SKU# 1001 668 048
Model #LWA1b075GL-PZR
USE AND CARE GUIDE
4FT.MULTI-LUMEN LED MOTION
SENSING COLOUR CHANGING WRAP LIGHT
Questions, problems, missing parts? Before returning to the store,
call Commercial Electric Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-877-527-0313
HOMEDEPOT.CA
THANK YOU
We appreciate the trust and con dence you have placed in Commercial Electric through the purchase of this LED Motion Sensing Colour
Changing Wrap Light. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line
of products available for your home improvement needs. Thank you for choosing Commercial Electric!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LWA1b075GL-PZR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Commercial Electric LWA1b075GL-PZR

  • Page 1 THANK YOU We appreciate the trust and con dence you have placed in Commercial Electric through the purchase of this LED Motion Sensing Colour Changing Wrap Light. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line...
  • Page 2: Safety Information

    Safety Information For your safety, always remember to: CAUTION: Turn off the main power at the circuit breaker □ Turn off the power supply at the fuse or circuit breaker box before installing the fixture, in order to prevent possible shock. before you install the xture.
  • Page 3: Installation

    Installation Preparing to mount housing to the ceiling □ Turn OFF the main power at the circuit breaker before the installation. □ Locate the electric power supply junction box that is being used for this installation. □ Ensure that the center knock out on the housing (B) will be aligned with the junction box. □...
  • Page 4: Installing The Housing

    Installation(continued) Accessing the Wires □ Once the diffuser is removed, disconnect the sensor terminal as shown bleow. Figure 1. □ Locate the metal terminal cover split into two parts in the middle of the housing. Figure 2. □ Start by removing the metal cover on the opposite side of the motion sensor that covers the LED Driver, by pushing down and pulling it apart from the center, then lift on the end closest to the end cap.
  • Page 5: Connecting The Wires

    Installation(continued) Connecting the wires □ Identify the wiring located inside of the housing: (black – line voltage, white – neutral, green – ground, and 0-10V dimming wires, purple – Dim (+) and pink – Dim (-) Figure 1. □ Feed the wires from the housing through the center knock out and. □...
  • Page 6 Installation(continued) Linking feature □ Follow above all steps for one xture to receive direct wire power. Only follow the step 1,2,4,7 to install other linkable xtures to receive power through the linking cable. □ Remove the silicone stopper from the side of the housing. □...
  • Page 7: Care And Cleaning

    Check the wire connections. breaker is tripped when turning Contact a quali ed electrician or call power wire is ground out. on the light. Commercial Electric customer service at 1-877-527-0313. Light Distribution Input Volts (AC) Input Frequency (Hz) Input Watts (W) 120-277V...
  • Page 8 Questions, problems, missing parts? Before returning to the store, call Commercial Electric Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-877-527-0313 HOMEDEPOT.CA Retain this manual for future use.
  • Page 9 HOMEDEPOT.CA MERCI Nous apprécions la con ance que vous avez placée en Commercial Electric en achetant ce support plat de panneau LED. Nous nous efforçons de créer continuellement des produits de qualité conçus pour améliorer votre maison. Visitez-nous en ligne pour voir notre gamme complète de produits disponibles pour vos besoins de rénovation pour la...
  • Page 10: Consignes De Sécurité

    Consignes de sécurité Pour votre sécurité, n'oubliez pas de: ATTENTION: Fermez le disjoncteur principal avant d'installer □ Couper l'alimentation électrique au niveau des fusibles ou le luminaire a n de prévenir tout choc électrique. disjoncteurs avant d'installer le luminaire. □ Mettez l'appareil à...
  • Page 11 Installation Préparation de la xation du boîtier au plafond □ Coupez l'alimentation principale au niveau du disjoncteur avant l'installation. □ Localisez la boîte de jonction de l'alimentation électrique qui est utilisée pour cette installation. □ Assurez-vous que le trou central du boîtier (B) sera aligné avec la boîte de jonction. □...
  • Page 12: Installation Du Boîtier

    Installation(continued) Accès aux ls □ Une fois le diffuseur retiré, débranchez la borne du capteur comme indiqué ci-dessous. Figure 1. □ Repérez le cache-bornes métallique divisé en deux parties au milieu du boîtier. Figure 2. □ Commencez par retirer le couvercle métallique du côté opposé au capteur de mouvement qui recouvre le driver LED, en le poussant vers le bas et en le tirant à...
  • Page 13 Installation(continued) Connecter les ls □ Identi ez le câblage situé à l'intérieur du boîtier : (noir - tension de ligne, blanc - neutre, vert - terre, et ls de gradation 0-10V, violet - Dim (+) et rose - Dim (-) Figure 1. □...
  • Page 14 Installation(continued) Fonction de liaison □ Suivez toutes les étapes ci-dessus pour qu'un luminaire soit alimenté par l direct. Ne suivez que les étapes 1, 2, 4 et 7 pour installer d'autres luminaires connectables qui seront alimentés par le câble de connexion. □...
  • Page 15: Entretien Et Nettoyage

    à la terre. Communiquez avec un électricien quali é ou appelez lors de l'allumage de la lumière. le service à la clientèle de Commercial Electric au 1-877-527-0313. Distribution de la lumière Volts d'entrée (AC) Fréquence d'entrée (Hz) Puissance d'entrée (W)
  • Page 16 Pour toutes vos questions, problèmes, pièces manquantes ? Avant de retourner au magasin, appelez le service client de Commercial Electric. De 8 h à 19 h, EST, du lundi au vendredi, de 9 h à 18 h, EST, Samedi. 1-877-527-0313 HOMEDEPOT.CA...
