Aquestia DOROT S100 AL Installation Operation & Maintenance

DOROT.AL.2W.IOM.EN.0324
Installation, Operation & Maintenance
Altitude Pilot Control Valve (AL)
Level Control Using CXAL Pilot
Applicable Series:
1. Function Description
Dorot Altitude Pilot Control Valve (' AL') is an automatic, pilot controlled, level-control valve, activated
by the pressure of the pipeline. The main valve is controlled by a highly sensitive pilot, located
outside the tank. The pilot opens or closes the valve in response to the static pressure of the water.
2. Technical Features
-
Media: Water; natural, non-aggressive fluids
-
Pressure rating: PN16 or PN25 (250psi or 360 psi) per specific valve-model
-
Temp. range:
-
Flow velocity for continuous operation: 0.05 – 5.5 m/sec (0.3 – 18 ft/sec)
Max. flow velocity for intermittent operation: 8 m/sec (26 ft/sec)
Notes:
-
In case the designed/actual operating conditions are not suitable for the above defined standard
features, please contact Aquestia Applications-Engineering.
-
Refer to specific valve model publications for further details.
3. Safety Guidelines
-
Injury or damage to the system/surroundings may occur if installation, commissioning, operation or
maintenance instructions are not followed correctly, or if applicable codes of practice and
regulations are ignored.
-
Dorot valves are designed for use in fresh water-systems. Please consult Aquestia Applications-
Engineering in case other media is to be used.
-
Be sure to depressurize the valve, prior to any disassembly of valve or control-trim parts.
-
Electrical works (e.g. connection of solenoid-valves, limit-switches etc.), must be executed by a
certified electrician.
-
Errors in the layout-design, installation or operation may affect valve performance and may be a risk
to the system and operators/users. Please note, the system layout, installation and commissioning of
valves is the responsibility of the system designer, installer and/or user.
-
In any case of doubt and prior to taking any further action, please contact Aquestia representative
for assistance.
Altitude Pilot Control Valve (AL)
S300, S100
S300: 2 – 80ᵒC (35 - 176ᵒF)
S100: 2 – 60ᵒC (35 - 140ᵒF)
Sizes:
1 1/2" - 40" / 40 - 1000mm
