Gigabyte 8S648-RZ-C User Manual

Gigabyte 8S648-RZ-C User Manual

Intel pentium 4 processor
Hide thumbs Also See for 8S648-RZ-C:

Advertisement

Quick Links

Download this manual
8S648-RZ /
8S648-RZ-C
Intel
Pentium
4 Processor Motherboard
®
®
User's Manual
Rev. 1001
12ME-8S648RZ-1001
Copyright
© 2003 GIGABYTE TECHNOLOGY CO., LTD
Copyright by GIGA-BYTE TECHNOLOGY CO., LTD. ("GBT"). No part of this manual may be reproduced or transmitted in any from
without the expressed, written permission of GBT.
Trademarks
Third-party brands and names are the property of their respective owners.
Notice
Please do not remove any labels on motherboard, this may void the warranty of this motherboard.
Due to rapid change in technology, some of the specifications might be out of date before publication of this booklet.
The author assumes no responsibility for any errors or omissions that may appear in this document nor does the author make a
commitment to update the information contained herein.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 8S648-RZ-C and is the answer not in the manual?

Questions and answers

Related Manuals for Gigabyte 8S648-RZ-C

Summary of Contents for Gigabyte 8S648-RZ-C

  • Page 1 User's Manual Rev. 1001 12ME-8S648RZ-1001 Copyright © 2003 GIGABYTE TECHNOLOGY CO., LTD Copyright by GIGA-BYTE TECHNOLOGY CO., LTD. ("GBT"). No part of this manual may be reproduced or transmitted in any from without the expressed, written permission of GBT. Trademarks Third-party brands and names are the property of their respective owners.
  • Page 3 Preparing Your Computer Computer motherboards and expansion cards contain very delicate Integrated Circuit (IC) chips. To protect them against damage from static electricity, you should follow some precautions whenever you work on your computer. 1. Unplug your computer when working on the inside. 2.
  • Page 4 Table of Contents Chapter 1 Introduction ....................5 Features Summary ...........................5 8S648-RZ Series Motherboard Layout.....................6 Block Diagram ..........................7 Hardware Installation Process ......................8 Step 1: Install the Central Processing Unit (CPU) ................8 Step 1-1: CPU Installation ....................9 Step 1-2: CPU Cooling Fan Installation ................9 Step 2: Install Memory Modules ....................10 Step 3: Install AGP Card .......................
  • Page 5 Chapter 1 Introduction Features Summary — Socket 478 for Intel ® Pentium ® 4 (Northwood, Prescott) with HT Technology — Intel ® Pentium ® 4 533/400MHz FSB — 2nd cache depends on CPU Chipset — North Bridge: SiS 648 — South Bridge: SiS 963L Memory —...
  • Page 6 CODEC PCI1 CD_I N PCI2 VRM10.0 AUX_IN PCI3 SiS 963L PCI4 P4 Titan BIOS PCI5 SPDI F_IO F_U SB2 SYS _FAN F_PANEL F_U SB1 PWR_LE D "*" Only for 8S648-RZ. "#" Only for 8S648-RZ-C. 8S648-RZ Series Motherboard - 6 -...
  • Page 7 Block Diagram Pentium 4 CPUCLK+/- (100/133 MHz) Socket 478 AGP 4X/8X System Bus AGPCLK 400/533 MHz (66MHz) 266/333 MHz SiS 648 ZCLK (66/133MHz) HCLK+/- (100/133MHz) 5 PCI RJ45 * 66/133 MHz 33 MHz 14.318 MHz 48 MHz ICS 1883 * BIOS SiS 963L Game Port...
  • Page 8 Hardware Installation Process To set up your computer, you must complete the following steps: Step 1- Install the Central Processing Unit (CPU) Step 2- Install mem ory modules Step 3- Install expansion cards Step 4- Install I/O Peripherals Cables Step 4 Step 1 Step 2 Step 4...
  • Page 9 Step 1-1: CPU Installation Figure 1. Socket Pull the rod to the 90-degree directly. Actuation Lever Figure 2. Locate Pin 1 in the socket and look for a (golden) cut edge on the CPU upper corner. Insert the CPU into the socket. (Do not force the CPU into the socket.) Then m ove the socket lever to the locked position while holding pressure on the center of the CPU.
  • Page 10 Step 2: Install Memory Modules Before installing the m emory modules, adhere to the following warning: 1. Please note that the DIMM module can only fit in one direction due to the one notch. Wrong orientation will cause im proper installation. Please change the insert orientation. The motherboard has 3 dual inline memory m odule (DIM M) sockets.
  • Page 11 Step 3: Install AGP Card 1. Read the relateAGP card's instruction document before install the AGP card into the computer. 2. If your AGP card has "AGP 8X/4X(1.5V) notch" (show below), please make sure your AGP card is AGP 8X/4X(1.5V). AGP 4X/8X notch 3.
  • Page 12 MIC In jack Microphone can be connect to MIC In jack. After installation of the audio driver, you are able to use 2/4/6-channel audio feature by software selection. You can connect "Front speaker" to "Line Out" jack, Connect "Rear speaker" to "Line In"...
  • Page 13 1) ATX_12V (+12V Power Connector) This connector (ATX_12V) supplies the CPU operation voltage (Vcore). If this "ATX_12V connector" is not connected, system cannot boot. Pin No. Definition +12V +12V 2) ATX (ATX Power) AC power cord should only be connected to your power supply unit after ATX power cable and other related devices are firmly connected to the mainboard.
  • Page 14 4) SYS_FAN (System Fan Connector) This connector allows you to link with the cooling fan on the system case to lower the system temperature. Pin No. Definition +12V Sense 5) IDE1 / IDE2 (IDE1 / IDE2 Connector) Im portant Notice: Please connect first hard disk to IDE1 and connect CD-ROM to IDE2. The red stripe of the ribbon cable must be the sam e side with the Pin1.
  • Page 15 7) PWR_LED PWR_LED is connect with the system power indicator to indicate whether the system is on/off. It will blink when the system enters suspend mode. If you use dual color LED, power LED will turn to another color. Pin No. Definition MPD+ MPD-...
  • Page 16 9) F_AUDIO (Front Audio Connector) If you want to use Front Audio connector, you must rem ove 5-6, 9-10 Jumper. In order to utilize the front audio header, your chassis must have front audio connector. Also please make sure the pin assigment on the cable is the same as the pin assigment on the MB header. To find out if the chassis you are buying support front audio connector, please contact your dealer.
  • Page 17 12) AUX_IN (AUX In Connector) Connect other device(such as PCI TV Tunner audio out)to the connector. Pin No. Definition AUX-L AUX-R 13) SPDIF_IO (SPDIF In/Out Connector) The SPDIF output is capable of providing digital audio to external speakers or com pressed AC3 data to an external Dolby Digital Decoder.
  • Page 18 14) F_USB1 / F_USB2 (Front USB Connector) Be careful with the polarity of the front USB connector. Check the pin assignment carefully while you connect the front USB cable, incorrect connection between the cable and connector will m ake the device unable to work or even damage it. For optional front USB cable, please contact your local dealer.
  • Page 19 Chapter 2 BIOS Setup BIOS Setup is an overview of the BIOS Setup Program. The program that allows users to modify the basic system configuration. This type of inform ation is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off. ENTERING SETUP Powering ON the com puter and pressing <Del>...
  • Page 20 If you can't find the setting you want, please press "Ctrl+F1" to search the advanced option hidden. • Standard CMOS Features This setup page includes all the item s in standard com patible BIOS. • Advanced BIOS Features This setup page includes all the items of Award special enhanced features. •...
  • Page 21 Standard CMOS Features CMOS Setup Utility-Copyright (C) 1984-2004 Award Software Standard CMOS Features Date (mm:dd:yy) Fri, Jan 9 2004 Item Help Time (hh:mm:ss) 22:31:24 Menu Level} Change the day, month, } IDE Primary Master [None] year } IDE Primary Slave [None] } IDE Secondary Master [None]...
  • Page 22 Drive A / Drive B The category identifies the types of floppy disk drive A or drive B that has been installed in the com puter. None No floppy drive installed 360K, 5.25" 5.25 inch PC-type standard drive; 360K byte capacity. 1.2M, 5.25"...
  • Page 23 Advanced BIOS Features CMOS Setup Utility-Copyright (C) 1984-2004 Award Software Advanced BIOS Features First Boot Device [Floppy] Item Help Second Boot Device [HDD-0] Menu Level} Third Boot Device [CDROM] Select Boot Device Boot Up Floppy Seek [Disabled] priority Password Check [Setup] CPU Hyper-Threading [Enabled]...
  • Page 24 CPU Hyper-Threading Enabled Enables CPU Hyper Threading Feature. Please note that this feature is only working for operating system with multi processors mode supported. (Default value) Disabled Disables CPU Hyper Threading. Init Display First Select the first initation of m onitor or display from AGP or PCI VGA card. Set Init display first to AGP.
  • Page 25 AC97 Audio Enabled Enable onboard AC'97 audio function. (Default value) Disabled Disable this function. On Board LAN device * Disabled Disable this function. Enabled Enable Onboard Lan Chip device. (Default value) USB Controller Enabled Enable USB Controller. (Default value) Disabled Disable USB Controller.
  • Page 26 Game Port Address Set Game Port Address to 201. (Default value) Set Game Port Address to 209. Disabled Disable this function. Midi Port Address Set Midi Port Address to 300. Set Midi Port Address to 330. (Default value) Disabled Disable this function. Midi Port IRQ Set M idi Port IRQ to 5.
  • Page 27 IRQ [3-7, 9-15], NMI Disabled Disable this function. Enabled Enable this function. (Default value) ModemRingOn Disabled Disable Modem Ring on function. Enabled Enable Modem Ring on function. (Default value) PME Event Wake Up Disabled Disable this function. Enabled Enable PM E as wake up event. (Default value) Power On by Keyboard Password Enter from 1 to 8 characters to set the keyboard power on password.
  • Page 28 PnP/PCI Configurations CMOS Setup Utility-Copyright (C) 1984-2004 Award Software PnP/PCI Configurations PCI 4 IRQ Assignment [Auto] Item Help PCI 1/5 IRQ Assignment [Auto] Menu Level} PCI 2 IRQ Assignment [Auto] PCI 3 IRQ Assignment [Auto] higf : Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit...
  • Page 29 PC Health Status CMOS Setup Utility-Copyright (C) 1984-2004 Award Software PC Health Status Vcore 1.54V Item Help DDR25V 2.544V Menu Level} +3.3V 3.360V +12V 11.92V Current CPU Temperature 41° C Current CPU FAN Speed 4440 RPM Current SYSTEM FAN Speed 0 RPM higf : Move Enter: Select...
  • Page 30 Frequency/Voltage Control CMOS Setup Utility-Copyright (C) 1984-2004 Award Software Frequency/Voltage Control CPU Clock Ratio [10X] Item Help Linear Frequency Control [Disabled] Menu Level} x CPU Clock (MHz) x DRAM Clock (MHz) AUTO AGP/PCI Clock Control [AUTO] x AGP Clock (MHz) x PCI Clock (MHz) AGP Voltage Control [Normal]...
  • Page 31 AGP Clock (MHz) Please set AGP Clock according to your requirement. Incorrect using it may cause your system broken. For power End-User use only! PCI Clock (MHz) Please set PCI Clock according to your requirement. Incorrect using it may cause your system broken. For power End-User use only! AGP Voltage Control Normal Set AGP Voltage Control to Normal.
  • Page 32 Load Fail-Safe Defaults CMOS Setup Utility-Copyright (C) 1984-2004 Award Software Standard CMOS Features Top Performance Advanced BIOS Features Load Fail-Safe Defaults Integrated Peripherals Load Optimized Defaults Power Management Setup Set Supervisor Password PnP/PCI Configurations Load Fail-Safe Defaults (Y/N)? N Set User Password PC Health Status Save &...
  • Page 33 Set Supervisor/User Password CMOS Setup Utility-Copyright (C) 1984-2004 Award Software Standard CMOS Features Top Performance Advanced BIOS Features Load Fail-Safe Defaults Integrated Peripherals Load Optimized Defaults Power Management Setup Set Supervisor Password PnP/PCI Configurations Enter Password: Set User Password PC Health Status Save &...
  • Page 34 Save & Exit Setup CMOS Setup Utility-Copyright (C) 1984-2004 Award Software Standard CMOS Features Top Performance Advanced BIOS Features Load Fail-Safe Defaults Integrated Peripherals Load Optimized Defaults Power Management Setup Set Supervisor Password PnP/PCI Configurations Save to CMOS and EXIT (Y/N)? Y Set User Password PC Health Status Save &...
  • Page 35 Revision History Chapter 3 Install Drivers Install Drivers Pictures below are shown in Windows XP Insert the driver CD-title that came with your motherboard into your CD-ROM drive, the driver CD-title will auto start and show the installation guide. If not, please double click the CD-ROM device icon in "My computer", and execute the setup.exe.
  • Page 36 Driver install finished!! you have to reboot system!! Item Description n SIS AGP Driver Install SIS AGP Driver. n USB Patch for WinXP This patch driver can help you to resolve the USB device wake up S3 hang up issue in XP. n SiS PCI Lan Driver * For SiS series Lan driver.
  • Page 37 - 37 - Memo...
  • Page 38 8S648-RZ Series Motherboard - 38 -...
  • Page 39 - 39 - Memo...
  • Page 40 Address: No.6, Bau Chiang Road, Hsin-Tien, Taipei Hsien, Address: Verdunplein 8 5627 SZ, Eindhoven, The Netherlands Taiwan, R.O.C. Tel: +31 40 290 2088 Tel: 886 (2) 8912-4888 NL Tech.Support : 0900-GIGABYTE (0900-44422983, 0.2/M) Fax: 886 (2) 8912-4004 BE Tech.Support : 0900-84034 ( 0.4/M) Tech. Support: Fax: +31 40 290 2089 http://tw.giga-byte.com/TechSupport/ServiceCenter.htm...
