MODEL G0600Z
20" X 60" 3-PHASE BIG
BORE METAL LATHE
MANUAL INSERT
For Machines Mfd. Since 09/24
and Owner's Manual Revised 05/15
The Model G0600Z is the same machine as the Model G0600 except for a different tailstock. The Model
G0600Z also has an added X- and Z-axis digital readout, chuck guard, and leadscrew cover. Except for
the differences noted in this insert, all other content in the Model G0600 owner's manual applies to this
machine.
: To reduce the risk of serious injury, you MUST read and understand this insert, the
entire Model G0600 manual, and the GL LCD digital readout manual, BEFORE assembling, install-
ing, or operating this machine!
If you have any further questions about this manual insert or the differences between the Model G0600Z and
the Model G0600, contact our Technical Support at (570) 546-9663 or email techsupport@grizzly.com.
COPYRIGHT © MARCH, 2025 BY GRIZZLY INDUSTRIAL, INC.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
#CS23367 PRINTED IN CHINA
***Keep for Future Reference***

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G0600Z and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Grizzly G0600Z

  • Page 1 Owner's Manual Revised 05/15 The Model G0600Z is the same machine as the Model G0600 except for a different tailstock. The Model G0600Z also has an added X- and Z-axis digital readout, chuck guard, and leadscrew cover. Except for the differences noted in this insert, all other content in the Model G0600 owner's manual applies to this machine.
  • Page 2: Machine Data Sheet

    MACHINE DATA SHEET Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901 MODEL G0600Z 20" X 60" 3-PHASE BIG BORE METAL LATHE Product Dimensions: Weight................................5071 lbs. Width (side-to-side) x Depth (front-to-back) x Height..............111 x 46-1/2 x 65 in.
  • Page 3 The information contained herein is deemed accurate as of 3/26/2025 and represents our most recent product specifications. Model G0600Z PAGE 2 OF 3 Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased. Model G0600Z (Mfd. Since 09/24)
  • Page 4 Stand..............................Cast Iron Paint Type/Finish............................Epoxy Fluid Capacities Headstock Capacity..........................12.7 qt. Headstock Fluid Type............... ISO 32 (e.g. Grizzly T23963, Mobil DTE Light) Gearbox Capacity............................. 7.0 qt. Gearbox Fluid Type..............ISO 68 (e.g. Grizzly T23962 Mobile Vactra 2) Apron Capacity............................2.8 qt.
  • Page 5 3-Jaw, 4-Jaw Chuck Key ......1 Ea. G. 4-Jaw Chuck 13 ⁄ " ........1 H. Quick Change Tool Holders ....... 4 Figure 1. Major inventory. D1-8 Camlock Studs........6 Cast Iron Foot Pads ........6 Model G0600Z (Mfd. Since 09/24)
  • Page 6 AA. Gap Pin Puller ..........1 AB. GL LCD DRO Manual (Not Shown) .... 1 Figure 2. Tool box inventory. Fastener Inventory (Not Shown) AC. Cap Screws M6-1 x 20 ....... 3 AD. Cap Screw M8-1.25 X 16 ......1 Model G0600Z (Mfd. Since 09/24)
  • Page 7: Site Considerations

    Shadows, glare, or strobe effects that may distract access restricted location. or impede the operator must be eliminated. Electrical " for Maintenance Wall = Min. 30 Connection 128" 46½" Lathe Keep Workpiece Loading Area Unobstructed 111" Figure 3. Minimum working clearances. Model G0600Z (Mfd. Since 09/24)
  • Page 8 1L1 & 1L2 Tools Needed Wires Phillips Head Screwdriver #2 ......1 To change motor rotation direction: Figure 5. Location of 1L1 and 1L2 incoming DISCONNECT MACHINE FROM POWER! power wires. Install main electrical box cover. Model G0600Z (Mfd. Since 09/24)
  • Page 9: Positioning Tailstock

    Slide tailstock to desired position. Push tailstock lock lever down to lock tailstock in place. The tailstock (see Figure 6) of the Model G0600Z can be used to support workpiece with the use Adjusting Tailstock Quill of a live or dead center. It can drill or bore holes...
  • Page 10 Remove retaining ring from center spindle 57T Gear (see Figure 9). 66T Gear Figure 10. Spindle and center gear assembly. Remove (3) M6-1 x 25 cap screws holding 57T and 66T gears together (see Figure 9). -10- Model G0600Z (Mfd. Since 09/24)
  • Page 11 Spindle Figure 12. Shoulder washer positioning. 11. Remove upper spindle cap screw, lock wash- er, spacer washer, 48T gear, and spacer (see Figure 14. Center gear and spindle installed. Figure 9 on Page 10). -11- Model G0600Z (Mfd. Since 09/24)
  • Page 12 17. Confirm gear arrangement matches (V) mode Figure 16. Threading chart. arrangement shown in Figure 16. 18. Close side cover and refer to Figure 16 for how to shift lathe to appropriate feed and thread pitch. -12- Model G0600Z (Mfd. Since 09/24)
  • Page 13: Cleaning & Protecting

    Protecting To reduce risk of shock or accidental startup, always disconnect machine from Cleaning the Model G0600Z is relatively easy. power before adjustments, Clean the machine every day or more often as maintenance, or service. needed, removing chips as they accumulate. Wet...
  • Page 14 Drain Fill Plug Plug Figure 20. Example of accessing quick change gearbox fill and drain plugs. Drain Plug Figure 18. Location of headstock gearbox fill and drain plugs. -14- Model G0600Z (Mfd. Since 09/24)
  • Page 15 Lubricate the guides once before and once after using the lathe. If the lathe is in an environment that has high moisture or is very dirty, increase the lubrication interval. Leadscrew (Behind Leadscrew Cover) Figure 23. Leadscrew lubrication components. -15- Model G0600Z (Mfd. Since 09/24)
  • Page 16: Ball Oilers

    20W non-detergent oil, ISO 68, or an equivalent machine oil. Figure 26. Cross slide leadscrew end ball oiler location. Figure 24. Apron and slide ball oiler locations. Figure 27. Tailstock ball oiler locations. Figure 25. Cross slide ball oiler location. -16- Model G0600Z (Mfd. Since 09/24)
  • Page 17 BIOLOGICAL & POISON HAZARD! Use personal protec- tion equipment when Pump Switch handling cutting fluid. Follow federal, state, and cutting fluid manu- facturer requirements Figure 29. Location of pump switch. for proper disposal. Install access cover. -17- Model G0600Z (Mfd. Since 09/24)
  • Page 18: Troubleshooting

    2. Thermal overload relay has tripped. 2. Reset relay. 3. Wiring broken, disconnected, or corroded. 3. Fix broken wires or disconnected/corroded connections (Page 23). 4. Motor or motor bearings at fault. 4. Replace motor. -18- Model G0600Z (Mfd. Since 09/24)
  • Page 19: Operation

    G0600 owner's manual) and feed rate (Page 38 in Model G0600 owner's manual). 4. Cutting tool dull. 4. Replace or sharpen cutting tool. 5. Gibs out of adjustment. 5. Adjust gibs (Page 61 in Model G0600 owner's manual). -19- Model G0600Z (Mfd. Since 09/24)
  • Page 20 6. Machine undersized for task. 6. Use sharp cutting tool at correct angle; reduce feed rate/depth of cut; use cutting fluid if possible. 7. Gearbox at fault. 7. Select appropriate gear ratio; replace broken or slipping gears. -20- Model G0600Z (Mfd. Since 09/24)
  • Page 21 5. Leak in distribution manifold located inside 5. Locate leak and seal/replace affected components. headstock. 6. Gearbox at fault. 6. Select appropriate gear ratio; replace broken or slipping gears. 7. Pump at fault. 7. Replace/repair pump. -21- Model G0600Z (Mfd. Since 09/24)
  • Page 22: Halfnut Adjustment

    This slightly pre-loads the gib. Tighten the jam nuts without moving the gib screws to secure the setting. Figure 30. Location of thread dial assembly and cap screw. -22- Model G0600Z (Mfd. Since 09/24)
  • Page 23: Wiring Safety Instructions

    EXPERIENCING DIFFICULTIES. If you are expe- the requirements at the beginning of this manual riencing difficulties understanding the information when connecting your machine to a power source. included in this section, contact our Technical Support at (570) 546-9663. -23- Model G0600Z (Mfd. Since 09/24)
  • Page 24 SA2: Coolant Pump Switch SQ4: Brake Switch KM3:Coolant Pump Contactor SB1: Emergency Stop Button SQ5: Chuck Guard Safety Switch KM4: Control Circuit Contactor SB2: Jog Switch DRO: Digitial Readout & Sensors READ ELECTRICAL SAFETY -24- Model G0600Z (Mfd. Since 09/24) ON PAGE 23!
  • Page 25: Control Panel

    Jog Switch (SB2) Emergency Stop Button (SB1) Power ON/OFF Switch (SA1) Power Lamp (XD) Coolant Pump Switch (SA2) Figure 32. Control panel controls. Figure 33. Control panel wiring. READ ELECTRICAL SAFETY -25- Model G0600Z (Mfd. Since 09/24) ON PAGE 23!
  • Page 26 Circuit Breaker Contactor Breakers Terminal (QM1) (KM4) (QM4 & QM5) Block Figure 34. Electrical box wiring. Figure 35. Main motor wiring (M1). Figure 36. Coolant pump wiring (M2). READ ELECTRICAL SAFETY -26- Model G0600Z (Mfd. Since 09/24) ON PAGE 23!
  • Page 27 Figure 38. Spindle rotation switches (SQ1, Figure 41. Chuck guard safety switch wiring SQ2). (SQ5). Figure 42. Work lamp and work lamp switch Figure 39. Gear cover safety switch (SQ3). wiring (HD). READ ELECTRICAL SAFETY -27- Model G0600Z (Mfd. Since 09/24) ON PAGE 23!
  • Page 28: Digital Readout

    Digital Readout Figure 43. Digital readout wiring (DRO). Figure 44. X-axis sensor (DRO). Figure 45. Z-axis sensor (DRO). READ ELECTRICAL SAFETY -28- Model G0600Z (Mfd. Since 09/24) ON PAGE 23!
  • Page 29: Stand & Bed

    PARTS We do our best to stock replacement parts when possible, but we cannot guarantee that all parts shown are available for purchase. Call (800) 523-4777 or visit www.grizzly.com/parts to check for availability. Stand & Bed 49 50 327-1 327-2...
  • Page 30 AUTO STOP ROD BRACKET RIGHT P0600Z0053 FILL PLUG M16-2 P0600Z0108 INDICATOR PLATE P0600Z0054 STOP PIN M12 X 50 SLOTTED P0600Z0109 CAP SCREW M8-1.25 X 12 -30- BUY PARTS ONLINE AT GRIZZLY.COM! Model G0600Z (Mfd. Since 09/24) Scan QR code to visit our Parts Store.
  • Page 31 CABINET COVER P0600Z0447 GEAR COVER SWITCH CORD 18G 2W 51" P0600Z0305 STRAIN RELIEF M24-1.5 P0600Z0448 MAIN MOTOR CORD 12G 4W 43" -31- BUY PARTS ONLINE AT GRIZZLY.COM! Model G0600Z (Mfd. Since 09/24) Scan QR code to visit our Parts Store.
  • Page 32 1022 1207 1011 1010 1021 1023 1220 1001 1204 1002 1201 1003 1202 1203 1027 1009 1005 1004 1006 1007 1008 -32- BUY PARTS ONLINE AT GRIZZLY.COM! Model G0600Z (Mfd. Since 09/24) Scan QR code to visit our Parts Store.
  • Page 33: Headstock Parts List

    1179 P0600Z1179 SET SCREW M6-1 X 12 KNURLED-PT 1220 P0600Z1220 CHUCK GUARD SWITCH CORD 18G 2W 79" 1180 P0600Z1180 SET SCREW M8-1.25 X 16 KNURLED-PT -33- BUY PARTS ONLINE AT GRIZZLY.COM! Model G0600Z (Mfd. Since 09/24) Scan QR code to visit our Parts Store.
  • Page 34 Gear Shafts A–C: See Pages 35–36 D–G: See Page 37 Shifting Levers I–V: See Pages 38–39 Ⅴ Ⅳ Ⅱ Ⅲ Ⅰ -34- BUY PARTS ONLINE AT GRIZZLY.COM! Model G0600Z (Mfd. Since 09/24) Scan QR code to visit our Parts Store.
  • Page 35 2078 2089 2089 2079 2079 2076 2076 2087 2087 2085 2085 2081 2082 2081 2082 2077 2077 2075 2075 2080 2080 -35- BUY PARTS ONLINE AT GRIZZLY.COM! Model G0600Z (Mfd. Since 09/24) Scan QR code to visit our Parts Store.
  • Page 36 CAM LOCK STUD D1-8 2063 P0600Z2063 EXT RETAINING RING 38MM 2102 P0600Z2102 CAP SCREW M8-1.25 X 16 DOG-PT 2064 P0600Z2064 EXT RETAINING RING 52MM -36- BUY PARTS ONLINE AT GRIZZLY.COM! Model G0600Z (Mfd. Since 09/24) Scan QR code to visit our Parts Store.
  • Page 37 KEY 6 X 6 X 28 RE 3111 P0600Z3111 SHAFT 11" D 3129 P0600Z3129 KEY 8 X 8 X 36 RE 3112 P0600Z3112 GEAR 36T -37- BUY PARTS ONLINE AT GRIZZLY.COM! Model G0600Z (Mfd. Since 09/24) Scan QR code to visit our Parts Store.
  • Page 38 4137 4134 4133 4137 4140 4143 4147 4141 4135 4139 4136 4139 4146 4137 4145 4138 4144 4140 4142 4139 4141 -38- BUY PARTS ONLINE AT GRIZZLY.COM! Model G0600Z (Mfd. Since 09/24) Scan QR code to visit our Parts Store.
  • Page 39 4173 P0600Z4173 FORK V 4151 P0600Z4151 LEVER HUB 4174 P0600Z4174 CONNECTING ROD V 4152 P0600Z4152 PLUG 20MM 4175 P0600Z4175 GEAR 31T MN2 -39- BUY PARTS ONLINE AT GRIZZLY.COM! Model G0600Z (Mfd. Since 09/24) Scan QR code to visit our Parts Store.
  • Page 40: Quick Change Gearbox

    5132 P0600Z5132 TAPER PIN W/INT THREADS 8 X 50 5124 P0600Z5124 COVER FRONT 5133 P0600Z5133 CAP SCREW M10-1.5 X 45 5125 P0600Z5125 SET SCREW M8-1.25 X 35 CONE-PT -40- BUY PARTS ONLINE AT GRIZZLY.COM! Model G0600Z (Mfd. Since 09/24) Scan QR code to visit our Parts Store.
  • Page 41 Quick Change Gearbox Inside Overview Gear Shafts A–C: See Pages 42–43 D–E: See Page 44 Shifting Levers F–I: See Pages 45–46 -41- BUY PARTS ONLINE AT GRIZZLY.COM! Model G0600Z (Mfd. Since 09/24) Scan QR code to visit our Parts Store.
  • Page 42 6004 6037 6035 6033 6034 6049 6030 6032 6028 6031 6030 6048 6029 6029 6030 6046 6030 6028 6032 6027 6047 -42- BUY PARTS ONLINE AT GRIZZLY.COM! Model G0600Z (Mfd. Since 09/24) Scan QR code to visit our Parts Store.
  • Page 43 6066 P0600Z6066 CAP RIGHT 6033 P0600Z6033 BALL BEARING 6203ZZ 6067 P0600Z6067 ROLL PIN 5 X 35 6034 P0600Z6034 GEAR 19T 6068 P0600Z6068 RECEIVER HUB -43- BUY PARTS ONLINE AT GRIZZLY.COM! Model G0600Z (Mfd. Since 09/24) Scan QR code to visit our Parts Store.
  • Page 44 COTTER PIN M2 X 30 STANDARD 6185 P0600Z6185 FORK CENTER 6176 P0600Z6176 CLAW SHIFTER E 6186 P0600Z6186 FORK RIGHT 6177 P0600Z6177 DOWEL PIN 8 X 16 -44- BUY PARTS ONLINE AT GRIZZLY.COM! Model G0600Z (Mfd. Since 09/24) Scan QR code to visit our Parts Store.
  • Page 45 7098 7104 7089 7095 7101 7090 7097 7107 7091 7092 7100 7082 7093 7094 7102 7097 7105 7098 7104 7095 7096 -45- BUY PARTS ONLINE AT GRIZZLY.COM! Model G0600Z (Mfd. Since 09/24) Scan QR code to visit our Parts Store.
  • Page 46 7100 P0600Z7100 SPACER 16 X 28.5 X 16 7116 P0600Z7116 FEED DIAL SCALE 7101 P0600Z7101 KEY 5 X 5 X 14 RE -46- BUY PARTS ONLINE AT GRIZZLY.COM! Model G0600Z (Mfd. Since 09/24) Scan QR code to visit our Parts Store.
  • Page 47: Change Gears

    7213 P0600Z7213 SPINDLE NUT M20-2.5 7226 P0600Z7226 KEY 6 X 6 X 12 RE 7215 P0600Z7215 SPACER 8.5 X 35 X 5MM -47- BUY PARTS ONLINE AT GRIZZLY.COM! Model G0600Z (Mfd. Since 09/24) Scan QR code to visit our Parts Store.
  • Page 48 8126 8076 8117 8128 8109 8057 8114 8129 8118 8081 8112 8130 8116 8122 8082 8115 8080 8127 8131 8113 8111 -48- BUY PARTS ONLINE AT GRIZZLY.COM! Model G0600Z (Mfd. Since 09/24) Scan QR code to visit our Parts Store.
  • Page 49: Carriage Parts List

    8053 P0600Z8053 WELD NUT M10-1.5 8107 P0600Z8107 BARREL NUT M24-1.5 8054 P0600Z8054 PHLP HD SCR M5-.8 X 14 8108 P0600Z8108 REVOLVING HANDLE M10-1.5 X 11 -49- BUY PARTS ONLINE AT GRIZZLY.COM! Model G0600Z (Mfd. Since 09/24) Scan QR code to visit our Parts Store.
  • Page 50 8232 P0600Z8232 STRAIGHT ADAPTER M14-1.5 X 8MM 8124 P0600Z8124 O-RING 16 X 2.4 P16 8244 P0600Z8244 WORK LIGHT CORD 20G 2W 185" -50- BUY PARTS ONLINE AT GRIZZLY.COM! Model G0600Z (Mfd. Since 09/24) Scan QR code to visit our Parts Store.
  • Page 51 9125 9126 9080 9017 9114 9018 9125 9111 9084 9034 9017 9084 9110 9074 9127 9119 9014 9118 9128 9117 9116 -51- BUY PARTS ONLINE AT GRIZZLY.COM! Model G0600Z (Mfd. Since 09/24) Scan QR code to visit our Parts Store.
  • Page 52: Apron Parts List

    9104 P0600Z9104 SLEEVE 9052 P0600Z9052 DIAL RACK 9105 P0600Z9105 SLEEVE SEAL 9053 P0600Z9053 CAP SCREW M6-1 X 25 9106 P0600Z9106 BUFFER -52- BUY PARTS ONLINE AT GRIZZLY.COM! Model G0600Z (Mfd. Since 09/24) Scan QR code to visit our Parts Store.
  • Page 53 9116 P0600Z9116 SET SCREW M8-1.25 X 30 9127 P0600Z9127 DOWEL PIN 8 X 40 9117 P0600Z9117 HEX NUT M8-1.25 9128 P0600Z9128 LEVER -53- BUY PARTS ONLINE AT GRIZZLY.COM! Model G0600Z (Mfd. Since 09/24) Scan QR code to visit our Parts Store.
  • Page 54: Steady & Follow Rests

    ROLL PIN 5 X 50 9310 P0600Z9310 HEX BOLT M10-1.5 X 40 9216 P0600Z9216 LOCK SCREW M10-1.5 X 18 9311 P0600Z9311 FLAT WASHER 10MM -54- BUY PARTS ONLINE AT GRIZZLY.COM! Model G0600Z (Mfd. Since 09/24) Scan QR code to visit our Parts Store.
  • Page 55 9406 9446 9405 9442 9448 9441 9447 9402 9401 9451 9445 9456 9449 9455 9452 9457 9449 9458 9450 9453 9454 -55- BUY PARTS ONLINE AT GRIZZLY.COM! Model G0600Z (Mfd. Since 09/24) Scan QR code to visit our Parts Store.
  • Page 56: Tailstock Parts List

    FLAT WASHER 12MM 9428 P0600Z9428 TAILSTOCK BODY 9457 P0600Z9457 CLAMP SHOE 9429 P0600Z9429 LEADSCREW 9458 P0600Z9458 FLAT WASHER 21 X 37 X 3MM -56- BUY PARTS ONLINE AT GRIZZLY.COM! Model G0600Z (Mfd. Since 09/24) Scan QR code to visit our Parts Store.
  • Page 57 9527 P0600Z9527 TOP CHUCK JAW SET (3-PC) 9514 P0600Z9514 WRENCH 12 X 14MM OPEN-ENDS 9528 P0600Z9528 BOTTOM CHUCK JAW SET (3-PC) -57- BUY PARTS ONLINE AT GRIZZLY.COM! Model G0600Z (Mfd. Since 09/24) Scan QR code to visit our Parts Store.
  • Page 58: Electrical Cabinet

    9610 P0600Z9610 GROUND TERMINAL BAR 3P M4 X 20 TM4 9704 P0600Z9704 CAP SCREW M6-1 X 12 9611 P0600Z9611 TERMINAL BAR 3P DIN28 14-12G -58- BUY PARTS ONLINE AT GRIZZLY.COM! Model G0600Z (Mfd. Since 09/24) Scan QR code to visit our Parts Store.
  • Page 59 9811 9830 9836 9806 9802 9806 9830 9804 9837 9803 9839 9841 9838 9830 9811 9831 9830 9811 9806 9834 9835 -59- BUY PARTS ONLINE AT GRIZZLY.COM! Model G0600Z (Mfd. Since 09/24) Scan QR code to visit our Parts Store.
  • Page 60 9850 P0600Z9850 BLOCK 9825 P0600Z9825 FLAT HD SCR M4-.7 X 10 9851 P0600Z9851 SCALE COVER X-AXIS 9826 P0600Z9826 SCALE MOUNTING PLATE X-AXIS -60- BUY PARTS ONLINE AT GRIZZLY.COM! Model G0600Z (Mfd. Since 09/24) Scan QR code to visit our Parts Store.
  • Page 61: Labels & Cosmetics

    9905 9906 9902 9907 9904 WARNING! BIOLOGICAL AND POISON HAZARD! Use personal protection when handling coolant. Immediately clean up spills. 9903 -61- BUY PARTS ONLINE AT GRIZZLY.COM! Model G0600Z (Mfd. Since 09/24) Scan QR code to visit our Parts Store.
  • Page 62 Safety labels help reduce the risk of serious injury caused by machine hazards. If any label comes off or becomes unreadable, the owner of this machine MUST replace it in the original location before resuming operations. For replacements, contact (800) 523-4777 or www.grizzly.com. -62- BUY PARTS ONLINE AT GRIZZLY.COM!
  • Page 63: Warranty And Returns

    WARRANTY & RETURNS Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of maintenance.
  • Page 65 OWNER'S MANUAL (For models manufactured since 7/11) COPYRIGHT © APRIL, 2007 BY GRIZZLY INDUSTRIAL, INC., REVISED NOVEMBER, 2016 (MN) WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
  • Page 66 This manual provides critical safety instructions on the proper setup, operation, maintenance, and service of this machine/tool. Save this document, refer to it often, and use it to instruct other operators. Failure to read, understand and follow the instructions in this manual may result in fire or serious personal injury—including amputation, electrocution, or death.
  • Page 67: Table Of Contents

    Table of Contents INTRODUCTION ..........................3 Foreword ............................ 3 Contact Info ..........................3 G0600 Data Sheet ........................4 Identification ..........................7 Headstock Controls ........................8 SECTION 1: SAFETY ........................9 Additional Safety for Metal Lathes ................... 11 Glossary of Terms ........................12 SECTION 2: CIRCUIT REQUIREMENTS ..................
  • Page 68 SECTION 5: ACCESSORIES ......................47 SECTION 6: MAINTENANCE......................52 Schedule ..........................52 Cleaning ........................... 52 Lubrication ..........................52 Coolant System ........................56 SECTION 7: SERVICE ........................57 Troubleshooting ........................57 Cross Slide Leadscrew Adjustment ..................60 Leadscrew Endplay Adjustment ....................60 Gib Adjustment .........................
  • Page 69: Introduction

    However, owing to Grizzly’s policy of con- Email: manuals@grizzly.com tinuous improvement, changes may be made at any time with no obligation on the part of Grizzly. For your convenience, we always keep current Grizzly manuals available on our website at www.
  • Page 70: G0600 Data Sheet

    MACHINE DATA SHEET Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901 MODEL G0600 20" X 60" 3‐PHASE BIG BORE METAL LATHE Product Dimensions: Weight................................5071 lbs. Width (side-to-side) x Depth (front-to-back) x Height............. 110-3/4 x 45-1/4 x 51 in. Footprint (Length x Width)......................
  • Page 71 Main Specifications: Operation Info Swing Over Bed............................20 in. Distance Between Centers........................60 in. Swing Over Cross Slide..........................12 in. Swing Over Saddle............................ 12 in. Swing Over Gap............................29 in. Maximum Tool Bit Size..........................1 in. Compound Travel............................5 in. Carriage Travel..........................
  • Page 72 Construction Base..............................Cast Iron Headstock............................Cast Iron End Gears........................ Flame Hardened Cast Iron Bed....................Hardened and Precision-Ground Cast Iron Body..............................Cast Iron Stand..............................Cast Iron Paint Type/Finish............................Epoxy Fluid Capacities Headstock Capacity........................12.68 quarts Gearbox Capacity..........................6.97 quarts Apron Capacity..........................2.75 quarts Coolant Capacity..........................
  • Page 73: Identification

    Identification Figure 1. The Model G0600 20" x 60" Big Bore Lathe. A. Headstock M. 4-Position Apron Stop Dial B. D1-8 Camlock MT#7 Spindle N. Spindle Rotation ON/OFF Lever C. Gap Piece O. Compound Rest Handwheel D. Ball Bearing Style Steady Rest P.
  • Page 74: Headstock Controls

    Headstock Controls Figure 2. Headstock and gearbox controls. A. Cutting Chart: Used for shifting the lathe Jog Button: Turns the spindle motor ON headstock and gearbox into the proper gear while being pressed and held. combinations for threading and feeding oper- ations.
  • Page 75: Section 1: Safety

    SECTION 1: SAFETY SECTION 1: SAFETY For Your Own Safety, Read Instruction Manual Before Operating this Machine The purpose of safety symbols is to attract your attention to possible hazardous conditions. This manual uses a series of symbols and signal words intended to convey the level of importance of the safety messages.
  • Page 76 Safety Instructions for Machinery DISCONNECTING POWER SUPPLY. Always APPROVED OPERATION. Untrained operators disconnect machine from power supply before can be seriously hurt by machinery. Only allow servicing, adjusting, or changing cutting tools trained or properly supervised people to use (bits, blades, cutters, etc.). Make sure switch is machine.
  • Page 77: Additional Safety For Metal Lathes

    Additional Safety for Metal Lathes 10. SAFETY CLEARANCES. Make sure READ UNDERSTAND THIS workpiece has adequate clearance before MANUAL BEFORE OPERATING THIS starting machine. Check tool and tool post MACHINE. YOUR SAFETY AND THE clearance, chuck clearance, and saddle PROPER USE OF THIS MACHINE IS clearance before starting the lathe.
  • Page 78: Glossary Of Terms

    The following is a list of common definitions, terms and phrases used throughout this manual as they relate to this lathe and metalworking in general. Become familiar with these terms for assembling, adjusting or operating this machine. Your safety is VERY important to us at Grizzly! Arbor: A machine shaft that supports a cutting Gib: A tapered wedge located along a sliding tool.
  • Page 79: Section 2: Circuit Requirements

    SECTION 2: CIRCUIT REQUIREMENTS 220V 3-Phase Grounding In the event of an electrical short, grounding Operation reduces the risk of electric shock. The grounding wire in the power cord must be properly connected to the grounding prong on the plug; likewise, the outlet must be properly installed and grounded.
  • Page 80: Section 3: Setup

    SECTION 3: SETUP Setup Safety Items Needed for Setup The following items are needed to complete the This machine presents setup process, but are not included with your serious injury hazards machine: to untrained users. Read through this entire manu- Description al to become familiar with •...
  • Page 81: Inventory

    Inventory Tool Box Inventory: (Figure 4) K. Tool Box ............. 1 Oil Bottle ............. 1 M. Carriage Lock and Tool Holder Wrench ..1 In the event that any nonproprietary parts are N. Three-Jaw Chuck Wrench ......1 missing (e.g. a nut or a washer), we would be O.
  • Page 82: Hardware Recognition Chart

    Hardware Recognition Chart -16- Model G0600 (Mfd. Since 7/11)
  • Page 83: Site Considerations

    Site Considerations Floor Load Unsupervised children and Refer to the Machine Data Sheet for the weight visitors inside your shop and footprint specifications of your machine. could cause serious per- Some floors may require additional reinforcement sonal injury to themselves. to support both the machine and operator.
  • Page 84: Lifting & Moving The Lathe

    Lifting & Moving the Lathe This lathe is an extremely heavy machine. Serious personal injury or death may occur if safe lifting Figure 6. Leveling feet and screws. and moving methods are not followed. Seek assis- When lifting, you must move the carriage and tance from a professional tailstock to the right and lock into place as shown rigger if you are unsure...
  • Page 85: Cleanup

    Remove this protective coating with a sol- used to clean machinery. vent cleaner or citrus-based degreaser such as DO NOT use gasoline or Grizzly’s G7895 Degreaser. To clean thoroughly, petroleum products to some parts may need to be removed. For opti- clean the machinery.
  • Page 86: Test Run

    Test Run Make sure that the chuck and jaws are secure refer to (Chuck and Faceplate Mounting on Page 25 and Reversing Jaws on Page 28). Fill the coolant pump reservoir, and switch NOTICE the pump switch to the OFF position (refer to Coolant System on Page 56).
  • Page 87 12. Make sure that all bystanders are out of the Observe the oil pump tube sight glass, and way, no tools are in the way, and the chuck make sure oil is being pumped out of the tube key is removed from the chuck. as seen through the sight glass (Figure 12).
  • Page 88: Changing Motor Rotation

    Changing Motor Rotation Disconnect the lathe from power before working on wiring, and get help from an Electrician if you are unsure If the chuck turns away from you at the top of the about your wiring skills and chuck when the spindle lever is in the down posi- codes.
  • Page 89: Apron And Spindle Break-In

    Spindle Balancing Apron and Spindle Break-in After the spindle has been broken in, or if the lathe has been used for a considerable amount of time, NOTICE you should adjust the spindle weights to minimize spindle vibration. Failure to follow beak-in procedures will likely cause rapid deterioration of bearings To minimize spindle vibration: and other related parts.
  • Page 90: Section 4: Operations

    SECTION 4: OPERATIONS Operation Safety General NOTICE Damage to your eyes, lungs, and ears could Failure to follow test-run and brake-in pro- result from using this machine without cedures will likely cause rapid deteriora- proper protective gear. Always wear safety tion of bearings and other related parts.
  • Page 91: Chuck And Faceplate

    Chuck and Faceplate To remove a chuck or faceplate: Mounting DISCONNECT LATHE FROM POWER! Place a piece of plywood across the lathe ways and position it just under the chuck. The Model G0600 is shipped with the 3-jaw chuck The board should be at least 8" wide and 10" installed.
  • Page 92 To install a chuck or faceplate: Align the chuck-to-spindle timing marks (Figure 19), and slide the chuck onto the DISCONNECT LATHE FROM POWER! spindle. Place a piece of plywood across the lathe Turn a camlock with the chuck key until the ways and position it just under the chuck.
  • Page 93: Camlock Stud Adjustment

    Camlock Stud If this is the case, you will have to remove the chuck and fine-tune the camlock stud adjustment. Adjustment See Figure 19 for which direction to turn the camlock studs. Once you have adjusted the camlock studs, install When fitting a chuck or face plate with camlock the chuck or faceplate as outlined in "To install studs, or when mounting a new chuck or face-...
  • Page 94: Reversing Jaws

    Reversing Jaws To reverse the jaws: DISCONNECT LATHE FROM POWER! Unbolt, then flip the jaw as shown in Figures 20-23, then re-tighten. Figure 22. Reversing jaw step 3. Figure 20. Reversing jaw step 1. Figure 23. Reversing jaw step 4. Repeat these steps for the other two jaws.
  • Page 95: Gap Removal

    Gap Removal Tailstock Your lathe has a gap section below the spindle Tailstock Lock that can be removed for turning large diameter parts. This gap was installed, then ground at the Quill Lock factory during lathe assembly for precise fit and alignment.
  • Page 96: Aligning Tailstock

    Aligning Tailstock Place the live center in the tailstock. Attach a lathe dog to the round stock and mount it between the centers. To align the tailstock: Turn approximately 0.010" off the diameter. Using a precision level, make sure the Mount a dial indicator so the plunger is on the bedways are level side-to-side and front-to- tailstock barrel before moving the tailstock.
  • Page 97: Drilling With Tailstock

    Drilling with Turn the quill feed handle clockwise to feed the drill bit into the rotating workpiece. Tailstock To remove the chuck taper, turn the quill feed handle counterclockwise until the chuck is pushed out from the tailstock taper. To install the tapered drill chuck: With the tailstock locked, pull up to unlock the Cutting Tapers with quill lock lever.
  • Page 98: Centers

    Centers The dead center can also be used in the spindle. The most common application is when using the faceplate (see Figure 34). The dead center is used in the tailstock to support To install the dead center in the spindle: workpieces.
  • Page 99: Steady Rest

    Steady Rest Loosen the hand lock knob and open the steady rest so a workpiece can fit inside of the fingers (see Figure 36). The steady rest serves as a support for long shafts (length to diameter ratio of 3:1 or greater). The steady rest can be placed anywhere along the length of the workpiece.
  • Page 100: Follow Rest

    Follow Rest Setting Compound Slide The follow rest in Figure 37 is mounted on the saddle and follows the movement of the tool. The follow rest requires only two fingers as the cut- The compound slide is used to cut tapers on parts ting tool acts as the third.
  • Page 101: Quick Change

    Quick Change Foot Brake Tool Post The Model G0600 lathe comes equipped with a foot brake (see Figure 40). The foot brake is This 500 series quick change tool post allows for intended to be used primarily as a time saving speedy tool changes.
  • Page 102: Setting Spindle Rpm

    Setting Spindle RPM Determine the final diameter, in inches, for the cut you are about to take. Note: For this step you will need to aver- The spindle speed dial positions the headstock age out the diameters or work with the finish gears in one of three speed modes.
  • Page 103 Figure 42. Range levers. X + L = 80 RPM Figure 43. Spindle speed lever in left position. Figure 44. Spindle speed lever in central Figure 45. Spindle speed lever in right position—55, 170, 525,1600 RPMs available. position —35, 120, 350,1100 RPMs available. -37- Model G0600 (Mfd.
  • Page 104: Manual Feed

    Power Feed Manual Feed You can manually move the cutting tool around NOTICE the lathe by three methods. This section will review the individual controls on the carriage and Feed rate is based on spindle RPM. High provide descriptions of their uses (see Figure feed rates combined with high spindle 46).
  • Page 105: Four-Position Apron Stop

    Four-Position Apron NOTICE Stop Every time you readjust the stop eccen- trics, always manually test your apron stop setting before you rely on apron stop sys- tem to automatically disengage the apron. Use the four-position apron stop for disengaging the apron automatically at up to four different apron locations.
  • Page 106: Starting Lathe

    Move the spindle ON/OFF lever (Figure 52) to Starting Lathe start and stop spindle and chuck rotation. Starting and stopping the lathe requires a couple of steps. First, the master switch (Figure 50) on Spindle ON/OFF Lever the back of the lathe must be turned to the "1" position "ON", the green power lamp (Figure 51) will light.
  • Page 107: Using The Thread Chart

    Using the Thread Chart This lathe comes with one 48-tooth and two 57-tooth change gears installed for cutting inch or metric threads. For cutting dimetrial or modu- lar pitch threads, certain gears must be replaced and repositioned (refer to Dimetrial and Modular Pitch Threading on Page 42).
  • Page 108: Dimetrial And Modular Pitch Threading

    Dimetrial and Modular Put on your safety glasses, and using a 14mm wrench, remove the center spindle Pitch Threading and gear assembly (Figure 58). Spindle 57-Tooth NOTICE Some threading operations may damage 66-Tooth the lead screw if performed at high speeds. Always use the slowest speed possible for your particular operation! Bolt Hole...
  • Page 109 13. Using a 24mm wrench, loosen the adjust- Thread the three M6-1 x 25 cap screws into ment arm locknut (Figure 62), and let the the gears so the cap screws act as guide adjustment arm swing away. dowels allowing the gears to slide together without binding.
  • Page 110: Inch And Metric Pitch Threading

    Inch and Metric Pitch Put on your safety glasses, and using a 14mm wrench, remove the center spindle Threading and gear assembly (Figure 63). Using retaining ring pliers, remove the retain- ing ring from the spindle (Figure 64). NOTICE Use a press to remove and flip the direction of the spindle and reinstall the retaining ring.
  • Page 111 13. Using a 24mm wrench, loosen the adjust- 10. Slide the 57-tooth gear onto the lower spindle, ment arm locknut (Figure 67), and let the install the shoulder washer on the spindle so the shoulder faces the gear (Figure 65), and adjustment arm swing away.
  • Page 112: Thread Dial

    Thread Dial This lathe is equipped with a thread dial that lets you know where on the leadscrew you can re-engage the halfnut to resume inch threading. However, since the leadscrew is a 4 TPI, then the thread dial is not needed for any thread that is divisible by 4.
  • Page 113: Section 5: Accessories

    ACCESSORIES SECTION 5: ACCESSORIES This section includes the most common accessories available for this lathe through the Grizzly catalog, online at www.grizzly.com, or by calling 1-800-523-4777. G7895—Citrus Degreaser G2871—Boeshield T-9 12 oz Spray ® This citrus based degreaser is perfect for cleaning G2870—Boeshield...
  • Page 114 Metal-Cutting Lathe. The positive-locking handle ing tolerances. clamps standard 5-C collets safely and securely for precision turning. See the current Grizzly catalog for a full line of 5-C collets. Figure 76. 15 Piece 5-C Collet Set. H3741—30 HP/25 HP Start, Phase Converter Add 3-phase electrical supply with this rota- Figure 74.
  • Page 115 H2670—HSS Square Tool Bits ½" x ½" x 4 G9777—20-Pc. Carbide Tipped Tool Bit Set Our ground tool bits are M-2 HSS, making them An exceptional value for carbide lathe tool bits! some of the most durable tool bits around. Make This twenty-piece set offers tremendous savings your own specialized cutters in any shape using over bits sold individually, plus every type is dupli-...
  • Page 116 H5930—HSS Center Drill Set 60° H7504—6 Pc. Square 5-C Collet Set H5931—HSS Center Drill Set 82° H7505—7 Pc. Hex 5-C Collet Set Double ended HSS center drills, are precision Whether you’re using a spin indexer, collet closer ground for unsurpassed accuracy. Each set on a lathe or grinding fixture on your surface grind- includes sizes 1-4.
  • Page 117 G9245—MT4 Live Center Set BODY DRILL OVERALL A super blend of quality and convenience, this MODEL SIZE DIA. DIA. LENGTH live center set offers seven interchangeable tips. H4456 ⁄ " ⁄ " ⁄ " High-quality needle bearings prolong tool life H4457 ⁄...
  • Page 118: Section 6: Maintenance

    (Figure 88). If oil is • Emergency stop and brake operation. not seen pumping, shut the lathe down immedi- • Worn or damaged wires. ately and contact Grizzly Technical Support. • Coolant level. • Lubrication levels. •...
  • Page 119 Quick Change Gearbox After the first month of daily operation, drain the oil through the drain plug at the back of the head- The quick change gearbox is lubricated with 20W stock (Figure 89), open the side cover and refill non-detergent oil, ISO 68, or an equivalent gear the headstock through the fill plug (Figure 90).
  • Page 120 Apron Fill Plug The apron gearbox is lubricated with 20W non- detergent oil, ISO 68, or an equivalent gear box Apron Oil Pump machine oil. Keep the oil level full as seen in the sight glass shown in (Figure 93). Sight Glass After the first month of daily operation, drain the apron oil through the drain plug (Figure 93), and...
  • Page 121 Ball Oilers This lathe has 11 ball oiler locations. To lubricate ball oilers, clean the outside of the ball oiler, push the ball with the tip of the oil can nozzle and squirt one or two drops of oil inside the oiler before and after using the lathe.
  • Page 122: Coolant System

    Coolant System Pump the old cutting fluid out of the reser- voir and dispose of according to State and Federal Environmental Laws. Using a magnet, brush, and rags clean out metal chips from the bottom of the reservoir. Flush with hot soapy water if required. BIOLOGICAL AND POISON HAZARD! Use the correct Refill the reservoir with applicable water-...
  • Page 123: Section 7: Service

    SECTION 7: SERVICE Review the troubleshooting and procedures in this section to fix your machine if a problem develops. If you need replacement parts or you are unsure of your repair skills, then feel free to call our Technical Support at (570) 546-9663.
  • Page 124 Operation and Work Results Symptom Possible Cause Possible Solution Entire machine 1. Workpiece is unbalanced. 1. Reinstall workpiece so it is as centered with the spindle bore as possible. vibrates exces- sively upon start- 2. Loose or damaged belt(s). 2. Tighten/replace the belt as necessary. up and while run- 3.
  • Page 125 Operation and Work Results Symptom Possible Cause Possible Solution Carriage hard to 1. Carriage lock is tightened down. 1. Check to make sure the carriage lock bolt is fully move. 2. Chips have loaded up on bedways. released. 2. Frequently clean away chips that load up during 3.
  • Page 126: Cross Slide Leadscrew Adjustment

    Cross Slide Leadscrew Endplay Leadscrew Adjustment Adjustment After a long period of time, you may find that the lead screw for threading operations may develop Backlash is the amount of play found in a lead a bit of end play. This lathe is designed so that screw.
  • Page 127: Gib Adjustment

    Gib Adjustment When adjusting the cross slide, tailstock, saddle, Left Gib and compound rest gib screws (Figures 103- Screw 106), keep in mind that the goal is to remove sloppiness in the ways without causing the slides to bind. Loose gibs will cause a poor finish on the workpiece and may cause undue wear on the slide.
  • Page 128: Halfnut Adjustment

    Halfnut Adjustment Feed Clutch Adjustment When adjusting the halfnut gibs remove the thread dial to expose the two gib screws (Figure This lathe is designed with a feed clutch. This 107). Your goal is to remove sloppiness in the cone type clutch helps protect the apron feed ways without causing the half nut to bind.
  • Page 129: V-Belts

    Brake and Switch V-Belts After consistent lathe usage, it will be necessary After consistent lathe usage, it will be necessary to compensate for brake lining wear. to compensate for belt wear. To adjust or replace the V-belts on the lathe: To adjust the brake and brake switch: DISCONNECT LATHE FROM POWER! DISCONNECT LATHE FROM POWER!
  • Page 130: Control Panel Electrical

    Control Panel Electrical Jog Switch Emergency Stop Switch Power ON/OFF Switch Power Lamp Pump Switch Figure 111. Control panel switches. -64- Model G0600 (Mfd. Since 7/11)
  • Page 131: Switch And Motor Electrical

    Switch and Motor Electrical Figure 112. Pump wiring (M2). Figure 115. Spindle motor wiring (M1). Figure 116. Main power switch (S). Figure 113. Spindle rotation switch (SQ1, SQ2). Figure 117. Gear cover limit switch (SQ3). Figure 114. Brake switch (SQ4). -65- Model G0600 (Mfd.
  • Page 132: Main Electrical Box

    Main Electrical Box Spindle Motor Spindle Motor Pump Motor Transformer (TC) Contactor (KM1) Contactor (KM2) Contactor (KM3) Spindle Motor Pump Motor Thermal Relay Thermal Relay (FR1) (FR2) Ground Block Master Power 6A Fuse 3A Fuse Contactor 50A Master (FU2) (FU3) Spindle Motor (KM4) Power Switch/...
  • Page 133: Model G0600 Electrical Diagram

    Model G0600 Electrical Diagram If a phase converter is being used, connect the “Wild Wire” or “Manufactured Leg” to L3 or contactor and transformer failure may result. -67- Model G0600 (Mfd. Since 7/11)
  • Page 134: Headstock Gear System

    Headstock Gear System (0000 Series Parts) 26 27 28 29 30 31 32 33 34 11 12 13 14 15 17 18 19 20 21 22 23 24 25 3, 2 108 109 93 94 95 96 97 98 99 100 101 102 89, 88 85, 84 134 135...
  • Page 135: Headstock Face And Shift System

    Headstock Face and Shift System (0000 Series Parts) -69- Model G0600 (Mfd. Since 7/11)
  • Page 136: Headstock Shift System

    Headstock Shift System (0000 Series Parts) 170 171 172 173 166,224 -70- Model G0600 (Mfd. Since 7/11)
  • Page 137: Headstock Oil Pump System

    Headstock Oil Pump System (0000 Series Parts) 211 212 217 218 -71- Model G0600 (Mfd. Since 7/11)
  • Page 138 REF PART # DESCRIPTION REF PART # DESCRIPTION PSB02M CAP SCREW M6-1 X 20 PSB29M CAP SCREW M6-1 X 40 P06000002 BEARING COVER P06000052 FRONT BEARING COVER P06000003 BEARING COVER SEAL P06000053 FRONT BEARING COVER SEAL P06000004 SPLINE SHAFT P06000054 BALL BEARING D2007124E P6205 BALL BEARING 6205...
  • Page 139 REF PART # DESCRIPTION REF PART # DESCRIPTION PR32M EXT RETAINING RING 48MM P06000150 SHAFT P06000101 GEAR 31T X M2.75 P06000151 FORK PK09M KEY 8 X 8 X 32MM PEC03M E-CLIP 10MM PSS16M SET SCREW M8-1.25 X 10 P06000153 LEVER P06000104 GEAR 24T X M2.75 PRP26M...
  • Page 140 REF PART # DESCRIPTION REF PART # DESCRIPTION PSB38M CAP SCREW M5-.8 X 25 P06000216 SEAL SLEEVE P06000201 MANIFOLD PLW12M SEAL WASHER P06000202 SEAL SLEEVE P06000218 SCREEN P06000203 BRASS FITTING P06000219 PLUG P06000204 BRASS TUBE 8 X 0.75" P06000220 TUBE FITTING P06000205 GEAR 20T X M2.75 PLW10M...
  • Page 141: Quick Change Gearbox Gear System

    Quick Change Gearbox Gear System (1000 Series Series Parts) 1047 1047 1067 1067 1070 1070 1049 1049 1052 1052 1054 1054 1069 1069 1050 1050 1048 1048 1051 1051 1046 1046 1073 1073 1066 1066 1053 1053 1059 1059 1055 1055 1071 1071...
  • Page 142: Quick Change Gearbox Face

    Quick Change Gearbox Face (1000 Series Parts) 1109 1110 1110 1128 1128 1108 1108 1103 1103 1074 1074 1116 1116 1077 1077 1112 1112 1072 1072 1019 1019 1002 1002 1127 1127 1061 1061 1037 1037 1111 1111 1103 1103 1113 1113 1114...
  • Page 143: Quick Change Gearbox Shift System

    Quick Change Gearbox Shift System (1000 Series Parts) 1092 1018 1084 1101 1085 1121 1099 1103 1104 1023 1097 1129 1122 1088 1086 1090 1094 1081 1083 1091 1095 1078 1124 1096 1082 1079 -77- Model G0600 (Mfd. Since 7/11)
  • Page 144: Quick Change Gearbox Shift System

    Quick Change Gearbox Shift System (1000 Series Parts) 1089 1089 1076 1076 1065 1065 1099 1099 1118 1118 1105 1105 1106 1107 1106 1107 1087 1087 1075 1075 1080 1080 1100 1100 1004 1004 1102 1102 1097 1097 1119 1119 1120 1120 1062...
  • Page 145 REF PART # DESCRIPTION PART # DESCRIPTION 1001 P06001001 GEAR BOX 1051 P06001051 GEAR 27T X 14D.P 1002 P06001002 FRONT COVER 1052 P06001052 GEAR 24T X M2.25 1003 P06001003 BEVEL GEAR 1053 P06001053 GEAR 26T X M2.25 1004 P06001004 HEX BOLT 1054 P06001054 GEAR 36T X M2...
  • Page 146 REF PART # DESCRIPTION REF PART # DESCRIPTION 1100 P06001100 1116 P06000141 RIVET 2 X 5MM 1101 P06001101 SHAFT 1117 P06001117 OIL-SEAL 1102 P06001102 FORK 1118 P06001118 FEMALE KNOB M10-1.5 1103 PSB37M CAP SCREW M6-1 X 50 1119 P06001119 SHAFT 1104 P06001104 LOCK WASHER...
  • Page 147: Carriage

    Carriage (2000 Series Parts) 2056 2048 2079 2044 2052 2078 2080 2081 2046 2091 -81- Model G0600 (Mfd. Since 7/11)
  • Page 148: Cross Slide & Carriage

    Cross Slide & Carriage (2000 Series Parts) 2055 2048 2083 2049 2082 2053 2025 2050 2047 2077 2081 2076 2030 2057 2051 2054 2054 2120 2119 2121 2018 2034 2014 2001 2021 2005 2022 2016 2032 2011 2017 2019 2006 2004 2002 2033...
  • Page 149: Compound Slide & Tool Post

    Compound Slide & Tool Post (2000 Series Parts) 2003 2069 2073 2050 2049 2089 2037 2043 2042 2040 2041 2094 2093 2092 2039 2061 2062 2034 2063 2075 2058 2071 2038 2013 2067 2074 2070 2086 2066 2087 2059 2084 2064 2007 2029...
  • Page 150: Carriage Oil Pump System

    Carriage Oil Pump System (2000 Series Parts) 2076 2108 2111 2110 2109 2095 2077 2107 2106 2096 2105 2097 2104 2098 2103 2099 2100 2102 2101 2113 2115 2118 2047 2117 2114 2112 2116 -84- Model G0600 (Mfd. Since 7/11)
  • Page 151 PART # DESCRIPTION PART # DESCRIPTION P06002000 FLANGE NUT M20-2.5 2051 P06002051 2000 P06002001 SADDLE 2052 P06002052 LEFT REAR CARRIAGE WAY WIPER 2001 P06002002 NUT (INCH) 2053 P06002053 CARRIAGE CLAMP 2002 P06002003 GIB SCREW 2054 P06002054 GIB SCREW 2003 PSB48M CAP SCREW M6-1 X 35 2055 P06002055...
  • Page 152 REF PART # DESCRIPTION REF PART # DESCRIPTION 2100 P06002100 SLEEVE 2112 P06002112 TUBE FITTING 2101 P06002101 CHECK VALVE 2113 P06002113 BRASS TUBE 4 X 200MM 2102 P06002102 BRASS TUBE 6 X 170MM 2114 P06002114 BRASS TUBE 4 X 170MM 2103 P06002103 TUBE FITTING 2115...
  • Page 153: Apron Face, Thread Dial, Auto Stop System

    Apron Face, Thread Dial, Auto Stop System (3000 Series Parts) 3003 3119 3001 3007 3096 3110 3028 3097 3098 3099 3018 Thread Dial 3104 3109 3103 3102 3101 3019 3020 3106 3108 3100 3008 3107 3029 3030 3075 3049 3082 3085 3064 3057...
  • Page 154: Apron Gearing, Halfnut, Feed System

    Apron Gearing, Halfnut, Feed System (3000 Series Parts) -88- Model G0600 (Mfd. Since 7/11)
  • Page 155: Apron Feed Rod, Clutch And Lever System

    Apron Feed Rod, Clutch and Lever System (3000 Series Parts) 3068 3053 3012 3017 3055 3051 3016 3015 3052 3046 3050 3014 3054 3051 3003 3038 3039 3012 3012 3034 3035 3036 3034 3041 3045 3042 3044 3042 3043 3049 3040 -89- Model G0600 (Mfd.
  • Page 156 PART # DESCRIPTION PART # DESCRIPTION 3001 P06003001 APRON CASE 3051 P06003051 SHAFT 3002 P06003002 3052 P06003052 BUFFER 3003 PSB26M CAP SCREW M6-1 X 12 3053 P06000169 O-RING 20 X 2.4MM 3004 P06003004 LEAD NUT ASSY (INCH) 3054 P06003054 SLEEVE 3005 P06003005 HAFT NUT (INCH)
  • Page 157 REF PART # DESCRIPTION PART # DESCRIPTION 3100 PLW06M LOCK WASHER 10MM 3110 P06003110 INDICATOR PLATE 3101 PN02M HEX NUT M10-1.5 3111 P06003111 SPACER 3102 P06003102 DOWEL PIN 3 X 8MM 3112 P06003112 FLAT SPRING 3103 P06003103 GEAR 16T X M2 3113 P06003113 COMPRESSION SPRING...
  • Page 158: Tailstock

    Tailstock (4000 Series Parts) -92- Model G0600 (Mfd. Since 7/11)
  • Page 159 PART # DESCRIPTION PART # DESCRIPTION 4001 P06004001 QUILL 4028 P06004028 SLEEVE 4002V2 P06004002V2 TAILSTOCK BODY V2.07.11 4029 P06004029 ADJUSTMENT BLOCK 4003 P06004003 OIL SEAL 4030 P06004030 SPECIAL SCREW 4004 P06004004 BALL OILER 4031 P06004031 4005 P06004005 FEED SCREW (INCH) 4037 P06004037 LEVER...
  • Page 160: Bed Assembly

    Bed Assembly (5000 Series Parts) -94- Model G0600 (Mfd. Since 7/11)
  • Page 161: Brake Pedal And Headstock Panels

    Brake Pedal and Headstock Panels (5000 Series Parts) 5174 5176 5084 5144 5145 5085 5083 -95- Model G0600 (Mfd. Since 7/11)
  • Page 162: Brake System And Change Gears

    Brake System and Change Gears (5000 Series Parts) 5082 5082 5081 5081 5035 5035 5080 5080 5079 5079 5078 5078 5036 5036 5077 5077 5037 5037 5038 5038 5039 5039 5006 5006 5073 5073 5072 5072 5071 5071 5037 5037 5069 5069 5037...
  • Page 163: Motor And Headstock Mounting

    Motor and Headstock Mounting (5000 Series Parts) 5175 5175 5167 5167 5076 5076 5166 5166 5037 5037 7021 5164 5164 5166 5166 5164 5164 5124 5124 5137 5137 5036 5036 5165 5165 5123 5123 5163 5163 5066 5066 5042 5042 5162 5162 5165...
  • Page 164: End Covers And Splash Guard

    End Covers and Splash Guard (5000 Series Parts) 5086 5086 5088 5088 5089 5089 5087 5087 5148 5148 5149 5149 5090 5090 5091 5091 5150 5150 5087 5087 5071 5071 -98- Model G0600 (Mfd. Since 7/11)
  • Page 165: Change Gear System

    Change Gear System (5000 Series Parts) 5082 5093 5094 5093 5111 5095 5108 5081 5112 5097 5109 5105 5114 5079 5080 5110 5106 5113 5098 5099 5100 5101 5073 5102 5078 5075 5074 5146 5104 5103 5147 5086 -99- Model G0600 (Mfd. Since 7/11)
  • Page 166 PART # DESCRIPTION PART # DESCRIPTION 5001 P06005001 SWITCH SEAT 5049 P06005049 SHAFT 5002 P06005002 LEAD SCREW (INCH) 5050 P06005050 TENSION SPRING 5003 P06005003 RACK 5051 P06005051 SHAFT 5004 PRP05M ROLL PIN 5 X 30MM 5052 P06005052 BRAKE LEVER 5005 PSB06M CAP SCREW M6-1 X 25 5053...
  • Page 167 REF PART # DESCRIPTION REF PART # DESCRIPTION 5100 P06005100 KEY 6 X 6 X 10 5139 P06005139 COMPRESSION SPRING 5101 P06005101 SHAFT 5140 P06005140 BUSHING 5102 P06005102 SPACER 5141 P06005141 CAP SCREW M8-1.25 X 20 5103 P06005103 PLATE SCREW 5142 P06005142 CAP SCREW M16-2 X 55 5104 P06005104 PLATE SCREW 5143 P06005143 LOCK WASHER 16MM...
  • Page 168: Steady And Follow Rests

    Steady and Follow Rests (6000 Series Parts) 6018 6017 6016 6015 6020 6014 6021 6019 6013 6012 6011 6010 6001A 6009 6008 6022A 6007 6022 6023 6024 6006 6025 6026 6005 6003 6002 6001 6027 6004 6028 6029 6030 6031 6032 -102- Model G0600 (Mfd.
  • Page 169 PART # DESCRIPTION REF PART # DESCRIPTION 6001 P06006001 CLAMPING BRACKET 6017 P06006017 ADJUSTMENT KNOB 6002 P06006002 HEX BOLT M20-2.5 X 110 6018 PSS03M SET SCREW M6-1 X 8 6003 P06006003 SPECIAL NUT M20-1.5 6019 P06006019 LOCK KNOB 6004 PLW07M LOCK WASHER 20MM 6020 P06006020...
  • Page 170: Accessories, Coolant, And Lighting System

    Accessories, Coolant, and Lighting System (7000 Series Parts) 7001 7009 7012 7006 7011 7013 7002 7018 7015 7008 7016 7005 7007 7014 7010 7017 7021 7019-1 7025 7019-2 7019-3 7024 7020 7023 7022 5176 7019 PART # DESCRIPTION PART # DESCRIPTION 7001 P06007001...
  • Page 171: Electrical

    Electrical (8000 Series Parts) 8002 8001 8004 8005 8006 8003 8007 8008 8014 8009 8013 8010 8012 8011 REF PART # DESCRIPTION REF PART # DESCRIPTION 8001 P06008001 CONTACTOR (3TB44) 8009 P06008009 CIRCUIT BREAKER (6A, 400VAC) 8002 P06008002 CONTACTOR (3TB44) 8010 P06008010 MAIN TERMINAL BOARD...
  • Page 172: Warranty And Returns

    WARRANTY AND RETURNS Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of maintenance.
  • Page 173 Would you recommend Grizzly Industrial to a friend? _____ Yes _____No Would you allow us to use your name as a reference for Grizzly customers in your area? Note: We never use names more than 3 times. _____ Yes _____No 10.
  • Page 174 FOLD ALONG DOTTED LINE Place Stamp Here GRIZZLY INDUSTRIAL, INC. P.O. BOX 2069 BELLINGHAM, WA 98227-2069 FOLD ALONG DOTTED LINE Send a Grizzly Catalog to a friend: Name_______________________________ Street_______________________________ City______________State______Zip______ TAPE ALONG EDGES--PLEASE DO NOT STAPLE...

Table of Contents
