- Page 1 PORTABLE GENERATOR Owner’s Manual GXS5800iRD DO NOT RETURN TO STORE! CALL US FIRST 855-888-3598 FOR SUPPORT Model# 2241002 REV00 Model: Serial: Date Purchased: SAVE THIS MANUAL FOR FUTURE REFERENCE P/N: 32082-07501-01...
-
Page 2: Table Of Contents
Table of Contents Introduction..........1 Connecting Electrical Loads....23 Safety............1 Low Idle Switch........23 General Safety Precautions....2 Stopping the Engine......24 Low Oil Shutdown........24 Safety and Dataplate Labels....8 Do Not Overload Generator....24 Unpacking the Generator.......9 Changing Fuels........25 Parts Included........9 Parallel & Series Operation....26 Controls and Features......10 Maintenance And Storage....27 Control Panel Features......12 Maintenance Schedule......27... -
Page 3: Introduction
If any section of this manual is not understood, contact customer Service at 855-888-3598, or www.a-ipower.com for starting, operating and servicing procedures. The owner is responsible for proper maintenance and safe use of the unit. SAVE THESE INSTRUCTIONS for future reference. -
Page 4: General Safety Precautions
Asphyxiation Electric Shock Fire Hazard Hazard Hazard Hot Surface. Explosion Moving Parts Do Not Touch the Surface. Hazard Hazard Burn Hazard Operator’s Manual Kickback GENERAL SAFETY PRECAUTIONS • Operate this product ONLY outside and at least 20 feet away from windows, doors and vents to Using a generator indoors CAN KILL YOU IN MINUTES. -
Page 5: Incorrect Usage
CORRECT USAGE Example location to reduce risk of carbon monoxide poisoning • Operate generators outside and at least 20 feet away from any structure with exhaust pointed away from doors and windows. KEEP AT LEAST 20 FEET AWAY at least 20 feet away from windows, doors and vents INCORRECT USAGE Do not operate in any of the following locations:... -
Page 6: Fuel Safety
Propane/LPG (Liquid Petroleum Gas) WARNING • Propane/LPG is highly flammable and explosive. Starter cord kickback (rapid retraction) • LPG is heavier than air and can settle in low places will pull hand and arm toward engine while dissipating. faster than you can let go which could •... - Page 7 • Store Fuel in a container approved for gasoline. DANGER • Store any containers containing gasoline or propane/LPG outdoor in a well-ventilated area, away from any combustibles or source of ignition. DANGER Gasoline, gasoline vapor and propane/LPG are highly flammable and explosive. Generator voltage could cause electrical Never use a gasoline container, gasoline tank, shock or burn will result in death or...
- Page 8 WARNING WARNING Starter and other rotating parts could entangle hands, hair, clothing, or accessories. Keep away from rotating parts, failure to do so could result in Exhaust heat/gases could ignite combustibles, death or serious injury. structures or damage fuel tank causing a fire, •...
- Page 9 devices or life support appliances. • Shut off generator if: • NEVER use this product to power medical devices -Electrical output is lost. or medical appliances. -Equipment sparks, smokes, or emits flames. • Inform your electricity provider immediately if you -Unit vibrates excessively.
-
Page 10: Safety And Dataplate Labels
SAFETY AND DATAPLATE LABELS These labels warn you of potential hazards that can cause serious injury. Read them carefully. If a label comes off or becomes hard to read, contact Technical Support Team for possible replacement. Side Back LABEL DESCRIPTION CO‐Watch Guard action automatic shutoff *See CO Watch Guard... -
Page 11: Unpacking The Generator
UNPACKING THE GENERATOR • Open carton completly. Remove and verify carton content prior to assembly. Your generator ships with following items. • Call our customer service at 855-888-3598 with the unit model and serial number for any missing item. • Record model, serial number, and date of purchase on front cover of this munual for your own record. -
Page 12: Controls And Features
CONTROLS AND FEATURES 1 - Maintenance Cover(Left) 8 - Recoil Starter 2 - Fuel Cap 9 - Panel LED Light 3 - Telescopic Handle 10 - Control Panel 4 - Maintenance Cover(Right) 11 - Propane Inlet 5 - Remote Holder 12 - Support Leg 6 - Fuel Tank 13 - Muffler/Spark Arrester... -
Page 13: Control Panel Features
CONTROL PANEL FEATURES 1. LED DATA CENTER: See LED DATA CENTER section. 9. 12V DC Battery Charger Inlet: Plug the battery float charger to this inlet and 120V wall outlet to 2. Circuit Breaker(AC): Protects the generator against charge the generator battery when the generator is electrical overloads. - Page 14 CONTROL PANEL FEATURES LED Data Center 1. LED Multi-Meter: Displays voltage,power,fuel level, 4. Overload Reset Button with Indicator Light: The frequency, and running time. indicator light is green when the inverter is running under rated load. The indicator light will turn to 2.
-
Page 15: Remote Control Programming
REMOTE CONTROL PROGRAMMING Before the generator can be started , an initial start-up Press and hold the START button of the remote procedure must be performed so the generator and the control fob, the engine push button red light will remote control recognize each other. -
Page 16: Specifications
SPECIFICATIONS GXS5800iRD Model Number 2241002 5800W-GAS / 5200W-Propane/LPG Starting Watts Running Watts 4500W-GAS / 4000W-Propane/LPG Rated AC Voltage 120V Rated DC Voltage Rated Frequency 60HZ Phase Single Grounding System (AC) Neutral Floating Engine Type Single Cylinder, 4-Stroke OHV Air Cooled... -
Page 17: Co Watch-Guard
CO WATCH-GUARD Carbon Monoxide (CO) Detection and Auto Shutoff System Your Generator is equipped with Carbon Monoxide (CO) WATCH-GUARD detect system for your protection and safety. This detecting and shutoff system monitors for the accumulation of poisonous CO gas around the generator produced by engine exhaust when the generator is running. - Page 18 The generator is shutoff automatically and the yellow light will blink for at least five minutes after shutoff. Call A-iPower Customer Service 855-888-3598 for repair. Do not use the generator until the sensor is working properly. The CO WATCH-GUARD must only be serviced by qualified technician to restore it to original settings.
-
Page 19: Add Engine Oil
Add Engine Oil NOTICE We recommend using SAE 10W-30 APISJ oil for We consider the first 5 hours of run time to be the best performance. Other high-quality detergent oils break-in period for the unit. During the break in (APISJ or higher) are acceptable. Do not use special period stay at or below 50% of the running watt additives. -
Page 20: Add Fuel: Gasoline
Add Fuel: Gasoline WHEN ADDING GASOLINE • Only fill the gasoline tank outdoors in a DANGER well-ventilated area. • DO NOT overfill gasoline tank. Allow space for fuel expansion. • If gasoline spills, wipe spilled gasoline from the unit or wait until it evaporates before starting engine. Gasoline and gasoline vapor are highly flammable •... - Page 21 • DO NOT check for leaks with a lighted match or Propane/LPG is highly flammable and explosive. flame. Fire or explosion can cause severe burns or death. • The propane cylinder valve should be fully closed • The provided propane/LPG hose with regulator, when the generator is not in use or is running with works with standard 20, 30 and 40 pound capacity gasoline.
-
Page 22: Fuel Sense
3.5% for every 1000 feet (305 m) of elevation above sea level. High altitude may cause hard starting, increased fuel consumption and spark plug fouling. To operate at high altitudes A-iPower can provide a high altitude carburetor main jet. The alternative main jet and installation instructions can be obtained by contacting Customer Support. -
Page 23: Operation
OPERATION Surge suppressors come in single- or multi-outlet Generator Location styles. They’re designed to protect against virtually WARNING all short-duration voltage fluctuations. Make sure you review each warning in order to For Cold Weather Starting prevent fire hazard. • While you must run your generator outside, you may keep the generator in a covered area to protect the generator and its battery from cold Using a generator indoors CAN KILL YOU IN MINUTES. -
Page 24: Starting The Engine (Generator)
5a. Remote start Turn and hold the REMOTE START switch for 5 seconds until the engine start. Starting the Engine (Generator) Select the Fuel Source (Gasoline) 5b. Electric start Turn and hold the ENGINE START/STOP 1. Make certain the propane cylinder knob is fully switch for 5 seconds until the engine start. -
Page 25: Connecting Electrical Loads
When starting engine, pull cord slowly until 2. Turn starting dial switch to the ON position. resistance is felt and then pull rapidly to avoid kickback. NOTE: If engine starts after 3 pulls but fails to run. Or if unit shuts down during operation, make sure unit is on a level surface and check for proper oil level in crankcase. -
Page 26: Stopping The Engine
2b. Electric start operation NOTICE Push and hold the START/STOP button for For periods of high electrical load or momentary 3 seconds until the engine stop. fluctuations, the LOW IDLE Switch should be turned OFF. NOTE: LOW IDLE minimizes fuel consumption and noise by adjusting the engine speed (RPM) to the minimum required for the current load. -
Page 27: Low Oil Shutdown
Changing Fuels WARNING DANGER Fuel and its vapors are extremely flammable and explosive which could cause burns, fire or explosion Gasoline, gasoline vapor and propane/LPG are highly resulting in death or serious injury. flammable and explosive. Fire or explosion can cause severe burns or death. NOTE: If the engine will not be used for a period of two DANGER... -
Page 28: Parallel&Series Operation
2b.Propane/LPG to Gasoline • Make certain the cylinder knob is fully closed. Parallel&Series Operation Two A-ipower model GXS5800iRD can be operated in parallel (120V) or in series (240V) to increase the total avaiable power up to 8100W from both parallel/series... -
Page 29: Maintenance And Storage
MAINTENANCE AND STORAGE MAINTENANCE SCHEDULE NOTE: Maintenance should be performed more frequently Regular Maintenance will improve the performance when generator is used in dusty areas. and extend the life of your generator. Follow When generator has exceeded the maximum figures maintenance schedule intervals whichever occurs specified in the table, maintenance should still be first according to use. -
Page 30: Change Engine Oil
Recommended Engine Oil Type CAUTION 1 0W-3 0 Avoid prolonged or repeated skin contact with used 5 W-3 0 1 0W-4 0 motor oil. 1. Loosen the bolts and remove the maintenance cover. 5 W-3 0 Full Synthetic 2. Remove the oil filler cap. °... -
Page 31: Air Filter Maintenance
Air Filter Maintenance 1. Loosen the battery access cover knobs to 1. Loosen the maintenance cover knobs to remove the cover(A). 2. Loosen the battery strap(B) by hand. remove the cover(A). 2. Remove the air cleaner knob (B). 3. Replace the battery with a new battery. Battery Specification: 12V, 4Ah sealed lead acid. -
Page 32: Valve Clearance
with appropriate authorities. Contact customer service or a qualified service center to purchase a replacement spark arrestor. A - Spark plug B - Spark plug cap C - Spark plug cover GENERATOR MAINTENANCE Make certain that the generator is kept clean and 0.7 - 0.8 mm stored properly. -
Page 33: Draining The Float Bowl
Long Term Storage (over one year) DANGER For long term storage, the gasoline tank and Explosion and Fire. Fuel and vapors are carburetor must be drained of gasoline. extremely flammable and explosive. 1 - After engine cools down, remove all gasoline Store fuel in a well ventilated area. -
Page 34: Trouble Shooting
TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Engine is running, 1. AC Circuit breaker is open. 1. Check AC load and reset circuit breaker. but no AC output is 2. Fault in generator. 2. Contact customer service or authorized service center. available. -
Page 35: Parts Diagram And Parts List
PARTS DIAGRAM AND PARTS LIST GXS5800iRD PARTS DIAGRAM(GENERATOR) Page 33... -
Page 36: Parts List
Parts List Part Number Description Qty. Part Number Description Qty. 33014-00082-02 Trim cover 60007-01362-00 Foam 31026-00357-00 Knob 20131-00086-00 Fuel cap assembly 30111-00008-00 Screw(M5*10) 34037-00329-00 Fuel filter 33013-01797-00 Left maintenance cover 20130-00748-00 Fuel tank assembly 33015-00366-00 Rubber pad 33015-00023-00 Fuel tank rubber sleeve 30136-00202-00 Flat washer 34023-00004-00... - Page 37 Part Number Description Qty. Part Number Description Qty. 33013-01700-00 Exhaust louver 70003-01783-00 Spark plug wrench 33015-00305-00 Exhaust rubber sleeve 70003-00920-00 Screw driver 30150-00026-00 Spring washer 20033-00125-00 Propane/LPG hose with regulator 20136-00795-00 Inverter assembly 60005-00237-00 Oil bottle 20014-01067-00 Inverter bracket 31034-00041-00 30 AMP RV Adapter 30101-00066-00 Screw(M5*12)
- Page 38 PARTS DIAGRAM (ENGINE) 50 51 58 59 9 10 68 69 71 72 Page 36...
- Page 39 Parts List Part Number Description Qty. Part Number Description Qty. 30125-00023-00 Nut(M8) 30117-00011-00 Screw(ST4.8*16) 30101-00887-00 Screw(M8*16） 20021-00077-00 Valve cover 20202-01221-00 Muffler assembly 30101-00042-00 Screw(M6*20) 30101-00461-00 Screw(M8*32） 34021-00419-00 Outer cover 33129-00106-00 Closure plate 30101-00070-00 Screw(M6*12) 33247-00032-00 Oil level sensor 34023-00506-00 Intake tube 30101-00400-00 Screw(M6*14）...
- Page 40 Part Number Description Qty. 30101-00830-00 Screw(M6*18) 20010-00408-03 Blower Housing 30117-00057-00 Screw(ST4.8*16) 30101-00042-00 Screw(M6*20) 30101-00342-00 Screw(M6*16) 33593-00228-00 Wire press plate 30101-00070-00 Screw(M6*12) 34021-00314-00 Blower housing(Intake side) 30111-00088-00 Screw(M5*14) 30101-00070-00 Screw(M6*12) 20028-00230-00 Ignition module 30111-00064-03 Screw(M5*20) 30101-00414-00 Screw(M5*35) 20149-00206-03 Starting motor component 34006-00001-00 Dowel pin(Φ8*12) 60008-00020-00...
-
Page 41: Circuit Diagram
Circuit Diagram Page 39... -
Page 42: Warranty
Warranty Term related service due to obstructions and other build ups resulting from improper maintenance. A-iPower will provide warranty for any of its products Additional exclusions - this warranty does not cover purchased through any authorized AiPower dealer in wearable parts such as filers, spark plugs, o-rings, North America to the original purchaser and will be batteries etc. - Page 43 Warranty limits and Implications and Consequential Damages A-iPower is not obligated to cover any loss of time, use of product, freight cost, or any other incidental or consequential claim from the use of this product. This warranty is in Lieu of all other warranties, express or implied.
- Page 44 Fontana, CA 92337 USA Phone: 855-888-3598 support@a-ipower.com www.a-ipower.com...
- Page 45 A-iPOWER WARRANTY REGISTRATION FORM Register your product by emailing this form to support@a-ipower.com or register on-line at: www.a-ipower.com. Registering your product is important , it provides the following protections: 1. You have record of product purchased 2. Customer Service can Better serve you for Warranty related issues...
- Page 46 Fontana, CA 92337 USA Phone: 855-888-3598 support@a-ipower.com www.a-ipower.com...
