SPEAKER SYSTEM
F-03BT-WP-UE
F-03WT-WP-UE
Thank you for purchasing TOA's Speaker System.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.
F-03BT-WP-UE, F-03WT-WP-UE
F-05BT-WP-UE, F-05WT-WP-UE
F-08BT-WP-UE, F-08WT-WP-UE
F-05BT-WP-UE
F-05WT-WP-UE
INSTRUCTION MANUAL
F-08BT-WP-UE
F-08WT-WP-UE
Advertisement
Related Manuals for Toa F-03BT-WP-UE
Summary of Contents for Toa F-03BT-WP-UE
- Page 1 INSTRUCTION MANUAL SPEAKER SYSTEM F-03BT-WP-UE, F-03WT-WP-UE F-05BT-WP-UE, F-05WT-WP-UE F-08BT-WP-UE, F-08WT-WP-UE F-03BT-WP-UE F-03WT-WP-UE F-05BT-WP-UE F-05WT-WP-UE F-08BT-WP-UE F-08WT-WP-UE Thank you for purchasing TOA’s Speaker System. Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.
-
Page 2: Table Of Contents
2. GENERAL DESCRIPTION AND FEATURES ........4 3. HANDLING PRECAUTIONS ..............4 4. DIMENSIONAL DIAGRAM ................5 4.1. F-03BT-WP-UE, F-03WT-WP-UE ................ 5 4.2. F-05BT-WP-UE, F-05WT-WP-UE ................ 5 4.3. F-08BT-WP-UE, F-08WT-WP-UE ................ 6 5. SPEAKER CABLE CONNECTIONS ............. 6 6. IMPEDANCE CHANGE ................. -
Page 3: Safety Precautions
1. SAFETY PRECAUTIONS • Before installation or use, be sure to carefully read all the instructions in this section for correct and safe operation. • Be sure to follow all the precautionary instructions in this section, which contain important warnings and/or cautions regarding safety. -
Page 4: General Description And Features
• Compact speakers with high quality sound that can suit a wide range of scenes such as background music and announcement use. • These speakers are IP65-rated, providing both dustproof and waterproof performance. • The table below shows the differences among models of the F-03BT-WP-UE/03WT-WP-UE, the F-05BT-WP- UE/05WT-WP-UE, and the F-08BT-WP-UE/08WT-WP-UE. Model... -
Page 5: Dimensional Diagram
4. DIMENSIONAL DIAGRAM 4.1. F-03BT-WP-UE, F-03WT-WP-UE Unit: mm [Front] [Rear] [Side] 130 (5.12") 132 (5.2") [Side (with U bracket)] 202 (7.95") U bracket 4.2. F-05BT-WP-UE, F-05WT-WP-UE Unit: mm [Front] [Rear] [Side] 162 (6.38") 164 (6.46") [Side (with U bracket)] 239 (9.41") -
Page 6: F-08Bt-Wp-Ue, F-08Wt-Wp-Ue
4.3. F-08BT-WP-UE, F-08WT-WP-UE Unit: mm [Front] [Side] [Rear] 251 (9.88") 216 (8.5") 40 (1.57") [Side (with U bracket)] 313 (12.32") U bracket 5. SPEAKER CABLE CONNECTIONS Applicable cable: 0.33 – 3.3 mm (AWG 22 – 12) [Input terminal polarity] [Stripped conductor of cable] 10 mm (0.39") Input terminal... -
Page 7: Impedance Change
6. IMPEDANCE CHANGE To change the impedance, use a standard screwdriver to rotate the rotary switch on the speaker's rear to select the desired input power. [F-03BT-WP-UE or F-03WT-WP-UE] [F-05BT-WP-UE or F-05WT-WP-UE] Factory-preset : 670 Ω Factory-preset : 330 Ω... - Page 8 The number of the mounting holes in the U bracket varies depending on the model. Be sure to use 2 or more mounting holes to secure the U bracket to the installation location. Use M10 nut for installation. F-03BT-WP-UE, F-03WT-WP-UE F-05BT-WP-UE, F-05WT-WP-UE F-08BT-WP-UE, F-08WT-WP-UE Mounting hole 4-ø11 (0.43")
-
Page 9: Range Of Speaker Installation Angle
7.2. Range of Speaker Installation Angle Install the speakers within the shaded range shown in the table below. 7.2.1. F-03BT-WP-UE, F-03WT-WP-UE Installation examples Horizontal angle adjustment range Wall mounting • Vertical installation 70° left and right from the center of the speaker... - Page 10 7.2.2. F-05BT-WP-UE, F-05WT-WP-UE Installation examples Horizontal angle adjustment range Wall mounting • Vertical installation 70° left and right from the center of the speaker example (Top view) 0° • Horizontal installation 0º horizontal to 70º downward (Side view) 0° Ceiling mounting •...
- Page 11 7.2.3. F-08BT-WP-UE, F-08WT-WP-UE Installation examples Horizontal angle adjustment range Wall mounting • Vertical installation 70° left and right from the center of the speaker example (Top view) 0° • Horizontal installation 0º horizontal to 70º downward (Side view) Wall Wall 0°...
-
Page 12: Mounting
• Keep the safety wire at the minimum length without slack. Note The safety wire is not supplied. Prepare it separately. F-03BT-WP-UE, F-03WT-WP-UE F-05BT-WP-UE, F-05WT-WP-UE F-08BT-WP-UE, F-08WT-WP-UE Safety wire Safety wire attachment hole... - Page 13 Step 3. Secure the speaker bracket to the rear surface of the speaker using the supplied screws. Recommended tightening torque: 2 N·m F-03BT-WP-UE, F-03WT-WP-UE, F-08BT-WP-UE, F-08WT-WP-UE F-05BT-WP-UE, F-05WT-WP-UE Machine screw M5 x 20 (with plain washer and spring Machine screw M5 x 20...
- Page 14 Step 8. Adjust the speaker angle by moving the speaker along the angle adjustment slots in the U bracket, then tighten the speaker using the supplied screws. (2 places) [Recommended tightening torque] F-03BT-WP-UE, F-03WT-WP-UE, F-05BT-WP-UE, F-05WT-WP-UE: 5 N·m F-08BT-WP-UE, F-08WT-WP-UE: 10 N·m...
- Page 15 The brand mark is attached to the speaker’s front grille with the double-sided Front grille adhesive tape. You can change the orientation of the brand mark, if needed, when the Brand mark speaker is installed horizontally to a wall or a ceiling. In this case, peel off the brand mark slowly and carefully, then you can reattach it after changing its orientation.
-
Page 16: Frequency Response (1 W, 4 M)
8. FREQUENCY RESPONSE (1 W, 4 m) 8.1. F-03BT-WP-UE, F-03WT-WP-UE [dB] 10 k 20 k [Hz] Frequency - SPL 8.2. F-05BT-WP-UE, F-05WT-WP-UE [dB] 10 k 20 k [Hz] Frequency - SPL... -
Page 17: F-08Bt-Wp-Ue, F-08Wt-Wp-Ue
8.3. F-08BT-WP-UE, F-08WT-WP-UE [dB] 10 k 20 k [Hz] Frequency - SPL... -
Page 18: Specifications
9. SPECIFICATIONS 9.1. F-03BT-WP-UE, F-03WT-WP-UE Model No. F-03BT-WP-UE F-03WT-WP-UE Standards EN 54-24: 2008 Loudspeaker for voice alarm systems for fire detection and alarm systems for buildings Cert. No.: 1438-CPR-1053 NB No.:1438 DoP: 24-105 Enclosure Sealed type Power Handling Capacity* Rated noise power: 30 W (8 Ω) Continuous program: 60 W (8 Ω) -
Page 19: F-05Bt-Wp-Ue, F-05Wt-Wp-Ue
9.2. F-05BT-WP-UE, F-05WT-WP-UE Model No. F-05BT-WP-UE F-05WT-WP-UE Standards EN 54-24: 2008 Loudspeaker for voice alarm systems for fire detection and alarm systems for buildings Cert. No.: 1438-CPR-1053 NB No.:1438 DoP: 24-105 Enclosure Sealed type Power Handling Capacity* Rated noise power: 60 W (8 Ω) Continuous program: 120 W (8 Ω) Rated Input 30 W (100 V line, 70 V line) -
Page 20: F-08Bt-Wp-Ue, F-08Wt-Wp-Ue
Speaker bracket ................2 Machine screw M8 x 12 (with plain washer and spring washer) ... 4 Machine screw M5 x 20 (with plain washer and spring washer) ... 4 Terminal cover ................1 Tapping screw 4 x 12 ..............4 https://www.toa-global.com/en 133-01-00385-00...
