Bauknecht BK6IB10BS7LA0 Quick Manual

Quick Guide
THANK YOU FOR BUYING A BAUKNECHT PRODUCT.
In order to receive a more complete assistance, please
register your appliance on: www.bauknecht.eu/register
Before using the appliance carefully read Safety and Installation Instructions.
After installation, please remember to remove all transport protection parts from
the dishwasher.
CONTROL PANEL
1. ON-OFF/Reset button with indicator light
2. Program selection button
3. Salt refill indicator light
4. Rinse Aid refill indicator light
5. Program number and delay time indicator
6. Tablet indicator light
7. Display
8. Multizone indicator lights
FIRST TIME USE
FILLING THE SALT RESERVOIR
The use of salt prevents the formation of LIMESCALE on the dishes and on
the machine's functional components.
• It is mandatory that the salt reservoir never be empty.
• It is important to set the water hardness.
The salt reservoir is located in the lower part of the dishwasher and must be
filled when the SALT REFILL indicator light
1. Remove the lower rack and unscrew the reservoir cap
(anticlockwise).
2. Only the first time you do this: fill the salt reservoir
with water.
3. Position the funnel (see figure) and fill the salt reservoir
right up to its edge (approximately 1 kg); it is not unu-
sual for a little water to leak out.
4. Remove the funnel and wipe any salt residue away from the opening.
Make sure the cap is screwed on tightly, so that no detergent can get into
the container during the wash program (this could damage the water sof-
tener beyond repair).
Whenever you need to add salt, it is mandatory to complete the pro-
cedure before the beginning of the washing cycle to avoid corrosion.
WATER SOFTENING SYSTEM
Water softener automatically reduces water hardness, consequently prevent-
ing scale buildup on heater, contributing also to better cleaning efficiency.
PROGRAMS TABLE
Eco 50°- Program is suitable to clean normally soiled tableware,
that for this use, it is the most efficient programme in terms of its
1.
combined energy and water consumption, and that it is used to
assess compliance with the EU Ecodesign legislation.
Intensive 65° - Program recommended for heavily soiled crock-
2.
ery, especially suitable for pans and saucepans.
Sensor 50-60°- For normally soiled dishes with dried food res-
3. idues. Senses the level of soiling on the dishes and adjusts the
program accordingly.
Fast Wash&Dry 50° - Normally soiled crockery. Everyday cycle, that
4.
ensures optimal cleaning and drying performance in shorter time.
Glass 45° - Program for delicate items, which are more sensitive to
5.
high temperatures, for example glasses and cups.
Rapid 30' 45° - Program to be used for half load of lightly-soiled
6.
dishes with no dried food residues. Without drying.
Silent 50° - Suitable for night-time operation of the appliance.
7.
With the lowest noise.
Hygiene 65° - Normally or heavily soiled crockery, with addition-
8.
al antibacterial wash. Can be used to perform maintenance of
the dishwasher.
Prewash - Use to refresh crockery planned to be washed later.
9.
No detergent to be used with this program.
9. Multizone button
10. Delay button
11. Extra Dry button with
indicator light
12. Power Clean® button
with indicator light
13. START/Pause button with indicator light / Tablet (Tab)
in the control panel is lit.
Programs description
PLEASE SCAN THE
QR CODE ON YOUR
APPLIANCE IN
ORDER TO HAVE
MORE DETAILED
INFORMATION
1 2 3 4 5 6 7 8
More information in the Daily Reference Guide on website.
This system regenerates itself with salt, therefore it is required to refill
salt container when empty.
Frequency of regeneration depends on water hardness level setting - regen-
eration takes place once per 6 Eco cycles with water hardness level set to 3.
Regeneration process starts in final rinse and finishes in drying phase, be-
fore cycle ends.
• Single regeneration consumes: ~3.5L of water;
• Takes up to 5 additional minutes for the cycle;
• Consumes below 0.005kWh of energy.
FILLING THE RINSE AID DISPENSER
Rinse aid makes dish DRYING easier. The rinse aid
dispenser A should be filled when the RINSE AID
D
REFILL indicator light
C
NEVER pour the rinse aid directly into the appli-
ance tub.
A
FILLING THE DETERGENT DISPENSER
To open the detergent dispenser use the opening device C. Introduce the
detergent into the dry dispenser D only. Place the amount of detergent for
pre-washing directly inside the tub. If all-in-one detergents are used, we
recommend using the TABLET button, because it adjusts the program so
that the best washing and drying results are always achieved.
Usage of detergent not designed for dishwashers may cause malfunc-
tion or damage to the appliance.
Available options
-
-
- -
9 10 11 12
in the control panel is lit.
Duration
Water
of wash
*) consumption
program
(litres/cycle)
(h:min) **)
3:35 8.7
2:45 17.5
1:20 - 3:00 7.0 - 14.0
1.25 11.5
1:40 12.0
0:30 9.0
3:30 16.0
1.50 12.0
0:10 4.5
EN
13
Energy
consumption
(kWh/cycle)
0.51
1.60
0.70 - 1.10
1.10
1.20
0.50
1.15
1.30
0.01
1
