USE AND CARE GUIDE
OUTDOOR PATIO HEATER
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this patio heater. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank
you for choosing Hampton Bay!

Advertisement

loading
Need help?

Need help?

Do you have a question about the HPS-C-PC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HAMPTON BAY HPS-C-PC

Summary of Contents for HAMPTON BAY HPS-C-PC

  • Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this patio heater. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank...
  • Page 2 DANGER If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. If odor continues, keep away from the appliance and immediately call your gas supplier or fire department. WARNING Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
  • Page 3 TABLE OF CONTENTS PACKAGE CONTENTS …………............…………........... HARDWARE CONTENTS …………............ SAFETY INFORMATION PREPARATION …………..............…………..........ASSEMBLY INSTRUCTIONS …………........... OPERATION INSTRUCTIONS …………..........CARE AND MAINTENANCE TROUBLESHOOTING …………............ONE-YEAR LIMITED WARRANTY …………........REPLACEMENT PARTS LIST …………..........
  • Page 4 PACKAGE CONTENTS QUANTITY Reflector Emitter Wire Guard Access Door (preassembled to Heater Housing (H)) Base Ring Weight Post with Burner Assembly Heater Housing Finial Reflector cap Tank conversion hose (length: 4.5ft)
  • Page 5 HARDWARE CONTENTS (shown actual size) Wrench Qty. 1 Nuts 3/16” Washers (not actual size) Qty. 7 Stainless Qty. 6 M6 X 20 Screw Bolts Reflector Qty. 8 spacers Qty. 4 Qty. 3 M6 X 60 Bolts Qty. 1 SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product.
  • Page 6 SAFETY INFORMATION DANGER DANGER • EXPLOSION - FIRE HAZARD • CARBON MONOXIDE HAZARD • Keep solid combustibles, such as building materials, • This heater is a combustion appliance. All paper or cardboard, a safe distance away from the combustion appliances produce carbon monoxide heater as recommended by the instructions.
  • Page 7 SAFETY INFORMATION WARNING WARNING California Proposition 65 • This product is fueled by propane gas. Propane gas Combustion by-products produced when using is invisible, odorless, and flammable. An odorant is this product contain chemicals known to the State normally added to help detect leaks and can be of California to cause cancer, birth defects, and described as a “rotten egg”...
  • Page 8 ASSEMBLY INSTRUCTIONS WARNING This product contain sharp edges on the panels,cylinder housing and handle please install with care. 1. Attach post with burner assembly (G) onto heater housing (H), using four 3/16” stainless screws (FF). Hardware Used 3/16” Stainless Screw 2.
  • Page 9 ASSEMBLY INSTRUCTIONS 4. Insert ends of wire guard (C) into holes in post with burner assembly (G). 5. Put washers (CC) into the top of support bolts on post with burner assembly (G). Attach reflector (A) to assembly with nuts (DD) and washers (CC). Put reflector cap (J) through the M6X60 bolt using finial (I) to secure it.
  • Page 10 ASSEMBLY INSTRUCTIONS The propane gas and cylinder are sold separately. Every part of the heater shall be secure against displacement and shall be constructed to maintain a fixed relationship between essential parts under normal and reasonable conditions of handling and usage. Parts not permanently secured shall be orientation to designed so they cannot be incorrectly assembled and cannot be provide vapor...
  • Page 11 OPERATION INSTRUCTIONS Portable Heater Location CEILING 1. This portable heater is intended for outdoor use only. Always ensure that adequate fresh air ventilation is provided. 24 in. 2. Always maintain proper clearance to combustible. materials, i.e. top 24 inches and sides 36 inches minimum. 36 in.
  • Page 12 OPERATION INSTRUCTIONS Turning ON the Heater 1. Turn on the valve on the gas supply cylinder completely. 2. Firmly press down and turn the variable control knob approximately 90° (counterclockwise). 3. Press down the variable control knob and hold for 90 seconds. While holding down the variable control knob, press the igniter button several times until the pilot flame comes on.
  • Page 13 OPERATION INSTRUCTIONS WARNING FOR YOUR SAFETY Be careful when attempting to manually ignite this heater. Holding in the control know for more than 10 seconds before igniting the gas will cause a ball of flame upon ignition. When Heater is ON: Emitter screen will become bright red due to intense heat.
  • Page 14 OPERATION INSTRUCTIONS 9. Heater is away from gasoline or other flammable liquids or vapors. 10. Heater is away from windows, air intake openings, sprinklers and other water sources. 11. Heater is at least 2 feet on top and at least 3 feet on sides from combustible materials. 12.
  • Page 15 CARE AND MAINTENANCE Visually checking portions of the hose assembly located within the confines of the heater post. Inspect the entire hose assembly at least annually, disassembling the reflector and burner. Inspect the hose assembly for evidence of excessive abrasion, cuts, or wear. Suspected areas should be leak tested. Then assembling the reflector and burner again following with step 3 to 5.
  • Page 16 TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Cylinder valve is closed Open valve Clean or replace orifice or Blockage in orifice or pilot tube pilot tube Open gas line and bleed it Pilot won’t light Air in gas line (pressing control knob in) for not more than 1 - 2 minutes or until you smell gas Low gas pressure with cylinder valve...
  • Page 17 ONE-YEAR LIMITED WARRANTY This product is inspected, tested and carefully packaged to minimize the chance of damage during shipment. If a part within one year from the date of purchase proves to be defective in material or fabrication under normal use, the part will be repaired or replaced. The Company's obligation under the warranty is to replace or repair defective parts at our discretion.
  • Page 18 REPLACEMENT PARTS LIST For replacement parts, call our customer service department at 1-855-885-5858, 7 a.m. - 4 p.m., PST, Monday - Friday. QUANTITY Reflector Emitter Wire Guard Access Door (preassembled to Heater Housing (H)) Base Ring Weight Post with Burner Assembly Heater Housing Finial Reflector cap...
  • Page 19 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
