ARTOME M10 Quick User Manual

Video conferencing software: device settings
Camera: "The name of the USB camera"
Uses camera connected to Artome as the image source
Speaker: ARTOME HybriDock
Artome speakers play back the video call audio
Speaker: "The name of the speakerphone"
Speakerphone plays back the video call audio
contact@artome.fi | www.artome.fi
Artome support: +358 40 455 4455
Quick user guide
A
1
• Connect the power cord to the POWER connector on the back (image A)
2
B
• Open the front door by pressing the door in the upper left corner
• Feed the HDMI-USB cable through the inlet and connect the cable to the
Artome HDMI 1 and ARTOME + connectors (image B)
3
• Connect the HDMI end of the cable to your computer. Use adapter if
C
necessary (image C)
• If you're using a camera or speakerphone attached to your Artome, also
connect the USB end of the cable to your computer (image C)
• Artome starts automatically when the HDMI cable is connected between
the computer and the Artome
• If necessary, turn on the Artome from the POWER button on the control panel
D
4
• If you're using a speaker phone, connect its USB-dongle to the USB
connector on the Artome (image B)
• Be sure to charge the speakerphone and turn it off after use (image D)
3.0
Teams, Zoom, Meet etc.
Microphone: "The name of the speakerphone"
Uses speakerphone as the audio source
Microphone: ARTOME HybriDock
Uses Artome MIC 1 or MIC 2 connection as the audio source
•
when using an external microphone, the mic sound plays
back from the Artome speakers in addition to the video call
