- Page 1 IN231000716V01_UK 842-346V70 EN_IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY. FR_IMPORTANT:A LIRE ATTENTIVEMENT ET À CONSERVER POUR CONSULTATION ULTÉRIEURE. ES_IMPORTANTE, LEA Y GUARDE PARA FUTURAS REFERENCIAS. PT_IMPORTANTE, RETER PARA REFERÊNCIA FUTURA: LEIA ATENTAMENTE. DE_WICHTIG! SORGFÄLTIG LESEN UND FÜR SPÄTER NACHSCHLAGEN AUFBEWAHREN.
- Page 3 Export information...
- Page 7 EXPANDED VIEW PART DESCRIPTION QTY Item Description Table lid Table top Door Front panel Side panel Later panel Right back leg Left back leg Left front leg Right front leg Metal stand Protective cover Controlknob(preassembled) Frie pit wind guard (preassembled) Firebowl (preassembled) Burner (preassembled) Glass clamps...
- Page 8 ASSEMBLY /INSTALLATION 1.Attach the leg (G,H,I,J) to the table top (B) using 8 Pcs M6×12 screws (AA). Note: Please don't lock the screws first. AA×8 2.Attach the panels (D,E,F) to the legs (G,H,I,J) using 12 pcs M6×30mm screws(BB). Note: Please don't lock the screws first. BB×12 3.Attach the metal stand(K) between the legs (G,H,I,J) using 4 pcs M6×30mm screws(BB).
- Page 9 6.Attach the Table lid (A) the table top (B) 7.Place propane gas tank (not included) into the Metal stand (K). Make sure the gas tank sits on the metal stand completely. Turn the preassembled wing screw on the outer part of Metal stand(K) clockwise to secure the propane gas 8.Turn the knob to the position shown in the figure(1).
- Page 10 Assembly instructions Assembling the glass Unscrew all preassembled screws on the glass clamps Then, assemble one glass panel to the other glass panel . Repeat for the rest two glass panels. Then, assemble the two glass panel pieces together with the final glass clamps as shown below.
- Page 14 Export information Importer information Exporting country Product range Importer ： MH STAR UK LTD All products Britain Address ： Unit 27, Perivale Park,Horsenden lane South Perivale, UB6 7RH Importé par : MH France 2, rue Maurice Hartmann All products France 92130 Issy-les-Moulineaux France Fabriqué...
