ARTOME M10 Quick User Manual

Quick user guide
First time use
A. Connect the power cable to the POWER connector on the back.
Open the front door by pressing the door from the upper left corner.
B. Feed the HDMI-USB cable through the cable grommet and connect the
cable to the Artome HDMI and ARTOME+ connectors.
C. Connect HDMI-USB cable to your computer HDMI and USB A-ports.
Use adapter if necessary.
Artome starts automatically when Artome detects HDMI from computer.
If necessary, turn on the Artome from the Power button.
Using Artome in video conferencing
USB connects Artome and computer to external USB devices, which are
needed for videoconferencing.
D. When using speakerphone for audio; install wireless USB Dongle of
external speakerphone to USB port.
E. Connect the USB cable to the camera. Place the camera on the top
panel and connect the cable to the USB port. If necessary, use the
magnetic camera stand.
Adjusting image focus
F. Adjust the image focus with the Focus lever.
SPEAKER
"The name of the speakerphone"
Speakerphone plays back the video call audio
Artome Hybridock (USB)
Artome speakers play back the video call audio
EPSON PJ (HDMI)
Artome speakers play back the video call audio
CAMERA
"The name of the USB camera"
Uses camera connected to Artome as the image source
Artome support
support@artome.fi
Video conferencing software: device settings
MICROPHONE
"The name of the speakerphone"
Uses speakerphone as the audio source
Artome Hybridock
Uses Artome MIC 1 or MIC 2 connection as the audio source
•
the mic sound plays back from the Artome speakers in
addition to the video call
4.3
A
B
C
D E
E
