Code Alarm ca6553sst Installation Manual page 23

Feature Bank 3 - 5 Chirps
Output Control
1 Extended Lock Pulse
Factory Disarm
2
Lt Green / Black
3 Ignition Controlled Locks
Trunk Output Timing
4
Red / White Output
5 Horn Output Timing
6 Real Panic
AUX 1
7
Violet / Black Output
AUX 2
8
White / Black Output
AUX 3
9
Gray / Black Output
AUX 4
10
Orange / Black Output
AUX 5
11
Pink / Black Output
2012 Audiovox Electronics Corporation. All rights reserved.
1 LED Flash 2 LED Flash
1 Second 3.5 Seconds
Factory
2nd Unlock
Disarm
Lock and
OFF
Unlock
1 Second
10 Seconds
Pulse
16mS 10mS
ON OFF
Push and Hold Latched
Push and Hold Latched
Push and Hold Latched
Push and Hold Latched
Push and Hold Latched
3 LED Flash 4 LED Flash
1 Second Lock, 30 Second
Double Pulse Lock, Double
Unlock Pulse Unlock
Factory Disarm
/ Start Status
Lock Only Unlock Only
Latched until
20 Seconds
IGN ON
30mS 40mS
Latched until Dome Light
IGN ON Output
Latched until 10 Second
IGN ON Pulse with Arm
Latched until 10 Second
IGN ON Pulse with Arm
Latched until 10 Second
IGN ON Pulse with Arm
Latched until 10 Second
IGN ON Pulse with Arm
5 LED Flash 6 LED Flash
Double Pulse
Lock, 1 Second
Unlock
Latched ON
until Button
Press
50mS
Defrost Output Defrost Output
Single Pulse Latched 5 Min
After Start After Start
10 Second
Pulse with
Disarm
10 Second
Pulse with
Disarm
10 Second
Pulse with
Disarm
10 Second
Pulse with
Disarm
23
