upper arm. INDEX MUST ►The range index of cuff should fall into this range.
Page 14 Taking Measurements ► Taking a Single Measurement Always apply the pressure cuff before turning on the monitor. Step 1 Press . All the LCD symbols will appear. Then the cuff will begin to inﬂate automatically. Step 2 The heart symbol “ ”...
Page 15 ► Averaging Measurement Mode (For FORA P30 Plus only) Always apply the pressure cuff before turning on the monitor. Step 1 Press .The monitor will turn on and enter the averaging mode. Then the cuff will begin to inﬂate automatically.
Page 16 Step 3 After taking three measurements, the results are averaged to produce the blood pressure measurement with AVERAGE symbol display on the monitor. Press to turn off the monitor. Or it will switch off automati- cally after idle for 3 minutes. ►...
Page 17 Step 1 Place a stethoscope on the arm where there is a pulse. Wrap the cuff around the upper arm and hold in place with Velcro. Step 2 until “ AUS ” symbol appears on the display with a Press and hold beep.
Page 18 Step 5 The diastolic pressure is measured from the moment the operator is unable to hear the sound of the pulse. Write down the value on the display. This value indicates the patient ’ s diastolic pressure. You have to record the values as the result will not be stored in the memory. Step 6 The monitor will return to 0 mmHg after the measurement is complet- or it will switch off auto-...
Page 19 MONITOR MEMORY Your monitor stores the 60 most recent blood pressure test results along with respective dates and times in the monitor memory. To recall the memory, start with the monitor off. Reviewing Test Results Step 1 Press and release Symbol 01 with “...
Page 20 Reviewing Day Average Results Step 1 Press and hold for 3 seconds. Step 2 Press and the Day average result appears on the display. Step 3 Press again to review the Day-time average result Step 4 Press again to review the Night-time average result.
Page 21 Step 5 Exit the memory. Press and the monitor turns off. NOTE • “ ” Day-time average is the average of the measurements taken during 4:00 A.M .to 11:59 A.M. • “ ” Night-time average is the average of the measurements taken during 6:00 P.M.
Page 22 MAINTENANCE Battery Your monitor comes with four 1.5V AA size alkaline batteries. ► Low Battery Signal The monitor displays either of the two messages below to alert you when the power is getting low. Step 1 The “ ” symbol appears with display messages: The monitor is functional and the result remains accurate, but it is time to change the batteries.
Page 23 ► Replacing the Battery To replace the batteries, make sure that the monitor is turned off. Step 1 Press the edge of the battery cover and lift it up to remove. Step 2 Remove the old batteries and replace with four new 1.5V AA size alkaline batteries.
Page 24 Using AC Adapter ► Connect AC adapter to the monitor Step 1 Connect AC adapter plug to AC adapter jack of the monitor. Step 2 Plug AC adapter power plug into an electrical outlet. The monitor is ready for use. ►...
Page 25 Caring for Your Monitor To avoid the meter and test strips attracting dirt, dust or other contaminants, please wash and dry your hands thoroughly before use. ► Cleaning • To clean the monitor exterior, wipe it with a cloth moistened with tap water or a mild cleaning agent, then dry the device with a soft dry cloth.
Page 26 SYSTEM TROUBLESHOOTING If you follow the recommended action but the problem persists, or er- ror messages other than the ones below appear, please call your local customer service. Do not attempt to repair by yourself and never try to disassemble the monitor under any circumstances. Error Messages MESSAGE CAUSE...
Page 27 Replace the batteries or Battery is too low. use the AC adaptor. Problem with the Please contact local cus- monitor. tomer service for help.
Page 28 Troubleshooting 1. If nothing is displayed after pressing POSSIBLE CAUSE WHAT TO DO Batteries exhausted. Replace the batteries. Batteries incorrectly installed or Check that the batteries are correctly absent. installed. 2. If the heart rate is higher/lower than user ’ s average: POSSIBLE CAUSE WHAT TO DO Movement during measurement.
Page 29 DETAILED INFORMATION Reference Values Human blood pressure naturally increases after reaching middle age. This symptom is a result of continuous ageing of the blood vessels. Further causes include diabetes, lack of exercise and cholesterol (LDL) adhering to the blood vessels. Rising blood pressure accelerates hardening of the arteries, and the body becomes more susceptible to apoplexy and coronary infarction.
Page 30 SYMBOL INFORMATION Symbol Referent Consult instructions for use Batch code Manufacturer Serial number Caution, consult accompanying documents Do not use if package is damaged Type BF Equipment CE mark Dispose of in accordance with the requirements of your country.
Page 31 SPECIFICATIONS System Performance Power Four 1.5V AA alkaline batteries 160 (L) x 95 mm (W) x 66.5 mm (H), 400g Size of monitor w/o cuff with batteries. 24-43 cm (9.4 - 16.9 inches) Cuff Size with air tube 100 cm Memory Maximum 60 memory records Automatic power off if system is idle for 3...
Page 32 Blood pressure measurement performance Measurement unit mmHg Systolic Measurement Range 50 mmHg -255 mmHg Diastolic Measurement Range 25 mmHg -195 mmHg Pulse Rate Measurement Range 40 -199 beats / minute ± 3 mmHg or ± 2% of reading Accuracy of Pressure ±...
