Aquestia DOROT S300 Series Installation Operation & Maintenance

DOROT.AL.3W. 8''– 32''.IOM.EN.0325
Installation, Operation & Maintenance
Altitude Pilot Control Valve (AL)
Level Control Using 3110A Pilot
Applicable Series:
1. Function Description
The Dorot Altitude Pilot Control Valve (' AL') is an automatic, pilot controlled, level control valve,
activated by the pressure of the pipeline. The main valve is controlled by a highly sensitive pilot, located
outside the tank. The pilot opens or closes the valve in response to the static pressure of the water. The
pilot allows for differential adjustments between maximum and minimum levels.
2. Technical Features
-
Media: Water; natural, non-aggressive fluids
-
Pressure rating: PN16 or PN25 (250psi or 360 psi) per specific valve-model
-
Temp. range:
-
Flow velocity for continuous operation: 0.05 – 5.5 m/sec (0.3 – 18 ft/sec)
Max. flow velocity for intermittent operation: 8 m/sec (26 ft/sec)
Notes:
-
In case the designed/actual operating conditions are not suitable for the above defined standard
features, please contact Aquestia Applications-Engineering.
-
Refer to specific valve model publications for further details.
3. Safety Guidelines
-
Injury or damage to the system/surroundings may occur if installation, commissioning, operation or
maintenance instructions are not followed correctly, or if applicable codes of practice and
regulations are ignored.
-
Dorot valves are designed for use in potable water-systems. Please consult Aquestia Applications-
Engineering in case other media is to be used.
-
Be sure to depressurize the valve, prior to any disassembly of valve or control-trim parts.
-
Electrical works (e.g. connection of solenoid valves, limit-switches etc.), must be executed by a
certified electrician.
-
Errors in the layout-design, installation or operation may affect valve performance and may be a risk
to the system and operators/users. Please note, the system layout, installation and commissioning of
valves is the responsibility of the system designer, installer and/or user.
-
In any case of doubt and prior to taking any further action, please contact Aquestia representative
for assistance.
Altitude Pilot Control Valve (AL)
S300, S100
S300: 2 – 80 C (35 – 176 F)
S100: 2 – 60 C (35 - 140 F)
Sizes:
8" - 32" / 200-800mm
