Toa F-122CU Specifications

F S
E R I E S
C S
E I L I N G P E A K E R S
F - 1 2 2 C U
F - 1 5 2 2 S C
F - 2 3 2 2 C
F - 2 3 5 2 C
F - 2 3 5 2 S C
F - 2 8 5 2 C
TOA F SERIES CEILING SPEAKERS are ideal for music
and paging applications such as audio/visual, business
music or retail sound systems. The new lineup consists
of six models with features and price points to suit
premium-to-economy applications; all built with the
same high quality and reliability the industry has
come to expect from TOA products. Key benefits
include smooth off-axis coverage, versatile range of
models, ease of installation, and competitive pricing.
For premium wide-dispersion performance, the new
F-122CU is a 5" full-range processed ceiling speaker,
UL1480/2043-Listed for Fire Protective, General
Purpose Signaling and Air-Handling Spaces. Other
new full-range models include the F-2322C with 5"
full-range driver and the ultra-compact F-1522SC with 4"
full-range driver.
Three new two-way co-axial models include the
F-2852C with 6.5" cone driver, the F-2352C with 5"
cone driver and the economy F-2352SC with 5" cone
driver. Each model has a special diffusor with built-in
dome tweeter for superior co-axial performance.
The F-122CU, F-2322C, F-2352C and F-2852C all
include integral metal back-cans with safety cable,
quick-mount hardware and removable Phoenix-style
connectors with loop-through points for adjacent
speakers. Built-in overload protection circuitry
ensures outstanding reliability.
All six new models include built-in multi-tap transformers
with 8/16 ohm direct modes, front baffle power tap
selection and double-locking, paintable grilles.
Accessories include HY-TB1 tile bridge rails, HY-TR1
trim ring and HY-BC1 surface back-can.
The F Series ceiling speakers are individually packaged
and backed with a five year warranty.
Related Products
BG-M Series Mixer/Amplifiers
BS-1030 Wall/Ceiling-Mount Box Speaker
FB-100 Corner-Mount Subwoofer
HB-1 In-Wall Subwoofer
H
I G H L I G H T S
Superior Sound Quality
Wide-Dispersion, Smooth Off-Axis Coverage
Fast And Easy Installation
UL-Listed And Compliant Models
Built-In 25/70.7 V Multi-Tap Transformer
Low Impedance Mode (8/16 Ohms)
Convenient Power Tap Selector On Front Baffle
Integral Metal Back-Can And Safety Cable
Low-Profile, Paintable Grille
Overload Protection Circuitry
Mounting Hardware Included
Competitive Pricing
Individually Packaged
Five Year Warranty
F-122CU
FULL-RANGE PROCESSED CEILING SPEAKER (5")
UL1480/2043-Listed
5" full-range driver
Wide-dispersion: 180º (1-4k Hz avg.)
Optimized equalization with model E-03R module or AC-120 processor
Power Handling: 30 W (xfmr) / 120 W (8 ohms)
F-2352C
CO-AXIAL CEILING SPEAKER (5")
Co-axial: 5" cone driver and dome tweeter
Wide-dispersion: 170º conical (1-4k Hz avg.)
Power Handling: 30 W (xfmr) / 120 W (8 ohms)
F-2852C
CO-AXIAL CEILING SPEAKER (6.5")
Extended bass response
Co-axial: 6.5" cone driver and dome tweeter
Wide-dispersion: 120º conical (1-4k Hz avg.)
Power Handling: 60 W (xfmr) / 180 W (8 ohms)
F-2322C
FULL-RANGE CEILING SPEAKER (5")
5" full-range driver
Wide-dispersion: 170º conical (1-4k Hz avg.)
Power Handling: 30 W (xfmr) / 120 W (8 ohms)
F-2352SC
LOW POWER CO-AXIAL CEILING SPEAKER (5")
Co-axial: 5" cone driver and dome tweeter
Wide-dispersion: 155º conical (1-4k Hz avg.)
Power Handling: 6 W (xfmr) / 18 W (8 ohms)
F-1522SC
COMPACT FULL-RANGE CEILING SPEAKER (4")
4" full-range driver
Wide-dispersion: 160º conical (1-4k Hz avg.)
Power Handling: 6 W (xfmr) / 18 W (8 ohms)
