8I845PE-RZ /
8I845PE-RZ-C
Intel
Pentium
4 Processor Motherboard
®
®
User's Manual
Rev. 1002
12ME-I845PERZ-1002
Copyright
© 2004 GIGABYTE TECHNOLOGY CO., LTD
Copyright by GIGA-BYTE TECHNOLOGY CO., LTD. ("GBT"). No part of this manual may be reproduced or transmitted in any from
without the expressed, written permission of GBT.
Trademarks
Third-party brands and names are the property of their respective owners.
Notice
Please do not remove any labels on motherboard, this may void the warranty of this motherboard.
Due to rapid change in technology, some of the specifications might be out of date before publication of this booklet.
The author assumes no responsibility for any errors or omissions that may appear in this document nor does the author make a
commitment to update the information contained herein.
Advertisement
Table of Contents
Related Manuals for Gigabyte 8I845PE-RZ
Summary of Contents for Gigabyte 8I845PE-RZ
- Page 1 User's Manual Rev. 1002 12ME-I845PERZ-1002 Copyright © 2004 GIGABYTE TECHNOLOGY CO., LTD Copyright by GIGA-BYTE TECHNOLOGY CO., LTD. ("GBT"). No part of this manual may be reproduced or transmitted in any from without the expressed, written permission of GBT. Trademarks Third-party brands and names are the property of their respective owners.
-
Page 3: Preparing Your Computer
Preparing Your Computer Computer motherboards and expansion cards contain very delicate Integrated Circuit (IC) chips. To protect them against damage from static electricity, you should follow some precautions whenever you work on your computer. 1. Unplug your computer when working on the inside. -
Page 4: Table Of Contents
Table of Contents Chapter 1 Introduction ... 5 Features Summary ...5 8I845PE-RZ Series Motherboard Layout...6 Block Diagram ...7 Hardware Installation Process ...8 Step 1: Install the Central Processing Unit (CPU) ...8 Step 1-1: CPU Installation ... 9 Step 1-2: CPU Cooling Fan Installation ... 9 Step 2: Install Memory Modules ...10... -
Page 5: Chapter 1 Introduction
(Note 2) A Northwood processor with 800MHz FSB can be supported through overclocking in BIOS. (Note 3) When 800MHz FSB is selected as processor frequency, memory will automatically adjust to DDR400. "*" For 8I845PE-RZ only. Pentium 4 (Northwood, Prescott ®... -
Page 6: 8I845Pe-Rz Series Motherboard Layout
8I845PE-RZ Series Motherboard Layout KB_MS CPU_FAN A TX_12V SUR_CEN F_AU DIO RTL8100C * CODEC AUX_IN CD_I N SPDI F_IO "*" For 8I845PE-RZ only. "#" For 8I845PE-RZ-C only. 8I845PE-RZ Series Motherboard 21 cm SOC KET 478 I ntel 845PE PCI1 CLR_CMOS... -
Page 7: Block Diagram
RJ45 * RTL8100C * AC97 Link AC97 PCICLK CODEC (33MHz) PCICLK (33MHz) USBCLK (48MHz) 14.318 MHz 33 MHz "*" For 8I845PE-RZ only. Pentium 4 CPUCLK+/- (100/133MHz) Socket 478 System Bus 400/533MHz 266/333MHz Intel 845PE GMCHCLK(66MHz) HCLK+/- (100/133MHz) 66MHz 33 MHz 14.318 MHz... -
Page 8: Hardware Installation Process
® Chipset that supports HT Technology - BIOS: A BIOS that supports HT Technology and has it enabled - OS: An operation system that has optim izations for HT Technology 8I845PE-RZ Series Motherboard Step 1 Step 2 Step 4 - 8 -... -
Page 9: Step 1-1: Cpu Installation
Step 1-1: CPU Installation Figure 1. Socket Pull the rod to the 90-degree directly. Actuation Lever Figure 2. Locate Pin 1 in the socket and look for a (golden) cut edge on the CPU upper corner. Insert the CPU into the socket. (Do not force the CPU into the socket.) Then m ove the socket lever to the locked position while holding pressure on the center of the CPU. -
Page 10: Step 2: Install Memory Modules
To install the memory module, just push it vertically into the DIMM socket. The DIM M module can only fit in one direction due to the notch. M emory size can vary between sockets. 8I845PE-RZ Series Motherboard Notch 1. The DIMM socket has a notch, so the DIMM memory module can only fit in one direction. -
Page 11: Step 3: Install Agp Card
This connector supports joystick, M IDI keyboard and other relate audio devices. Line Out jack Connect the stereo speakers or earphone to this connector. Line In jack Devices like CD-ROM , walkm an etc. can be connect to Line In jack. "*" For 8I845PE-RZ only. - 11 - Hardware Installation Process... -
Page 12: Step 4-2: Connectors Introduction
2) ATX 3) CPU_FAN 4) SYS_FAN 5) IDE1 / IDE2 6) FDD 7) PWR_LED 8) F_PANEL 9) F_AUDIO "*" For 8I845PE-RZ only. 8I845PE-RZ Series Motherboard 10) SUR_CEN 11) CD_IN 12) AUX_IN 13) SPDIF_IO 14) CI 15) F_USB1 / F_USB2 16) CLR_CMOS... - Page 13 1) ATX_12V (+12V Power Connector) This connector (ATX_12V) supplies the CPU operation voltage (Vcore). If this "ATX_12V connector" is not connected, system cannot boot. 2) ATX (ATX Power) AC power cord should only be connected to your power supply unit after ATX power cable and other related devices are firmly connected to the mainboard.
- Page 14 Please connect the floppy drive ribbon cables to FDD. It supports 360K, 1.2M, 720K, 1.44M and 2.88M bytes floppy disk types. The red stripe of the ribbon cable must be the sam e side with the Pin1. 8I845PE-RZ Series Motherboard Pin No. Definition...
- Page 15 7) PWR_LED PWR_LED is connect with the system power indicator to indicate whether the system is on/off. It will blink when the system enters suspend mode. If you use dual color LED, power LED will turn to another color. 8) F_PANEL (2 x 10 pins Connector) Please connect the power LED, PC speaker, reset switch and power switch etc of your chassisfront panel to the F_PANEL connector according to the pin assignment below.
- Page 16 10) SUR_CEN (Surround Center Connector) Please contact your nearest dealer for optional SUR_CEN cable. 11) CD_IN (CD In Connector) Connect CD-ROM or DVD-ROM audio out to the connector. 8I845PE-RZ Series Motherboard Pin No. Definition Power Front Audio (R)
- Page 17 12) AUX_IN (AUX In Connector) Connect other device(such as PCI TV Tunner audio out)to the connector. 13) SPDIF_IO (SPDIF In/Out Connector) The SPDIF output is capable of providing digital audio to external speakers or com pressed AC3 data to an external Dolby Digital Decoder. Use this feature only when your stereo system has digital input function.
- Page 18 You may clear the CMOS data to its default values by this jumper. To clear CMOS, temporarily shor 1-2 pin. Default doesn't include the "Shunter" to prevent from im proper use this jumper. 17) BAT (BATTERY) 8I845PE-RZ Series Motherboard Pin No. Definition...
-
Page 19: Chapter 2 Bios Setup
Chapter 2 BIOS Setup BIOS Setup is an overview of the BIOS Setup Program. The program that allows users to modify the basic system configuration. This type of inform ation is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off. ENTERING SETUP Powering ON the com puter and pressing <Del>... - Page 20 Change, set, or disable password. It allows you to lim it access to the system. • Save & Exit Setup Save CMOS value settings to CM OS and exit setup. • Exit Without Saving Abandon all CMOS value changes and exit setup. 8I845PE-RZ Series Motherboard - 20 -...
-
Page 21: Standard Cmos Features
Standard CMOS Features CMOS Setup Utility-Copyright (C) 1984-2004 Award Software Date (mm:dd:yy) Time (hh:mm:ss) } IDE Primary Master } IDE Primary Slave } IDE Secondary Master } IDE Secondary Slave Drive A Drive B Floppy 3 Mode Suport Holt On Base Memory Extended Memory Total Memory... - Page 22 640K for systems with 640K or more memory installed on the motherboard. Extended Memory The BIOS determines how much extended memory is present during the POST. This is the am ount of mem ory located above 1 M B in the CPU's memory address map. 8I845PE-RZ Series Motherboard - 22 -...
-
Page 23: Advanced Bios Features
Advanced BIOS Features CMOS Setup Utility-Copyright (C) 1984-2004 Award Software First Boot Device Second Boot Device Third Boot Device Boot Up Floppy Seek Password Check CPU Hyper-Threading Init Display First higf : Move Enter: Select F5: Previous Values " # " System will detect automatically and show up when you install the Intel processor with HT Technology. -
Page 24: Integrated Peripherals
Set IDE2 Conductor Cable to ATA66/100 (Please make sure your IDE device and cable is com patible with ATA66/100). ATA33 Set IDE2 Conductor Cable to ATA33 (Please make sure your IDE device and cable is compatible with ATA33). "*" For 8I845PE-RZ only. 8I845PE-RZ Series Motherboard Integrated Peripherals [Enabled] [Enabled]... - Page 25 Using Parallel port as Standard Parallel Port. (Default value) Using Parallel port as Enhanced Parallel Port. Using Parallel port as Extended Capabilities Port. ECP+EPP Using Parallel port as ECP & EPP mode. "*" For 8I845PE-RZ only. - 25 - BIOS Setup...
-
Page 26: Power Management Setup
Instant-off Press power button then Power off instantly. (Default value) Delay 4 Sec. Press power button 4 sec to Power off. Enter suspend if button is pressed less than 4 sec. 8I845PE-RZ Series Motherboard Power Management Setup [S1(POS)] [Blinking] [Instant-Off]... - Page 27 PME Event Wake Up Disabled Disable this function. Enabled Enable PM E as wake up event. (Default value) ModemRingOn Disabled Disable Modem Ring on function. Enabled Enable Modem Ring on function. (Default value) Resume by Alarm You can set "Resume by Alarm" item to enabled and key in Date/time to power on system. Disabled Disable this function.
-
Page 28: Pnp/Pci Configurations
3,4,5,7,9,10,11,12,14,15 PCI 2 IRQ Assignment Auto 3,4,5,7,9,10,11,12,14,15 PCI 3 IRQ Assignment Auto 3,4,5,7,9,10,11,12,14,15 PCI 4 IRQ Assignment Auto 3,4,5,7,9,10,11,12,14,15 8I845PE-RZ Series Motherboard PnP/PCI Configurations [Auto] [Auto] [Auto] [Auto] +/-/PU/PD: Value F10: Save ESC: Exit F6: Fail-Save Default F7: Optimized Defaults Auto assign IRQ to PCI 1/PCI 5. -
Page 29: Pc Health Status
PC Health Status CMOS Setup Utility-Copyright (C) 1984-2004 Award Software Reset Case Open Status Case Opened Vcore DDR25V +3.3V +12V Current CPU Temperature Current CPU FAN Speed Current SYSTEM FAN Speed CPU Warning Temperature CPU FAN Fail Warning SYSTEM FAN Fail Warning higf : Move Enter: Select F5: Previous Values... -
Page 30: Frequency/Voltage Control
Incorrect using it may cause your system broken. For power End-User use only! Fixed PCI/AGP Frequency You can choose those mode to adjust PCI/AGP frequency. (Select PCI/AGP frequency asynchronous with CPU frequency). 8I845PE-RZ Series Motherboard Frequency/Voltage Control [15X] [Disabled] Disabled... -
Page 31: Top Performance
Host/DRAM Clock Ratio (Warning: wrong frequency may m ake system can boot, clear CMOS to overcom e wrong frequency issue) for FSB(Front Side Bus) frequency=400MHz, 2.66 Memory Frequency = Host clock X 2.66. Auto Set M em ory frequency by DRAM SPD data. (Default value) for FSB(Front Side Bus) frequency=533MHz, Memory Frequency = Host clock X 2.0. -
Page 32: Load Fail-Safe Defaults
Frequency/Voltage Control ESC: Quit F8: Q-Flash Selecting this field loads the factory defaults for BIOS and Chipset Features which the system autom atically detects. 8I845PE-RZ Series Motherboard Top Performance Load Fail-Safe Defaults Load Optimized Defaults Set Supervisor Password Set User Password Save &... -
Page 33: Set Supervisor/User Password
Set Supervisor/User Password CMOS Setup Utility-Copyright (C) 1984-2004 Award Software Standard CMOS Features Advanced BIOS Features Integrated Peripherals Power Management Setup PnP/PCI Configurations Enter Password: PC Health Status Frequency/Voltage Control ESC: Quit F8: Q-Flash When you select this function, the following message will appear at the center of the screen to assist you in creating a password. -
Page 34: Save & Exit Setup
Frequency/Voltage Control ESC: Quit F8: Q-Flash Type "Y" will quit the Setup Utility without saving to RTC CM OS. Type "N" will return to Setup Utility. 8I845PE-RZ Series Motherboard Top Performance Load Fail-Safe Defaults Load Optimized Defaults Set Supervisor Password... -
Page 35: Chapter 3 Install Drivers
Revision History Chapter 3 Install Drivers Install Drivers Pictures below are shown in Windows XP Insert the driver CD-title that came with your motherboard into your CD-ROM drive, the driver CD-title will auto start and show the installation guide. If not, please double click the CD-ROM device icon in "My computer", and execute the setup.exe. - Page 36 Intel/NEC USB 2.0 Driver It is recommended that you use the Microsoft Windows update for the most updated driver for XP/2K. "*" For 8I845PE-RZ only. 8I845PE-RZ Series Motherboard Driver install finished!! you have to reboot system!! - 36 -...
- Page 37 - 37 - Memo...
- Page 38 8I845PE-RZ Series Motherboard - 38 -...
- Page 39 - 39 - Memo...
- Page 40 8I845PE-RZ Series Motherboard — The Netherlands Giga-Byte Technology B.V. Address: Verdunplein 8 5627 SZ, Eindhoven, The Netherlands Tel: +31 40 290 2088 NL Tech.Support : 0900-GIGABYTE (0900-44422983, BE Tech.Support : 0900-84034 ( 0.4/M) Fax: +31 40 290 2089 Tech. Support: http://nz.giga-byte.com/TechSupport/ServiceCenter.htm Non-Tech.
