Intel pentium® 4 processor motherboard

Advertisement

8VM533M-RZ /
8VM533M-RZ-C
Intel
Pentium
4 Processor Motherboard
®
®
User's Manual
Rev. 1003
12ME-VM533MRZ-1003
Copyright
© 2004 GIGABYTE TECHNOLOGY CO., LTD
Copyright by GIGA-BYTE TECHNOLOGY CO., LTD. ("GBT"). No part of this manual may be reproduced or transmitted in any from
without the expressed, written permission of GBT.
Trademarks
Third-party brands and names are the property of their respective owners.
Notice
Please do not remove any labels on motherboard, this may void the warranty of this motherboard.
Due to rapid change in technology, some of the specifications might be out of date before publication of this booklet.
The author assumes no responsibility for any errors or omissions that may appear in this document nor does the author make a
commitment to update the information contained herein.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8VM533M-RZ and is the answer not in the manual?

Questions and answers

Summary of Contents for Gigabyte 8VM533M-RZ

  • Page 1 User's Manual Rev. 1003 12ME-VM533MRZ-1003 Copyright © 2004 GIGABYTE TECHNOLOGY CO., LTD Copyright by GIGA-BYTE TECHNOLOGY CO., LTD. ("GBT"). No part of this manual may be reproduced or transmitted in any from without the expressed, written permission of GBT. Trademarks Third-party brands and names are the property of their respective owners.
  • Page 3: Preparing Your Computer

    Preparing Your Computer Computer motherboards and expansion cards contain very delicate Integrated Circuit (IC) chips. To protect them against damage from static electricity, you should follow some precautions whenever you work on your computer. 1. Unplug your computer when working on the inside.
  • Page 4: Table Of Contents

    Table of Contents Chapter 1 Introduction ... 5 Features Summary ...5 8VM533M-RZ Series Motherboard Layout...6 Block Diagram ...7 Hardware Installation Process ...8 Step 1: Install the Central Processing Unit (CPU) ...8 Step 1-1: CPU Installation ... 9 Step 1-2: CPU Cooling Fan Installation ... 9 Step 2: Install Memory Modules ...10...
  • Page 5: Chapter 1 Introduction

    — System Voltage Detect Additional Features — Supports @BIOS — Supports EasyTune 4 Form Factor — Micro ATX size form factor, 24.5cm x 20.8cm "*" For 8VM533M-RZ only. Pentium 4 (Northwood) with HT Technology ® ® 4 533/400MHz FSB ®...
  • Page 6: 8Vm533M-Rz Series Motherboard Layout

    8VM533M-RZ Series Motherboard Layout KB_MS A TX_12V R_USB AUDIO V T6103 * F_AU DIO CODEC BIOS I TE 8705 CD_I N "*" For 8VM533M-RZ only. "#" For 8VM533M-RZ-C only. 8VM533M-RZ Series Motherboard 20.8 cm SOC KET 478 IDE2 VIA P4M 266A /P4M 533...
  • Page 7: Block Diagram

    VT6103 * PCI BUS 33MHz 6 Channel CODEC PCICLK (33MHz) PCICLK (33MHz) USBCLK (48MHz) 14.318 MHz 33 MHz "*" For 8VM533M-RZ only. Pentium 4 CPUCLK+/- (100/133MHz) Socket 478 System Bus 533/400MHz MCHCLK (100/133MHz) P4M266A/P4M533 AGPCLK66 MHz 33 MHz 14.318 MHz...
  • Page 8: Hardware Installation Process

    - Chipset: An VIA Chipset that supports HT Technology - BIOS: A BIOS that supports HT Technology and has it enabled - OS: An operation system that has optim izations for HT Technology 8VM533M-RZ Series Motherboard Step 2 Step 1...
  • Page 9: Step 1-1: Cpu Installation

    Step 1-1: CPU Installation Figure 1. Socket Pull the rod to the 90-degree directly. Actuation Lever Figure 2. Locate Pin 1 in the socket and look for a (golden) cut edge on the CPU upper corner. Insert the CPU into the socket. (Do not force the CPU into the socket.) Then m ove the socket lever to the locked position while holding pressure on the center of the CPU.
  • Page 10: Step 2: Install Memory Modules

    To install the memory module, just push it vertically into the DIMM socket. The DIM M module can only fit in one direction due to the notch. M emory size can vary between sockets. 8VM533M-RZ Series Motherboard Notch 1. The DIMM socket has a notch, so the DIMM memory module can only fit in one direction.
  • Page 11: Step 3: Install Agp Card

    Also m ake sure your OS supports USB controller. If your OS does not support USB controller, please contact OS vendor for possible patch or driver upgrade. For more information please contact your OS or device(s) vendors. "*" For 8VM533M-RZ only. - 11 - Hardware Installation Process...
  • Page 12: Step 4-2: Connectors Introduction

    "Line In" jack and connect "Center/Subwoofer" to "MIC In" jack. Step 4-2: Connectors Introduction 1) ATX_12V 2) ATX 3) CPU_FAN 4) FDD 5) IDE1 / IDE2 6) BAT "*" For 8VM533M-RZ only. 8VM533M-RZ Series Motherboard 7) F_PANEL 8) PWR_LED 9) F_AUDIO 10) CD_IN 11) F_USB1 12) COMB...
  • Page 13 1) ATX_12V (+12V Power Connector) This connector (ATX_12V) supplies the CPU operation voltage (Vcore). If this "ATX_12V connector" is not connected, system cannot boot. 2) ATX (ATX Power) AC power cord should only be connected to your power supply unit after ATX power cable and other related devices are firmly connected to the mainboard.
  • Page 14 Im portant Notice: Please connect first hard disk to IDE1 and connect CD-ROM to IDE2. The red stripe of the ribbon cable must be the sam e side with the Pin1. 6) BAT (BATTERY) 8VM533M-RZ Series Motherboard IDE2 IDE1 CAUTION Danger of explosion if battery is incorrectly replaced.
  • Page 15 7) F_PANEL (2 x 10 pins Connector) Please connect the power LED, PC speaker, reset switch and power switch etc of your chassisfront panel to the F_PANEL connector according to the pin assignment below. HD (IDE Hard Disk Active LED) SPK (Speaker Connector) RES (Reset Switch) PW (Soft Power Connector)
  • Page 16 USB cable, incorrect connection between the cable and connector will m ake the device unable to work or even damage it. For optional front USB cable, please contact your local dealer. 8VM533M-RZ Series Motherboard Pin No. Definition...
  • Page 17 12) COMB (COM B Connector) Be careful with the polarity of the COMB connector. Check the pin assignm ent while you connect the COMB cable. Please contact your nearest dealer for optional COMB cable. Pin No. Definition NDCDB- NSINB NSOUTB NDTRB- NDSRB- NRTSB-...
  • Page 18 8VM533M-RZ Series Motherboard - 18 -...
  • Page 19: Chapter 2 Bios Setup

    Chapter 2 BIOS Setup BIOS Setup is an ov erv iew of the BIOS Setup Program. The program that allow s users to modify the basic sy stem configuration. This ty pe of information is stored in battery -backed CM OS RAM so that it retains the Setup information w hen the pow er is turned off.
  • Page 20 • Save & Exit S etup Sav e CMOS v alue settings to CMOS and ex it s etup. • Exit Without S aving Abandon all CM OS v alue changes and ex it s etup. 8VM533M-RZ Series Motherboard - 20 -...
  • Page 21: Standard Cmos Features

    Standard CMOS Features CMOS Setup Ut ility-Co pyright (C) 1984 -2003 Aw ard Soft ware Date (mm:dd :yy) Time (hh:mm :ss) } IDE P rimary M aster } IDE P rimary S lave } IDE S econdary M aster } IDE S econdary Slave Driv e A Driv e B Floppy 3 Mode Su pport...
  • Page 22 Extended Memory The BIOS determines how much ex tended memory is present during the POST. This is the am ount of memory located abov e 1 MB in the CPU 's memory address map. 8VM533M-RZ Series Motherboard - 22 -...
  • Page 23: Advanced Bios Features

    Advanced BIOS Features CMOS Setup Ut ility-Co pyright (C) 1984 -2003 Aw ard Soft ware Firs t Boot D evice Seco nd Boot D evice Thir d Boot D evice Pas sword C heck CPU H yper-Threa ding higf: M ove Enter: Select F5: P revious V alues "...
  • Page 24: Integrated Peripherals

    Disable this option if y ou are not using the onboard U SB 2.0 feature. Enabled Enable USB 2. 0 Controller. (Default v alue) Disabled Disable USB 2. 0 Controller. "*" For 8VM533M-RZ only. 8VM533M-RZ Series Motherboard Inte grated Periphe rals [Enab led] [Enab led]...
  • Page 25 USB Keyboard Support Enabled Enable USB key board support. Disabled Disable USB key board support. (Default v alue) USB Mouse Support Enabled Enable USB mouse support. Disabled Disable USB m ouse support. (Default v alue) Onboard Serial P ort 1 Auto BIOS w ill autom atically s etup the port 1 address.
  • Page 26: Power Management Setup

    Disabled Can't Pow er on sy stem by Mouse Ev ent. (Default v alue) Enabled Can Pow er on sy stem by Mouse Ev ent. 8VM533M-RZ Series Motherboard Powe r Manag ement S etup [S1(P OS)] Disa bled [Instan t-Off]...
  • Page 27: Pnp/Pci Configurations

    PME Event Wake Up When set at Enabled, any PCI-PM ev ent aw akes the sy stem from a PCI-PM controlled state. This feature requires an ATX pow er supply that prov ides at least 1A on the +5VSB lead. Disabled Disable this function.
  • Page 28: Pc Health Status

    Detec t CPU Fan speed status automatic ally . CPU FAN Fail Warning Disabled Fan w arning function disable. (Default v alue) Enabled Fan w arning function enable. 8VM533M-RZ Series Motherboard PC H ealth St atus 1.54V 2.5 44V 3.3 60V 11. 92V 45°...
  • Page 29: Frequency/Voltage Control

    Frequency/Voltage Control CMOS Setup Ut ility-Co pyright (C) 1984 -2003 Aw ard Soft ware CPU Clock R atio Auto Detect PCI/DIMM Clk Spre ad Spec trum CPU Host Cl ock Con trol ø CPU C lock higf: M ove Enter: Select F5: P revious V alues ø...
  • Page 30: Load Fail-Safe Defaults

    F8: Q- Flash Selecting this field loads the factory defaults for BI O S and Chipset Features w hich t h e sy stem automatically detects. 8VM533M-RZ Series Motherboard Load Fail-Sa fe Defa ults Load Optimiz ed Defa ults Set Supervis or Pass word Set U ser Pass word Save &...
  • Page 31: Set Supervisor/User Password

    Set Supervisor/User Password CMOS Setup Ut ility-Co pyright (C) 1984 -2003 Aw ard Soft ware Stan dard CM OS Feat ures Adva nced BI OS Feat ures Inte grated Periphe rals Powe r Manag ement S etup PnP/ PCI Con figurat ions Ente r Passw ord: PC H ealth St atus Frequ ency/Vol tage Con trol...
  • Page 32: Save & Exit Setup

    F8: Q- Flash Ty pe "Y" w ill quit the Setup Utility w ithout sav ing to RTC CMOS. Ty pe "N" w ill return to Setup Utility . 8VM533M-RZ Series Motherboard Load Fail-Sa fe Defa ults Load Optimiz ed Defa ults...
  • Page 33: Chapter 3 Install Drivers

    Revision History Chapter 3 Install Drivers Install Drivers Pictures below are shown in Windows XP (CD ver. 2.3) Insert the driver CD-title that came with your motherboard into your CD-ROM drive, the driver CD-title will auto start and show the installation guide. If not, please double click the CD-ROM device icon in "My computer", and execute the setup.exe.
  • Page 34 Pack. After install Windows Service Pack, it will show a question mark "?" in "Universal Serial Bus controller" under "Device Manager". Please remove the question mark and restart the system (System will auto-detect the right USB2.0 driver). "*" For 8VM533M-RZ only. 8VM533M-RZ Series Motherboard Driver install finished!! you have to reboot system!!
  • Page 35 TEL: +886 (2) 8912-4888 FAX: +886 (2) 8912-4003 Tech. Support : http://tw.giga-byte.com/TechSupport/ServiceCenter.htm Non-Tech. Support (Sales/Marketing) : http://ggts.gigabyte.com.tw/nontech.asp WEB address (English): http://www.gigabyte.com.tw WEB address (Chinese): http://chinese.giga-byte.com — U.S.A. G.B.T. INC. Address: 17358 Railroad St, City of Industry, CA 91748. TEL: +1 (626) 854-9338 FAX: +1 (626) 854-9339 Tech.
  • Page 36 China — NINGBO G.B.T. TECH. TRADING CO., LTD. Tech. Support : http://cn.giga-byte.com/TechSupport/ServiceCenter.htm Non-Tech. Support (Sales/Marketing) : http://ggts.gigabyte.com.tw/nontech.asp WEB address : http://www.gigabyte.com.cn Shanghai TEL: +86-021-63410999 FAX: +86-021-63410100 Beijing TEL: +86-010-82886651 FAX: +86-010-82888013 Wuhan TEL: +86-027-87851061 FAX: +86-027-87851330 GuangZhou TEL: +86-020-87586074 FAX: +86-020-85517843...
