- Page 1 IN231000715V01_UK 842-345V70 EN_IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY. FR_IMPORTANT:A LIRE ATTENTIVEMENT ET À CONSERVER POUR CONSULTATION ULTÉRIEURE. ES_IMPORTANTE, LEA Y GUARDE PARA FUTURAS REFERENCIAS. PT_IMPORTANTE, RETER PARA REFERÊNCIA FUTURA: LEIA ATENTAMENTE. DE_WICHTIG! SORGFÄLTIG LESEN UND FÜR SPÄTER NACHSCHLAGEN AUFBEWAHREN.
- Page 3 MISE EN GARDE Export information...
-
Page 7: Expanded View
EXPANDED VIEW PART DESCRIPTION QTY Main parts Table lid Frie pit wind guard (preassembled) Table top Firebowl (preassembled) Door Burner (preassembled) Front panel Electronic igniter (preassembled) Side panel Glass clamps(×8) Later panel Long glass (×2) Right back leg Stub glass (×2) Left back leg Glass stone (×3kg) Left front leg... -
Page 8: Assembly & Installation
ASSEMBLY /INSTALLATION Attach the legs 1.Attach the door (C) and legs (G,J) to the table AA×4 top using 4 pcs M6×12mm screws(AA). Note: Do not tighten the screws first. Attach the side panels 2.Attach the panels (D,E,F) to the legs (G,H,I,J) using 12 pcs M6×25mm screws(BB). - Page 9 Checking the gas control 6.Check that the control knob (FF) for the gas supply system is turned to the "OFF” position before stating any assembly.. Securing the propane tank 7.Place propane gas tank (not included) into the Metal stand (K). Make sure the gas tank sits on the Metal stand(K) completely.
- Page 10 Assembly instructions Assembling the glass Unscrew all preassembled screws on the glass clamps Then, assemble one glass panel to the other glass panel . Repeat for the rest two glass panels. Then, assemble the two glass panel pieces together with the final glass clamps as shown below.
-
Page 15: Export Information
Export information Importer information Exporting country Product range Importer ： MH STAR UK LTD All products Britain Address ： Unit 27, Perivale Park,Horsenden lane South Perivale, UB6 7RH Importé par : MH France 2, rue Maurice Hartmann All products France 92130 Issy-les-Moulineaux France Fabriqué...
