DAILY REFERENCE
GUIDE
THANK YOU FOR BUYING A BAUKNECHT PRODUCT.
In order to receive a more complete assistance, please
register your appliance on:
www.bauknecht.eu/register
Before using the appliance carefully read Health and Safety guide.
PRODUCT DESCRIPTION
APPLIANCE
1
4
7
8
10
12
Service:
0000 000 00000
13
CONTROL PANEL
1
1. On-Off/Reset button with indicator light
2. Program selection button with indicator light
3. Multizone button with indicator light / Key lock
4. Eco program indicator light
5. Key lock indicator light
6. Display
7. Program number and remaining time indicator
2
3
4
5
6 7
You can download the Safety Instructions and the Use
and Care Guide, by visiting our website
docs.bauknecht.eu and following the Instructions on
the back of this booklet.
2
1.Upper rack
2. Cutlery rack
3
3.Foldable flaps
4.Upper rack height adjuster
5.Upper spray arm
6.Lower rack
7.Space Zone
5
8.Lower spray arm
9.Filter Assembly
6
10.Salt reservoir
11.Detergent and Rinse Aid dispensers
9
12.Rating plate
13.Control panel
11
8
9
1011
12
13
8. Tablet (Tab) indicator light
9. Closed water tap indicator light
10. Rinse Aid refill indicator light
11. Salt refill indicator light
12. Power Clean button with indicator light / Tablet (Tab)
13. Delay button with indicator light
14. Start/Pause button with indicator light / Drain out
EN
14
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BFC 3C26 PF A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bauknecht BFC 3C26 PF A

Summary of Contents for Bauknecht BFC 3C26 PF A

  • Page 1 DAILY REFERENCE GUIDE THANK YOU FOR BUYING A BAUKNECHT PRODUCT. You can download the Safety Instructions and the Use In order to receive a more complete assistance, please and Care Guide, by visiting our website register your appliance on: docs.bauknecht.eu and following the Instructions on www.bauknecht.eu/register...

  • Page 2: First Time Use

    FIRST TIME USE SALT, RINSE AID AND DETERGENT ADVICE REGARDING THE FIRST TIME USE FILLING THE RINSE AID DISPENSER After installation, remove the stoppers from the racks and the retaining Rinse aid makes dish DRYING easier. The rinse aid dispenser A should elastic elements from the upper rack.

  • Page 3: Programs Table

    PROGRAMS TABLE Detergent Duration of Water Energy container Program Available options wash program consumption consumption (h:min) (litres/cycle) (kWh/cycle) 50° 3:40 0,93 Sensor 50-60° 01:25 - 3:00 7 - 14 0,9 - 1,40 Intensive 65° 2:50 1,60 Daily 50° 1:30 1,15 Silent 50°...

  • Page 4: Multi Zone

    OPTIONS AND FUNCTIONS OPTIONS can be selected directly by pressing the corresponding TABLET (Tab) button (see CONTROL PANEL). This setting allows you to optimize the performance of the program according to the type of detergent used. If an option is not compatible with the selected program see Press the POWER CLEAN button for 3 seconds (the PROGRAMS TABLE, the corresponding LED flashes rapidly 3 times corresponding symbol will light up) if you use combined...

  • Page 5: Daily Use

    DAILY USE 1. CHECK WATER CONNECTION MODIFYING A RUNNING PROGRAM Check that the dishwasher is connected to the water supply and If a wrong program was selected, it is possible to change it, provided that the top is open. that it has only just begun: press and hold the ON/OFF button, the 2.

  • Page 6: Loading The Racks

    LOADING THE RACKS CUTLERY RACK FOLDABLE FLAPS WITH ADJUSTABLE POSITION The side foldable flaps can be positioned at The third rack was designed to three different heights to optimize the house the cutlery. arrangement of crockery inside the rack. Arrange the cutlery as shown in Wine glasses can be placed safely in the the figure.

  • Page 7: Care And Maintenance

    CARE AND MAINTENANCE CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS Regularly clean the filter assembly so that the filters do not clog and On occasions, food residue may become encrusted onto the spray arms that the waste water flows away correctly. and block the holes used to spray the water.

  • Page 8: Troubleshooting

    • After-Sales Service; phone number see in warranty booklet. right side inside the door of the • download from website: docs.bauknecht.eu dishwasher. The phone number is listed • use QR code in the warranty booklet or on the website: IEC 436 www.bauknecht.eu...
