Planet HDP-5261PT User Manual

1080p sip vandalproof door phone with rfid and poe
Hide thumbs Also See for HDP-5261PT:

Advertisement

Quick Links

Download this manual
1080p SIP Vandalproof Door Phone with RFID and PoE
1080p SIP Vandalproof Door
Phone with RFID and PoE
HDP-1261PT
HDP-5261PT
1
HDP-1261PT, HDP-5261PT

Advertisement

loading
Need help?

Need help?

Do you have a question about the HDP-5261PT and is the answer not in the manual?

Questions and answers

Related Manuals for Planet HDP-5261PT

Summary of Contents for Planet HDP-5261PT

  • Page 1 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT HDP-5261PT...
  • Page 2 "as is". Should the programs prove defective following their purchase, the buyer (and not PLANET, its distributor, or its dealer) assumes the entire cost of all necessary servicing, repair, and any incidental or consequential damages resulting from any defect in the software.
  • Page 3 Do not dispose of WEEE as unsorted municipal waste and have to collect such WEEE separately. Revision User’s Manual of 1080p SIP Vandalproof Door Phone with RFID and PoE Model: HDP-1261PT, HDP-5261PT Rev:1.1(May, 2025) Part No. EM-HDP-1261PT_5261PT_v1.1...

  • Page 4: Table Of Contents

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT Table of Contents Chapter 1. Product Introduction ........................7 Package Contents ........................7 Overview ............................8 Features ............................. 11 Specifications..........................13 Chapter 2. Hardware Interface ........................16 Physical Descriptions ........................ 16 Hardware Installation .........................
  • Page 5 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT System >> Configurations ......................55 System >> Upgrade ........................56 System >> Auto Provisioning ..................... 57 System >> FDMS ........................60 System >> Tools ........................61 System >> Reboot ........................61 5.10...
  • Page 6 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.44 EGS Setting >> Logs ....................... 118 Chapter 6. Troubleshooting ........................119 Get Device System Information ....................119 Reboot Device ......................... 119 Device Factory Reset ......................119 Network Packets Capture ......................119 Get Device Log ........................

  • Page 7: Chapter 1. Product Introduction

    Chapter 1. Product Introduction 1.1 Package Contents Thank you for purchasing PLANET SIP Vandalproof Door Phone, HDP-1261PT and HDP-5261PT. Open the box of the SIP Vandalproof Door Phone and carefully unpack it. The box should contain the following items: Quick Installation Guide...

  • Page 8: Overview

    It also supports HD voice and G.722 codec that relax bandwidth limitation and provide clear communications. The HDP-5261PT enhances user access with a backlit numeric keypad, while both models support RFID for keyless entry using IC/ID cards. The door lock can be unlocked remotely via mobile device, SIP video intercom, or locally with RFID.
  • Page 9 HDP-1261PT, HDP-5261PT Easy Communication via Intercom The two-way intercom function provided by the HDP-1261PT and HDP-5261PT allow you to see the visitors and also communicate with them. The HDP-1261PT and HDP-5261PT include 3 short-in detect port and 2 short-out control port for connecting with external devices such as door lock or door sensors. When the visitors press the call button at your door, you can press the unlock button on your mobile phone or SIP Indoor Touch Screen PoE Video Intercom to open the door for your visitors.
  • Page 10 Standard Protocol Compliance The HDP-1261PT and HDP-5261PT support IETF Session Initiation Protocol 2.0 (RFC 3261) and ONVIF protocol for easy integration with general voice over IP system and video management system. The IP PBX/NVR device is able to broadly interoperate with equipment provided by VoIP/IP surveillance infrastructure providers, thus enabling them to provide their customers with better multimedia exchange services.

  • Page 11: Features

    Standard IETF SIP protocol for VoIP services  Compatible with the ONVIF for video surveillance  Compliant with IEEE 802.3at PoE interface for flexible deployment HTTPS, TR069 and auto-provisioning   PLANET DDNS and Easy DDNS  PLANET Smart Discovery Utility for deployment management...
  • Page 12 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT  Easy Installation and Management  Hands-free intercommunication  Conveniently unlock the door for visitors without having to go to it  Have peace of mind from being able to see, hear and speak to your visitors before opening the door...

  • Page 13: Specifications

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 1.4 Specifications Product HDP-1261PT HDP-5261PT Front View Physical Interface Speed-dial Button 1 DSS button 1 DSS button 12 standard phone digits keys Numerical Keypad 1 dialing key Power Requirements Power over Ethernet (IEEE 802.3at), class 3 and DC12V...
  • Page 14 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT Line-out port x 1: for induction loop antenna loop DC port x 1: DC power input Installation Wall-mount type External Power Supply DC 12V, 1A Access Control Dual SIP line, Dual SIP servers DTMF tones, RFID /IC card: ID (EM4100,125KHz) &...
  • Page 15 Static/DHCP/PPPoE Auto provisioning: FTP/TFTP/HTTP/HTTPS/DHCP OPT66/SIP PNP/TR-069 VLAN Web Management Web-based packet dump Deployment/Maintenance Configuration backup/restore Firmware Upgrade via Web Syslog PLANET DDNS and Easy DDNS PLANET Smart Discovery Utility Environments Operating Temperature -40~70°C Storage Temperature -40~70°C Operating Humidity 10~95% (non-condensing)

  • Page 16: Chapter 2. Hardware Interface

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT Chapter 2. Hardware Interface 2.1 Physical Descriptions Product Dimensions (W x D x H) 88 x 36.15 x 177.4 mm 493g Net Weight Front Panel  HDP-1261PT Camera Photosensitive...
  • Page 17 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT  Feature Description Number Interface Description The door phone has a built-in IP camera supporting a high-resolution Camera video of up to 1920 x 1080 pixels. The door phone has a built-in microphone hidden in the pinhole located on the front panel.
  • Page 18 Power interface: 12V/1A input up positive, down grounded 2 short-circuit output control interfaces for controlling electric locks, alarms, etc. 6, 7 Line out interface SD card slot The HDP-1261PT and HDP-5261PT require either IEEE 802.3at PoE or DC power from the power connector.
  • Page 19 HDP-5261PT : When the HDP-5261PT is powered on and the button indicator is rapidly flashing, press the DSS button once to enter POST mode. Then press the speed-dial button three times to reset the system to default and automatically announce the...

  • Page 20: Hardware Installation

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 2.2 Hardware Installation Wall mounting steps: Figure 2-2-1 Three Major Parts of HDP-1261PT or HDP-5261PT (Main Body, Back Shell and Wall Bracket) Step 1: Installation preparation A. Check the following contents: •...
  • Page 21 A. Detach the wall bracket downward from the device and loosen the four screws on the rear cover with a screwdriver, as shown in Figures 2-2-3-1 and 2-2-3-2. ( The installation method of the HDP-5261PT is the same as that of the HDP-1261PT. The illustration uses the HDP-1261PT as a reference.) Figure 2-2-3-1 Figure 2-2-3-2...
  • Page 22 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT Step 4: Install the wall bracket, wiring and casing A. Align the screw holes of the wall bracket with the holes in the wall and fix them to the wall with the screws,...
  • Page 23 HDP-1261PT, HDP-5261PT F. Attach the device to the wall bracket in a top-down manner, locking the screws at the Bottom, as shown in (The installation method of the HDP-5261PT is the same as that of the HDP-1261PT. The illustration uses Figure 2-2-6.

  • Page 24: Searching Door Phone

    HDP-1261PT, HDP-5261PT 2.3 Searching Door Phone There are two methods as shown below to search the HDP-1261PT. Method 1: Open the Planet SmartDiscoveryLite Utility. Press the Refresh button to search the HDP-1261PT or HDP- 5261PT and find the IP address.
  • Page 25 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT Default Setting 172.16.0.1 Default IP Address Default Web Port admin Default Login User Name Default Login Password...

  • Page 26: Starting Web Management And Door Phone Setting

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 2.4 Starting Web Management and Door Phone Setting The following web management interface is identical for both models, with the HDP-1261PT used as the example. Step 1: Log in the web setting page of door phone Enter the IP address of the door phone (e.g., https://172.16.0.1) in the address bar using the https method...
  • Page 27 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT Step 3: Setting DSS key Set the DSS key as shown below for a quick start. Click “Apply” to save this setting. Type: Memory Key. Value: The DSS Key will dial to this value.

  • Page 28: Door Unlocking Setting

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 2.5 Door Unlocking Setting RFID Card Step 1: Access control settings on web page→EGS Setting→Add Card Rule →Select "Type" ("Normal" card provides door opening function, "Add" card and "Del" card provide add and delete card function, Default "Normal"...

  • Page 29: Chapter 3. Basic Function

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT Chapter 3. Basic Function 3.1 Swipe to Open the Door Access control settings on web page → EGS Setting → Card → Add Card Rule → Select " Type"...
  • Page 30 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT Figure 3-1-1 Card Setting Page Screenshot...

  • Page 31: Local Door Opening

    Set access control on the web page → EGS Setting → Password → Add password rule → Select "Local "  Enter your name, password and number, and add them to the password list.  Only the HDP-5261PT supports local password unlocking.

  • Page 32: Remote Door Opening

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 3.3 Remote Door Opening  Set access control on the web page → EGS Setting → Password → Add password rule → Select "Remote "  Enter your name, password and number, add to the password list.

  • Page 33: Active Uri

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 3.4 Active URI The HDP-5261PT Video Door Phone supports door unlocking via Active URI. By configuring a compatible IP phone with an "Action URL", users can remotely unlock the door by pressing a designated key. Prerequisites ...
  • Page 34 4. Enter the complete Active URI command from Step 2 as the value. 5. Save the configuration. Once configured, pressing the shortcut key will send the HTTP command to the HDP-5261PT and trigger the door unlock remotely. Figure 3-4-2 Configure IP Phone Shortcut Key Notes: ...

  • Page 35: Input Trigger Unlock

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 3.5 Input Trigger Unlock The HDP-1261 and HDP-5261PT video door phones support door unlocking via input trigger. This function allows integration with a physical exit button, enabling simple and convenient local door release. Hardware Wiring Instructions Please follow the diagram to connect a push-to-exit button to the door phone: ...

  • Page 36: Scheduled Door Unlock

    HDP-1261PT, HDP-5261PT 3.6 Scheduled Door Unlock The HDP-1261 and HDP-5261PT video door phones support scheduled unlocking, allowing administrators to configure automatic door opening based on predefined time periods. This feature is ideal for managing regular access in offices, schools, or public buildings.
  • Page 37 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT Figure 3-6-1 Scheduled door unlock...

  • Page 38: Web Interface Unlock

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 3.7 Web Interface Unlock The HDP-1261 and HDP-5261PT video door phones support direct door unlocking via their web interface. This allows administrators to open the door remotely through a browser without requiring any external device.

  • Page 39: Call Status Trigger Unlock

    HDP-1261PT, HDP-5261PT 3.8 Call Status Trigger Unlock The HDP-1261 and HDP-5261PT video door phones support call status-triggered unlocking. When the device enters a specified call state, it can automatically trigger the relay output to unlock the door. This feature is useful for seamless integration of intercom and access control systems.

  • Page 40: Making Calls

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 3.9 Making Calls After setting the function key to Hot key and setting the number, press the function key to immediately call out the set number, as shown below:...

  • Page 41: Auto Answer

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 3.12 Auto Answer The user can turn off the auto-answer function (enabled by default) on the device webpage, and the ring tone will be heard after the shutdown, and the auto-answer will not time out.

  • Page 42: Call Waiting

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 3.13 Call Waiting  Enable call waiting: new calls can be accepted during a call.  Disable call waiting: new calls will be automatically rejected and a busy signal will be prompted.

  • Page 43: Chapter 4. Advanced Function

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT Chapter 4. Advanced Function 4.1 Intercom The equipment can answer intercom calls automatically. Figure 4-1-1 Intercom Setting Page Screenshot Parameters Description When the intercom system is enabled, the device will...

  • Page 44: Mcast

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 4.2 MCAST This feature allows user to make some kind of broadcast call to people who are in multicast group. User can configure a multicast DSS Key on the phone, which allows user to send a Real-time Transport Protocol (RTP) stream to the pre-configured multicast address without involving SIP signaling.
  • Page 45 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT Multicast：  Go to web page of [Function Key] >> [Function Key], select the type to multicast, set the multicast address, and select the codec.  Click Apply. ...

  • Page 46: Hotspot

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 4.3 Hotspot SIP hotspot is a simple utility. Its configuration is simple, which can realize the function of group vibration and expand thequantity of SIP account. Take one device A as the SIP hotspot and the other devices (B, C) as the SIP hotspot clients.
  • Page 47 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT Client Settings: As a SIP hotspot client, there is no need to set up a SIP account, which is automatically acquired and configured when the device is enabled. Just change the mode to "client" and the other options are set in the same way as the hotspot.

  • Page 48: Onvif

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 4.4 Onvif The door phone supports ONVIF protocol for integration with third-party NVRs, VMS, or ONVIF Device Manager tools. This function allows the door phone’s video stream to be accessed and managed like a standard IP camera.
  • Page 49 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 3. Add Device to ONVIF Device Manager Open ONVIF Device Manager on a PC within the same network. The device should appear in the list automatically. If not, click Refresh or manually enter the IP address.

  • Page 50: Nvr Integration

    HDP-1261PT, HDP-5261PT 4.5 NVR Integration The HDP-1261PT and HDP-5261PT Video Door Phone support integration with Network Video Recorders (NVRs) via RTSP streaming. This allows the NVR to record and display the video feed from the door phone as if it were an IP camera.
  • Page 51 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT To locate this path, go to HDP-5261PT Web UI > Camera Settings > Intercom settings > RTSP Information. Figure 4-5-2 Door Phone Web Interface Page Figure 4-5-3 NVR web interface for configuring the door phone...
  • Page 52 4. Confirm Connection If successfully added, the device will show Online. You can now preview and record video from the HDP-5261PT via the NVR. Notes: Only video is transmitted via RTSP; door control or intercom functions must still be operated through other integrations (e.g., SIP phone or management platform).

  • Page 53: Chapter 5. Web Configurations

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT Chapter 5. Web Configurations 5.1 Web Page Authentication Users can log into the device's web page to manage user device information and operate the device. Users must provide the correct user name and password to log in. If the password is entered incorrectly three times, it will be locked and can be entered again after 5 minutes.

  • Page 54: System >> Account

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.3 System >> Account Figure 5-3-1 Account Setting Page Screenshot On this page the user can change the password for the login page. Users with administrator rights can also add or delete users, manage users, and set permissions and...

  • Page 55: System >> Configurations

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.4 System >> Configurations On this page, users with administrator privileges can view, export, or import the phone configuration, or restore the phone to factory settings. Figure 5-4-1 System Setting Page Screenshot ...

  • Page 56: System >> Upgrade

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.5 System >> Upgrade Figure 5-5-1 Upgrade Setting Page Screenshot Upgrade the software version of the device to a new version through the webpage. After the upgrade, the device will automatically restart and update to the new version. Click select, select the version and then click...

  • Page 57: System >> Auto Provisioning

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.6 System >> Auto Provisioning Webpage: Login and go to [System] >> [Auto provision]. Figure 5-6-1 Auto Provision Setting Page Screenshot Devices support SIP PnP, DHCP options, Static provision and TR069. If all of the 4 methods are enabled, the priority from high to low is shown below: PNP >...
  • Page 58 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT Common Config enabled Enable Get Digest When the feature is enable, if the configuration of server is changed, From Server phone will download and update. DHCP Option Configure DHCP option, DHCP option supports DHCP custom option...
  • Page 59 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT will check the update every 1 hour. Provision Mode. 1. Disabled. Update Mode 2. Update after reboot. 3. Update after interval. Static Provisioning Server TR069 Enable TR069 Enable TR069 after selection ACS Server Type There are 2 options Serve type, common and CTC.

  • Page 60: System >> Fdms

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.7 System >> FDMS Figure 5-7-1 FDMS Setting Page Screenshot FDMS information Settings Community Name of equipment installation community Designations Building a Name of equipment installation building movie theater...

  • Page 61: System >> Tools

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.8 System >> Tools This page gives the user the tools to solve the problem. Figure 5-8-1 Tools Setting Page Screenshot Syslog：When enabled, set the syslog software address, and log information of the device will be recorded in the syslog software during operation.

  • Page 62: Network >> Basic

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.10 Network >> Basic This page allows users to configure network connection types and parameters. Figure 5-10-1 Network Setting Page Screenshot Field Name Explanation IPv4 Network Status The current IP address of the equipment...
  • Page 63 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT DNS Domain Enter the domain of the DNS. Attention: 1）After setting the parameters, click【Apply】to take effect. 2）If you change the IP address, the webpage will no longer respond, please enter the new IP address in web browser to access the device.

  • Page 64: Network >> Service Port

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.11 Network >> Service Port This page provides the settings of webpage login protocol, protocol port and RTP port. Figure 5-11-1 Service Port Setting Page Screenshot parameter description Web server type Restart after setting takes effect.

  • Page 65: Network >> Vpn

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.12 Network >> VPN Figure 5-12-1 Service Port Setting Page Screenshot Virtual Private Network (VPN) is a technology to allow device to create a tunneling connection to a server and becomes part of the server’s network.
  • Page 66 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT  OpenVPN To establish an OpenVPN connection, user should get the following authentication and configuration files from the OpenVPN hosting provider and name them as the following, OpenVPN Configuration file: client.ovpn...

  • Page 67: Network >> Advanced

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.13 Network >> Advanced Figure 5-13-1 Network Advanced Setting Page Screenshot Network advanced Settings are typically configured by IT administrators to improve the quality of device service. Field Name...

  • Page 68: Network >> Ddns

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.14 Network >> DDNS This page provides the settings of DDNS. The default is Disable. You can choose PLANET DDNS or Easy DDNS. Figure 5-14-1 DDNS Setting Page Screenshot...

  • Page 69: Line >> Sip

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.15 Line >> SIP Figure 5-15-1 SIP Setting Page Screenshot Parameters Description Register Settings Line Status Display the current line status at page loading. To get the up to date line status, user has to refresh the page manually.
  • Page 70 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT Display Name Enter the display name to be sent in a call request. Authentication Password Enter the authentication password of the service account Realm Enter the SIP domain if requested by the service provider Server Name Input server name.
  • Page 71 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT Enable Failback Whether to switch to the primary server when it is available. Failback Interval A Register message is used to periodically detect the time interval for the availability of the main Proxy.
  • Page 72 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT Blocking Anonymous Call Reject any incoming call without presenting caller ID User Agent Set the user agent, the default is Model with Software Version. Specific Server Type Set the line to collaborate with specific server type...

  • Page 73: Line >> Sip Hotspot

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT Unregister On Boot Whether to enable logout function. Enable MAC Header Whether to open the registration of SIP package with user agent with MAC or not. Enable Register MAC...

  • Page 74: Line >> Dial Plan

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.17 Line >> Dial Plan Figure 5-17-1 Dial Plan Setting Page Screenshot Parameters Description Press # to invoke dialing The user dials the other party's number and then adds the # number to dial out;...
  • Page 75 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT Parameters Description Dial rule There are two types of matching: Full Matching or Prefix Matching. In Full matching, the entire phone number is entered and then mapped per the Dial Peer rules.

  • Page 76: Line >> Action Plan

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.18 Line >> Action Plan Figure 5-18-1 Action Plan Setting Page Screenshot Parameter Description Number Auxiliary phone number (support video) Type Support video display on call. Direction For call mode, incoming/outgoing call displays video Line Set up outgoing lines.

  • Page 77: Line >> Basic Settings

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.19 Line >> Basic Settings A STUN (Simple Traversal of UDP through NAT) server allows a phone in a private network to know its public IP and port as well as the type of NAT being used. The equipment can then use this information to register itself to a SIP server so that it can make and receive calls while in a private network.
  • Page 78 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT Parameters Description STUN Settings Server Address Set the STUN server address Server Port Set the STUN server port, default is 3478 Binding Period Set the STUN binding period which can be used to keep the NAT pinhole opened.

  • Page 79: Intercom Setting >> Features

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.20 Intercom Setting >> Features Figure 5-20-1 Intercom Features Setting Page Screenshot Parameters Description Basic Settings Enable Call Waiting Enable this setting to allow user to take second incoming call during an established call.
  • Page 80 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT Outgoing List Enable Country Code Specify whether to enable Country Code. Country Code Country Code Area Code Area Code Allow IP Call If enabled, user can dial out with IP address.
  • Page 81 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT successfully successfully. Default: Use the default prompt tone. Voice: Include a built-in voice prompt with the default message set to "open the door successfully." The system supports customization of the door opening success prompt tone, which can be modified in the system settings under "Upgrade"...
  • Page 82 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT Successful beep for Close: No beep after successful card deletion card deletion Default: Use the default beep Voice: The default built-in voice prompt is set to "Card deletion successful."...

  • Page 83: Intercom Setting >> Media

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.21 Intercom Setting >> Media Figure 5-21-1 Media Setting Page Screenshot Parameters Description Select the enabled and disabled voice codecs Codecs Settings codec:G.711A/U,G.722,G.729,ILBC,opus,G.726,G.723.1 Media Setting Default Ring Type Set the default ring type. If the caller ID of an incoming call was not configured with specific ring type, the default ring will be used.
  • Page 84 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT CNAME host Set CNAME host RTP Settings RTP keep alive Hold the call and send the packet after 30s Alert Info Ring Settings Value Set the value to specify the ring type.

  • Page 85: Intercom Setting >> Camera Settings

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.22 Intercom Setting >> Camera Settings Customers can configure camera related parameters and adjust video coding related settings. Figure 5-22-1 Media Setting Page Screenshot Description Parameters Connection Mode Setting Local: Automatically use the local camera to transmit images.
  • Page 86 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT Auto mode: The camera automatically sets the parameters; no need for the operator to adjust. Manual exposure time: Set the exposure time by yourself; the range is Exposure Mode 0~10000.
  • Page 87 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT Enable or disable wide dynamic. Turning on wide dynamic allows the Wide dynamic camera to see the image in a very strong contrast. Wide dynamic Set image brightness by yourself; the range is 0~10.
  • Page 88 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT The larger the value, the worse the video quality; otherwise, adjustment is Frame Interval not recommended. RTSP Information Main Stream Url Display the main stream URL address. Sub Stream Url Display the sub stream URL address.

  • Page 89: Intercom Setting >> Mcast

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.23 Intercom Setting >> MCAST It is easy and convenient to use multicast function to send notice to each member of the multicast via setting the multicast key on the device and sending multicast RTP stream to pre-configured multicast address. By configuring monitoring multicast address on the device, monitor and play the RTP stream which is sent by the multicast address.

  • Page 90: Intercom Setting >> Time/Date

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.25 Intercom Setting >> Time/Date Users can configure the device's time and on this page. Figure 5-25-1 Time/Date Setting Page Screenshot Time/Date Field Name Explanation Network Time Server Settings...

  • Page 91: Intercom Setting >> Time Plan

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT To set the time manually, you need to disable the SNTP service first, and you need to fill in and submit each item of year, month, day, hour and minute in the figure above to make the manual settings successful.

  • Page 92: Intercom Setting >> Tone

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.27 Intercom Setting >> Tone The user can configure the prompt tone of the device on this page. You can select the country area or customize the area. The selected area can directly appear the default information, and the customized one can modify the key tone, callback tone and other information.

  • Page 93: Intercom Setting >> Led

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.28 Intercom Setting >> Led The user can configure the status and color of the indicator light on this page. Figure 5-28-1 LED Setting Page Screenshot Status indicator: The user can customize how the LED displays when the device is in different status.

  • Page 94: Intercom Setting >> P2P Communication Setup

    P2P (Point-to-Point) communication enables direct audio calls between two IP devices without requiring a SIP server or PBX system. This section illustrates how to configure direct IP calling between a video door phone (e.g., HDP-5261PT) and an IP phone. System Overview ...
  • Page 95 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT...
  • Page 96 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 2. Configure Door Phone for One-Touch Dialing To allow the door phone to call the IP phone via a single button:  Go to Line > SIP > Basic Settings, enable "Dial Without Registere".
  • Page 97 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 3. Configure IP Phone to Receive P2P Calls To enable the IP phone to receive direct IP calls:  Go to Line > SIP > SIP Global Settings ...

  • Page 98: Call List >> Call List

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.30 Call list >> Call List  Restricted Incoming Calls It’s same as blacklist.By adding a number to the blacklist, user will no longer receive phone call from that number and it will be rejected automatically by the device until user deletes it from the blacklist.

  • Page 99: Function Key

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.32 Function Key Figure 5-31-1 Function Key Setting Page Screenshot Parameters Description Function key settings Memory Speed Dial:The user can directly dial the set number. This feature is convenient for customers to dial frequent numbers.
  • Page 100 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT Speed dial: Make a call when pressed, and end the call when lifted. Intercom: Start the intercom when pressed, and end the intercom when lifted. Multicast: Initiate multicast when pressed, and end multicast when lifted.
  • Page 101 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT The start time of the day when the <Day/Night> mode is defined. Default Day Start Time "06:00" The end time of the day when the <Day/Night> mode is defined. Default Day End Time "18:00”...
  • Page 102 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT  Keep pressing the shortcut key set to make a call, release it and hang up.

  • Page 103: Security >> Web Filter

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.33 Security >> Web Filter Users can set up to allow only a certain network segment IP to access the device. Figure 5-32-1 Web Filter Setting Page Screenshot Add and delete the allowed IP network segments; configure the start IP address in the start IP, configure the end IP address in the end IP, and then click [Add] to add successfully.

  • Page 104: Security >> Trust Certificates

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.34 Security >> Trust Certificates You can upload and delete uploaded trust certificates. Figure 5-33-1 Trust Certificates Setting Page Screenshot...

  • Page 105: Security >> Device Certificates

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.35 Security >> Device Certificates Select the default certificate or the custom certificate as the device certificate. You can upload and delete uploaded certificates. Figure 5-34-1 Device Certificates Setting Page Screenshot...

  • Page 106: Security >> Firewall

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.36 Security >> Firewall Figure 5-35-1 Firewall Setting Page Screenshot Through this page, you can set whether to enable the input and output firewalls, and at the same time, you can set the input and output rules of the firewall.

  • Page 107: Device Log

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT network segment; It is the destination address mask. When it is configured as 255.255.255.255, it means it is a specific host. When it is set as a Dst Port Range subnet mask of 255.255.255.0 type, it means that a network...

  • Page 108: Security Settings

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.38 Security Settings Tamper protection is enabled. Upon activation, if the device is forcibly removed, an alarm message will be sent to the server, and an alarm ring will be played.
  • Page 109 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT Output Settings Enable Logs Enable or disable LOG Triggered by DTMF Ring tone Select the DTMF trigger ringtone. Triggered by URI Ringtone Select the URI trigger ringtone. Triggered By SMS Ringtone Select the SMS trigger ringtone.
  • Page 110 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT Select the input port. When the input port meets the trigger Triggered by Input condition, the output port will be triggered (The Port level time change, By < Output Duration > control).

  • Page 111: Egs Setting >> Features

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.39 EGS Setting >> Features Figure 5-38-1 ESG Feature Setting Page Screenshot You can set basic access control settings on this screen Field Name Explanation Basic Settings Relay1 Mode Monostable: There is only one fixed action status for door unlocking.
  • Page 112 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT change, the status would be kept. Initial Value is Monostable. Relay2 Duration Door unlocking time for Monostable mode only. If the time is up, the door would be locked automatically. Initial Value is 5 seconds.

  • Page 113: Egs Setting >> Relay

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.40 EGS Setting >> Relay Figure 5-39-1 Relay Setting Page Screenshot Field Name Explanation Relay Status Door Sensor1 Enable or disable door sensor 1. Door Sensor Check Delay 1 Door Sensor1 detection delay time setting, 5 seconds by default.

  • Page 114: Egs Setting >> Card

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.41 EGS Setting >> Card Figure 5-40-1 Card Setting Page Screenshot Field Name Explanation Import Card List Click the <Select> button to choose and import the remote card list file (cardlist.csv). Subsequently, click <Update>...

  • Page 115: Egs Setting >> Password

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.42 EGS Setting >> Password Figure 5-41-1 Password Rule Setting Page Screenshot Field Name Explanation Import Password List Click the <Select> button to choose and import the remote password list file (passwordlist.csv). Then, click <Update>...
  • Page 116 1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT Name User name Password Password to open the door Number When the indoor unit calls the access control or the access control calls the indoor unit to open the door, the door can be opened by entering the DTMF password.

  • Page 117: Egs Setting >> Time Profile

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.43 EGS Setting >> Time Profile Figure 5-42-1 Time Profile Setting Page Screenshot Field Name Explanation Import time list Click the <Select> button to choose and import the remote Profile list file (timeProfileList.csv).

  • Page 118: Egs Setting >> Logs

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT 5.44 EGS Setting >> Logs Figure 5-43-1 Logs Page Screenshot Field Name Explanation Relay Relay Result Display the result of a single door opening (success or failure) Name The name of the person who opened the door.

  • Page 119: Chapter 6. Troubleshooting

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT Chapter 6. Troubleshooting When the device is not working properly, users can try the following methods to restore the device to normal operation or collect relevant information to send a problem report to the technical support mailbox.

  • Page 120: Get Device Log

    1080p SIP Vandalproof Door Phone with RFID and PoE HDP-1261PT, HDP-5261PT Get Device Log Log information is helpful when encountering abnormal problems. In order to obtain the log information of the device, the user can log on to the device web page by opening the web page [device log], and clicking the "start"...

This manual is also suitable for:

Hdp-1261pt
