472378 Rev00
Please read these instructions thoroughly before installation.
If you have any questions or need
spare parts don't worry, we're happy to help.
Customer Helpline
Online Support
www.avfgroup.com/support
0333 320 0463
Helpine Open Mon to Thurs 9am - 5pm, Fri 9am - 4pm
AVF Group Ltd. Hortonwood 30, Telford, Shropshire, TF1 7YE, England
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for AVF Group 472378
Summary of Contents for AVF Group 472378
- Page 1 If you have any questions or need spare parts don’t worry, we’re happy to help. Customer Helpline Online Support www.avfgroup.com/support 0333 320 0463 Helpine Open Mon to Thurs 9am - 5pm, Fri 9am - 4pm AVF Group Ltd. Hortonwood 30, Telford, Shropshire, TF1 7YE, England...
- Page 2 Mount your TV in 3 easy steps! Assembly Overview Attach the TV Mounting Plate to the TV 50 x 100mm (2 x 4”) Min Attach the Wall Plate to the Wall Hook the TV on to the Mount...
- Page 3 CAUTION 100 kg VESA 220 lb Use with products 100 x100mm heavier than capacity up to STRONG may result in instability 600 x 400mm causing possible injury SECURE Suitable Wall Types Solid Concrete Wall W ood St ud Wall You will need "...
- Page 4 Parts Included No.16 (5/16”) Ø12mm JYWL602 Use this way up Use this way up 0333 320 0463 Contact us for help!
- Page 5 TV Fixings 45mm 30mm 16mm You won’t need all these screws. Just use the screws that fit your TV. Keep left over screws in a safe place. avfgroup.com/support...
- Page 6 Preparing the TV Mounting Plate Before you can attach the TV mounting plate to your TV you need to disassemble the wall mount. Wall Bracket Cover TV Mounting Plate Level Lock Screw Wall Bracket Cover Remove the Level Lock Screw and safely keep for Step 3A. Remove the TV Mounting Plate.
- Page 7 Measure the distance between the mounting holes (VESA) on the back of your TV. If the distance is 200mm or less then proceed straight to Step 1B. • • If the distance is greater than 200mm you will need to add the four VESA adaptors before proceeding to Step 1B.
- Page 8 Attach the TV Mounting Plate to the TV Position the TV Mounting Plate • Position the TV Mounting Plate on the back of your TV. The plate must be level and positioned on the vertical centre line of your TV. •...
- Page 9 Attach the TV Mounting Plate If TV VESA is 200x200mm or less, use holes in the TV Mounting Plate. Select the correct TV screw to fit your TV. You may need to use Spacers I1 or I2 if the screws are too long or the back of your TV is not flat.
- Page 10 Marking the Wall for Drill Points TV Height Calculator Determine the exact position for your drill points with our easy online tool at avfgroup.com/avf-jl/product/jywl602 Determine the Height for Your Drill Points • Measure A from the bottom of the TV mounting plate to the bottom of your TV as shown.
- Page 11 Solid Concrete Wall • Use the Wall Template to mark the drill points on your wall. • Use the 3 drill points as shown. W ood St ud Wall • Use the Wall Template to mark the drill points on your wall. •...
- Page 12 Attach the Wall Plate to the Wall Solid Concrete Wall 140mm (5½”) Min. 75mm (3") Remove dust 12mm / 15/32" from holes. Masonry 140mm (5½”) Min. It can be difficult to accurately drill holes with a large drill bit. Try drilling 6mm pilot holes first.
- Page 13 Lubricate screw thread with soap. DO NOT overtighten screws. No.16 (5/16”) Ø12mm Tighten screws by hand only. avfgroup.com/support avfgroup.com/support...
- Page 14 W ood St ud Wall 12.5mm (1/2”) Max 50 x 100mm (2 x 4”) Min Ensure you drill in the centre of the wood stud. 75mm (3") 5mm / 13/64" Wood 0333 320 0463 Contact us for help!
- Page 15 12.5mm (1/2”) Max 50 x 100mm (2 x 4”) Min DO NOT use wall plugs in a wood stud wall. Lubricate screw thread with soap. No.16 (5/16”) DO NOT overtighten screws. Tighten screws by hand only. avfgroup.com/support...
- Page 16 Fitting the Wall Bracket Covers Wall Bracket Cover Use the Wall Bracket Covers removed in Step 1A. Wall Bracket Cover 0333 320 0463 Contact us for help!
- Page 17 Connect the TV to the Mount Arm Reuse Level Lock Screw saved in step 1A. When the TV is level, ensure the Level Lock Screw is fully tightened. To remove the TV, reverse this procedure. avfgroup.com/support...
- Page 18 Post-Installation Adjustment TV Levelling Loosen the Level Lock Screw, adjust your TV until it is level, then re-tighten the screw. 0333 320 0463 Contact us for help!
- Page 19 Tilt If you feel the tilt is too stiff or too loose you can adjust the tilt screws to achieve perfect tilt resistance. You must adjust both screws equally. You can also lock the tilt if required. avfgroup.com/support...
- Page 20 LIFETIME WARRANTY AVF warrants that the product is free from defects in material and workmanship, as long as the product is owned by the original consumer purchaser. If, during the stated warranty of this product, it proves to be defective, AVF will remedy the defect by either repairing or replacing the defective part or, replacing the entire product.
