Mini Digital ClaMp Meter
asseMbly anD OperatiOn instruCtiOns
Due to continuing improvements, actual product may differ slightly from the product described herein.
Visit our website at: http://www.harborfreight.com
tO preVent seriOus injury, reaD anD unDerstanD
all warnings anD instruCtiOns befOre use.
©
Copyright
2007 by Harbor Freight Tools
this manual or any artwork contained herein may be reproduced in any shape
or form without the express written consent of Harbor Freight Tools.
for technical questions or replacement parts, please call 1-800-444-3353.
Model
3491 Mission Oaks Blvd., Camarillo, CA 93011
96308
®
. All rights reserved. No portion of
®
Advertisement
Table of Contents
Related Manuals for Harbor Freight Tools CEN-TECH 96308
Summary of Contents for Harbor Freight Tools CEN-TECH 96308
- Page 1 . All rights reserved. No portion of this manual or any artwork contained herein may be reproduced in any shape or form without the express written consent of Harbor Freight Tools. for technical questions or replacement parts, please call 1-800-444-3353.
-
Page 2: Specifications
speCifiCatiOns 120 VAC / 220 VAC Continuity Check Volts DC Voltage Check AC Voltage Functions Measuring Resistance Continuity Measurement Diode Measurement Data Hold LCD maximum reading 1999 Display Over range Indicator Low Battery Indicator Maximum Capacity 1” Conductor 36” Long Red and Black with 90° Banana Plugs and 5/8” Nail Test Leads Points AC Volts: ±... -
Page 3: Electrical Safety
Do not operate electrical tools in explosive atmospheres, such as in the presence of flammable liquids, gases, or dust. Power tools may create sparks which may ignite the dust or fumes. keep bystanders, children, and visitors away while operating or testing electrical equipment or leads. -
Page 4: Specific Safety Rules
Maintain labels and nameplates on the tool. These carry important information. If unreadable or missing, contact Harbor Freight Tools for a replacement. Maintain a safe working environment. Make sure there is adequate surrounding workspace. Do not use this product in a damp or wet location. - Page 5 fault interrupt (GFCI) system is also a good precaution. This inexpensive device is a good safety measure because it prevents a sustained electrical shock. • Properly maintain and inspect all tools before use to avoid electrical shock. grOunDing warning! improperly connecting the grounding wire can result in the risk of electric shock.
- Page 6 When unpacking, check to make sure that the item is intact and undamaged. If any parts are missing or broken, please call Harbor Freight Tools at the number shown on the cover of this manual as soon as possible.
- Page 7 rotary switch. Used to select desired function and range. Also used to turn meter ON and OFF. “Hold” button. Pressing the Hold button will hold the current reading on the LCD screen. The word “HOLD” will also appear on the screen. Pressing the Hold button again will release the reading and the word “HOLD”...
- Page 8 Set the Rotary Switch to the “300V~” position. Connect the Red Test Lead to the hot source or load to be measured, and the Black Test Lead to the neutral source to be measured. Read the voltage value (VAC) on the LCD Display Screen. Measuring aC Current Set the Rotary Switch to the desired AC current range.
-
Page 9: Inspection, Maintenance, And Cleaning
Set the Rotary Switch to the diode position. Connect the Red Test Lead to the anode of the diode, connect the Black Test Lead to the cathode of the diode. Read the approximate forward voltage on the LCD Display Screen. NOTE: The reading units are “mV”. -
Page 10: Limited 90-Day Warranty
90 Day warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
