DOROT.FR.2W.IOM.EN.0324
Installation, Operation & Maintenance
Control function Flow Regulation (FR)
Flow Regulation Using CXSD Pilot
Applicable models:
1.
Function Description
Dorot Series 300 Flow Control Valve ('30-FR') is activated by the pressure of the pipeline. The valve limits
the flow rate in the network to a preset value, regardless of upstream pressure variations. The valve fully
opens when the flow rate drops below the set point.
2.
Technical Features
-
Media: Water; natural, non-aggressive fluids
-
Pressure rating: PN16 or PN25 (250psi or 360 psi) per specific valve-model
-
Temp. range:
-
Flow velocity for continuous operation: 0.05 – 5.5 m/sec (0.3 – 18 ft/sec)
Max. flow velocity for intermittent operation: 8 m/sec (26 ft/sec)
Notes:
-
In case the designed/actual operating conditions are not suitable for the above defined standard
features, please contact Aquestia Applications-Engineering.
-
Refer to specific valve model publications for further details.
3.
Safety Guidelines
-
Injury or damage to the system/surroundings may occur if installation, commissioning, operation or
maintenance instructions are not followed correctly, or if applicable codes of practice and
regulations are ignored.
-
Dorot valves are designed for use in fresh water-systems. Please consult Aquestia Applications-
Engineering in case other media is to be used.
-
Be sure to depressurize the valve, prior to any disassembly of valve or control-trim parts.
-
Electrical works (e.g. connection of solenoid-valves, limit-switches etc.), must be executed by a
certified electrician.
-
Errors in the layout-design, installation or operation may affect valve performance and may be a risk
to the system and operators/users. Please note, the system layout, installation and commissioning of
valves is the responsibility of the system designer, installer and/or user.
-
In any case of doubt and prior to taking any further action, please contact Aquestia representative
for assistance.
Control Function Flow Regulation (FR)
300,100,500
S300: 2 – 80ᵒC (35 - 176ᵒF)
S500/S100: 2 – 60ᵒC (35 - 140ᵒF)
Sizes:
1½" – 40/ 40-/1000mm
Advertisement
Related Manuals for Aquestia Dorot 300 Series
Summary of Contents for Aquestia Dorot 300 Series
- Page 1 Please note, the system layout, installation and commissioning of valves is the responsibility of the system designer, installer and/or user. In any case of doubt and prior to taking any further action, please contact Aquestia representative for assistance.
- Page 2 DOROT.FR.2W.IOM.EN.0324 Installation, Operation & Maintenance Control Function Flow Regulation (FR) Typical Installation Dorot Hydraulic Control-valve Installation a. The valve can be installed in any position, although installation with the bonnet facing up is recommended for ease of maintenance. b. Flow direction should match the engraved arrow on the bonnet. For maintenance considerations, it is recommended that manual isolation valves (gate or butterfly) are installed, both sides with a strainer between the upstream isolation valve and the valve inlet (as shown in the diagram above).
- Page 3 DOROT.FR.2W.IOM.EN.0324 Installation, Operation & Maintenance Control Function Flow Regulation (FR) No Indicator Air bleed in S-300/500 valves This should be done with the control chamber pressurized (main valve closed) Using the supplied Allen key – open air-bleed-screw at the top of the bonnet and reclose it when only water, (no air) is discharged (refer to diagram on the right).
- Page 4 Aquestia Ltd. reserves the right to make product changes without prior notice. To ensure receiving updated information on parts specifications, please contact us at info@aquestia.com. Aquestia Ltd. shall not be held liable for any errors. All rights reserved...
