- Page 1 Mod. 1730-1735-1736 DS1730-025A ACCESS CONTROL MODULE FOR KIT 1730, 1735 and 1736 Ref. 1730/65 Installation and instruction manual...
-
Page 2: Table Of Contents
Deleting a user key ....................6 Deleting all user keys ....................7 Programming keys as masters ................7 USE OF THE 1730/65 MODULE IN THE 1730, 1735 AND 1736 KITS ....8 CONTENTS OF THE PACKAGE ................ 9 TECHNICAL SPECIFICATIONS ................. 9 SIMPLIFIED EU DECLARATION OF CONFORMITY ........ -
Page 3: General Warnings
GENERAL WARNINGS Read the warnings contained in this document carefully as they provide important information regarding safe installation, use and maintenance. The device must be used only for the use for which it was expressly designed. Any other use is to be considered improper. The manufacturer cannot be held responsible for any damage resulting from improper and unreasonable use. -
Page 4: Module Installation
MODULE INSTALLATION Inside the outdoor station for kit Ref. 1730, 1735 and 1736/51, there is a housing designed to accommodate the access control module (Fig. 6). Stick the double-sided tape on the module to fix it (Fig. 5) to the housing on the outdoor station. The key reading area will be dashed after... -
Page 5: Key Configuration
KEY CONFIGURATION Pay particular attention to the sound feedback of the module for all illustrated procedures. Repeat the procedure from the beginning if it differs from that described. ADDING A USER KEY Use the YELLOW key to store a new USER key. ... -
Page 6: Using The Stored User Key
USING THE STORED USER KEY Place and, if necessary, swipe the key over the sensitive area of the name tag to trigger the lock connected to the outdoor station: Note: The blue key will not activate the lock if a conversation is in progress between the outdoor station and an apartment device. -
Page 7: Deleting All User Keys
DELETING ALL USER KEYS To delete all the keys, place the YELLOW key after the RED key. Fast confirmation beeps will sound for about 15 seconds. Lift the YELLOW key at the end of the beeps. Place the RED key to quit the programming mode. RED KEY YELLOW RED KEY... -
Page 8: Use Of The 1730/65 Module In The 1730, 1735 And 1736 Kits
USE OF THE 1730/65 MODULE IN THE 1730, 1735 AND 1736 KITS The images relating to the use and installation of the 1730/65 module contained in this manual are purely indicative. The 1730/65 device works in the three video intercom systems 1730, 1735 and 1736 with the same operating, use and installation methods. -
Page 9: Contents Of The Package
CONTENTS OF THE PACKAGE ACCESS CONTROL MODULE To be installed inside the outdoor station in the housing provided to allow lock activation with the user keys. MASTER KEYS Keys for adding and deleting user keys. The keys are supplied pre- programmed. -
Page 10: Simplified Eu Declaration Of Conformity
Hereby, URMET S.p.A. declares that the radio equipment type: ACCESS CONTROL MODULE FOR KIT 1730, 1735 and 1736 Ref. 1730/65 and the KEYS SUPPLIED are in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: www.urmet.com. - Page 11 DIRECTIVE 2012/19/EU OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL of 4 July 2012 on waste electrical and electronic equipment (WEEE). The crossed-out wheelie bin symbol on the equipment or its packaging indicates that the product at the end of its useful life must be collected separately from other waste. Therefore, any products that have reached the end of their useful life must be given to waste disposal centres specialising in separate collection of waste electrical and electronic equipment.
