ARTOME X20 Quick User Manual

Image adjustment
T. Test Pattern
Select the Test Pattern mode and adjust the image with phases 1-4.
2. Menu / Settings / Geometry Correction / H/V-keystone
V-keystone:
Adjusts the tilt angle of the image
(compare that the vertical edges are straight)
3. Zoom
Adjusts the image size
contact@artome.fi | www.artome.fi
Artome support: +358 40 455 4455
3.0
Quick User Guide
A
1
• Open the door by pressing the upper right corner (image A)
2
B
• Feed the HDMI-USB cable through the inlet and connect the cable to the
Artome HDMI and ARTOME + connectors (image B)
3
• Connect HDMI-USB cable to your computer HDMI and USB A-ports.
C
Use adapter if necessary. (image C)
4
• Power on the Artome by pressing the POWER button on the control panel
2. 1. T.
3.
4.
1. Lens shift
Adjusts the image position horizontally and vertically
V-balance:
Adjusts the image height
(compare that the circular shapes of the
Test Pattern are symmetrical)
4. Focus
Adjusts the image focus
