- Page 1 User's Manual Rev. 1001 12ME-8S651MPRZ-1001 Copyright © 2003 GIGABYTE TECHNOLOGY CO., LTD Copyright by GIGA-BYTE TECHNOLOGY CO., LTD. ("GBT"). No part of this manual may be reproduced or transmitted in any from without the expressed, written permission of GBT. Trademarks Third-party brands and names are the property of their respective owners.
-
Page 3: Preparing Your Computer
Preparing Your Computer Computer motherboards and expansion cards contain very delicate Integrated Circuit (IC) chips. To protect them against damage from static electricity, you should follow some precautions whenever you work on your computer. 1. Unplug your computer when working on the inside. -
Page 4: Table Of Contents
Table of Content Chapter 1 Introduction ... 5 Features Summary ...5 8S651MP-RZ Series Motherboard Layout ...7 Block Diagram ...8 Hardware Installation Process ...9 Step 1: Install the Central Processing Unit (CPU) ...9 Step 1-1: CPU Installation ...10 Step 1-2: CPU Cooling Fan Installation ...10 Step 2: Install memory modules ... -
Page 5: Chapter 1 Introduction
Chapter 1 Introduction Features Summary Motherboard — 8S651MP-RZ Series: 8S651M P-RZ / 8S651M P-RZ-C — Socket 478 for Intel — Support Intel — Intel Pentium — 2nd cache depends on CPU Chipset — North Bridge:SiS 651 — South Bridge:SiS 962L Memory —... - Page 6 CPU, chipset and most of the peripherals. Whether your system can run under these specific bus frequencies properly will depend on your hardware configurations, including CPU, Chipsets, Mem ory, Cards… .etc. 8S651MP-RZ Series Motherboard - 6 -...
-
Page 7: 8S651Mp-Rz Series Motherboard Layout
KB_MS A TX_12V USB_LAN RTL820 1 F_AU DIO CD_I N SUR_CEN CODEC BIOS SPDI F_IO “ * ” For 8S651MP-RZ only. “ # ” For 8S651MP-RZ-C. 21.5 cm SOC KET478 SiS 651 PCI1 SiS 962L PCI2 PCI3 CLR_CMOS PWR_LE D... -
Page 8: Block Diagram
AC97 PCICLK CODEC (33MHz) PCICLK (33MHz) USBCLK (48MHz) 14.318 MHz 33 MHz “ * ” For 8S651M P-RZ only. 8S651MP-RZ Series Motherboard Pentium 4 CPUCLK+/- (100/133 MHz) Socket 478 System Bus 400/533 MHz 200/266/333MHz SiS 651 ZCLK (66MHz) HCLK+/- (100/133 MHz) -
Page 9: Hardware Installation Process
Hardware Installation Process To set up your computer, you must complete the following steps: Step 1- Install the Central Processing Unit (CPU) Step 2- Install mem ory modules Step 3- Install expansion cards Step 4- Install I/O Peripherals cables Step 4 Step 4 Step 3 Step 1: Install the Central Processing Unit (CPU) -
Page 10: Step 1-1: Cpu Installation
CPU and cooling fan. Figure 2. Fasten the cooling fan supporting-base onto the CPU socket on the motherboard. Figure 3. Make sure the CPU fan is plugged to the CPU fan connector, than install complete. 8S651MP-RZ Series Motherboard - 10 -... -
Page 11: Step 2: Install Memory Modules
Step 2: Install memory modules Before installing the m emory modules, adhere to the following warning: 1. When DIMM LED is ON, do not install / remove DIMM from socket. 2. Please note that the DIMM module can only fit in one direction due to the one notch. Wrong orientation will cause improper installation. -
Page 12: Step 3: Install Expansion Cards
OS vendor for possible patch or driver upgrade. For more inform ation please contact your OS or device(s) vendors. x Parallel port (LPT) Device like printer can be connected to Parallel port. y Serial port (COMA) Mouse and modem etc. can be connected to Serial port. "*" For 8S651MP-RZ only. 8S651MP-RZ Series Motherboard - 12 -... -
Page 13: Step 4-2: Connectors Introduction
z VGA port Monitor can be connected to VGA port. { Game/MIDI port This connector supports joystick, M IDI keyboard and other relate audio devices. | Line Out jack Connect the stereo speakers or earphone to this connector. } Line In jack Devices like CD-ROM , walkm an etc. - Page 14 Please note, a proper installation of the CPU cooler is essential to prevent the CPU from running under abnormal condition or damaged by overheating.The CPU fan connector supports Max. current up to 600 mA. 8S651MP-RZ Series Motherboard Pin No. Definition +12V +12V Pin No.
- Page 15 4) SYS_FAN (System FAN Connector) This connector allows you to link with the cooling fan on the system case to lower the system temperature. 5) IDE1/ IDE2(IDE1/IDE2 Connector) Please connect first harddisk to IDE1 and connect CDROM to IDE2. The red stripe of the ribbon cable must be the same side with the Pin1. 6) FDD (Floppy Connector) Please connect the floppy drive ribbon cables to FDD.
- Page 16 HD (IDE Hard Disk Active LED) SPK (Speaker Connector) RST (Reset Switch) PW (Soft Power Connector) MPD(Message LED/Power/ Sleep LED) 8S651MP-RZ Series Motherboard So ft Pow er Spea ker Co nnector Me ssa g e LED /Po w e r / Conne ctor...
- Page 17 9 ) PWR_LED PWR_LED is connect with the system power indicator to indicate whether the system is on/off. It will blink when the system enters suspend mode. If you use dual color LED, power LED will turn to another color. 10) BAT (Battery) Pin No.
- Page 18 12) SUR_CEN Please contact your nearest dealer for optional SUR_CEN cable. 13) CD_IN Connect CD-ROM or DVD-ROM audio out to the connector. 8S651MP-RZ Series Motherboard Pin No. Definition POWER FrontAudio(R) RearAudio(R)
- Page 19 14) SPDIF_IO (SPDIF In/Out) The SPDIF output is capable of providing digital audio to external speakers or compressed AC3 data to an external Dolby Digital Decoder. Use this feature only when your stereo system has digital input function. Use SPDIF IN feature only when your device has digital output function. Be careful with the polarity of the SPDIF_IO connector.
- Page 20 You may clear the CMOS data to its default values by this jumper. To clear CMOS, temporarily shor 1-2 pin. Default doesn't include the "Shunter" to prevent from im proper use this jumper. 8S651MP-RZ Series Motherboard Pin No. Definition NDCDB-...
-
Page 21: Chapter 2 Bios Setup
Chapter 2 BIOS Setup BIOS Setup is an ov erv iew of the BIOS Setup Program. The program that allow s users to modify the basic sy stem configuration. This ty pe of information is stored in battery -backed CM OS RAM so that it retains the Setup information w hen the pow er is turned off. - Page 22 • Save & Exit S etup Sav e CMOS v alue settings to CMOS and ex it s etup. • Exit Without S aving Abandon all CM OS v alue changes and ex it s etup. 8S651MP-RZ Series Motherboard - 22 -...
-
Page 23: Standard Cmos Features
Standard CMOS Features CMOS Setup Ut ility-Co pyright (C) 1984 -2004 Aw ard Soft ware Date (mm:dd :yy) Time (hh:mm :ss) } IDE P rimary M aster } IDE P rimary S lave } IDE S econdary M aster } IDE S econdary Slave Driv e A Driv e B Flopp y 3 Mode S uport... - Page 24 Extended Memory The BIOS determines how much ex tended memory is present during the POST. This is the am ount of memory located abov e 1 MB in the CPU 's memory address map. 8S651MP-RZ Series Motherboard - 24 -...
-
Page 25: Advanced Bios Features
Advanced BIOS Features CMOS Setup Ut ility-Co pyright (C) 1984 -2004 Aw ard Soft ware First Boot Device Second Boot Device Third Boot Device Boot Up Floppy Seek Password Check higf: M ove Enter: Select F5: P revious V alues First / Second / Third Boot Device Floppy Select y our boot dev ice priority by Floppy . -
Page 26: Integrated Peripherals
Disable onboard 2nd channel IDE port. AC97 Audio Enabled Enable onboard AC'97 audio function. (Default v alue) Disabled Disable this function. "*" F or 8S651MP-RZ only. 8S651MP-RZ Series Motherboard Inte grated Periphe rals [Auto] Item Help [Auto] Menu Level u... - Page 27 Enable onboard LPT port and address is 278/IRQ5. Disabled Disable onboard LPT port. 3BC/IRQ7 Enable onboard LPT port and address is 3BC/IRQ7. "*" F or 8S651MP-RZ only. Set onchip VGA shared memory size.(Def a ult Value:32MB) - 27 - BIOS Setup...
-
Page 28: Power Management Setup
Power LED in S1 state higf: M ove Enter: Select +/-/ PU/PD: V alue F5: P revious V alues F6: Fa il-Save De fault 8S651MP-RZ Series Motherboard Powe r Manag ement S etup [S1(POS)] Item Help [Off] Menu Level u... - Page 29 ACPI Suspend Type S1(POS) Set ACPI suspend ty pe to S1. (Default Value) S3(STR) Set ACPI suspend ty pe to S3. Soft-off by PWR_BTTN The user press the pow er button once, he can turn off the sy stem. (Default Value) Suspend The user press the pow er button once, then the sy stem w ill can enter suspend mode.
-
Page 30: Pnp/Pci Configurations
Auto 3,4,5,7,9,10,11,12,14,15 PCI 2 IRQ Assignment Auto 3,4,5,7,9,10,11,12,14,15 PCI 3 IRQ Assignment Auto 3,4,5,7,9,10,11,12,14,15 8S651MP-RZ Series Motherboard PnP/ PCI Con figurat ions [Au to] [Au to] [Au to] +/-/ PU/PD: V alue F10: Save ESC: Exit F6: Fa il-Save De fault F7: Optimiz ed Defa ults Auto assign IRQ to PCI 1. -
Page 31: Pci Health Status
PCI Health Status CMOS Setup Ut ility-Co pyright (C) 1984 -2004 Aw ard Soft ware Reset Case Open Status Case Opened VCORE +3.3V +12V Current System Temperature Current CPU Temperature Current CPU FAN Speed Current SYSTEM FAN Speed CPU Warning Temperature CPU FAN Fail Warning SYSTEM FAN Fail Warning higf: M ove... -
Page 32: Frequency/Voltage Control
If y ou use DDR200 DRAM module, please set "DRAM Clock(MHz)" to 200. If y ou use DDR333 DRAM module, please set "DRAM Clock(MHz)" to 333. Incorrect using it may cause y our sy stem broken. For pow er End-User use only ! 8S651MP-RZ Series Motherboard Frequ ency/Vol tage Con trol [10X]... -
Page 33: Top Performance
AGP Clock (MHz) Please set AGP Clock according to y our requirement. Incorrect using it may cause y our sy stem broken. For pow er End-User use only ! PCI Clock (MHz) Please set PCI Clock according to y our requirement. Incorrect using it may cause y our sy stem broken. -
Page 34: Load Optimized Defaults
If y ou select "Setup" at "Passw ord Check" in Adv ance BIOS Features Menu, y ou w ill be prompted only w hen y ou try to enter Setup. 8S651MP-RZ Series Motherboard Top Perform ance Load Fail-Sa fe Defa ults... -
Page 35: Save & Exit Setup
Save & Exit Setup CMOS Setup Ut ility-Co pyright (C) 1984 -2004 Aw ard Soft ware Stan dard CM OS Feat ures Adva nced BI OS Feat ures Inte grated Periphe rals Powe r Manag ement S etup PnP/ PCI Con figurat ions PC H ealth St atus Frequ ency/Vol tage Con trol ESC: Quit... -
Page 36: Chapter 3 Driver Installation
"GO" button. The by itself. We recommend that you install all components in the list. 8S651MP-RZ Series Motherboard to install the drivers automatically. Massage: Some device drivers will restart your system automatically. After restarting your system the "Xpress Install"... - Page 37 USB2.0 driver for Windows 98 and Windows ME, we will ® put the driver on GIGABYTE website asap. (http://www.gigabyte.com.tw). For USB2.0 driver support under Windows XP operating system, please use Windows Service Pack. After install Windows Service Pack, it will show a question mark "?" in "Universal Serial Bus controller"...
- Page 38 8S651MP-RZ Series Motherboard - 38 -...
- Page 39 - 39 - Driver Installation...
- Page 40 8S651MP-RZ Series Motherboard The Netherlands Giga-Byte Technology B.V. Address: Verdunplein 8 5627 SZ, Eindhoven, The Netherlands Tel: +31 40 290 2088 NL Tech.Support : 0900-GIGABYTE (0900-44422983, 0.2/M) BE Tech.Support : 0900-84034 ( 0.4/M) Fax: +31 40 290 2089 Tech. Support: http://nz.giga-byte.com/TechSupport/ServiceCenter.htm Non-Tech.
