Installation and maintenance instructions for
PLATIN Rainwater Underground Tank
1500 L
Order No. 390000
3000 L
Order No. 390001
5000 L
Order No. 390002
7500 L
Order No. 390005
The points described in these
instructions must be observed
under all circumstances. All
warranty rights are invalidated
in the event of non-observance.
Separate
instructions are enclosed in the
transportation packaging for all
additional
articles
from GRAF.
Missing instructions must be
requested from us immediately.
The tank must be checked for
any damage prior to insertion
into
the
trench
circumstances.
Missing
instructions
downloaded on www.graf.info or
can be requested from GRAF.
mail@graf.info
www.graf.info
Table of contents
1.
GENERAL NOTES
1.1
Security
1.2
Identification obligation
installation
2.
INSTALLATION CONDITIONS
3.
TECHNICAL DATA
purchased
4.
TANK STRUCTURE
5.
INSTALLATION AND ASSEMBLY
5.1
Construction site
5.2
Trench
5.3
Insertion and filling
5.4
Routing connections
6.
ASSEMBLING THE AND TELESCOPIC DOME SHAFT
6.1
Assembling the telescopic dome shaft
6.2
Telescopic dome shaft on which persons may walk
under
all
6.3
Telescopic dome shaft over which passenger cars
may drive
6.4
BEGU telescopic dome shaft
7.
ASSEMBLY OF THE ADAPTER
can
be
7.1
Assembling the adapter
8.
INSPECTION AND SERVICING
11 / 39
12
12
12
13
14
15
15
16
16
17
17
18
18
18
18
18
19
19
19
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Graf Platin 1350
Summary of Contents for Graf Platin 1350
- Page 1 Telescopic dome shaft over which passenger cars circumstances. may drive BEGU telescopic dome shaft ASSEMBLY OF THE ADAPTER Missing instructions Assembling the adapter downloaded on www.graf.info or can be requested from GRAF. INSPECTION AND SERVICING 11 / 39...
- Page 2 GRAF must be used. GRAF offers an extensive range of accessories, all of which are designed to match each other and which can be extended to form complete systems. The use of other accessories may lead to impediments to the system's functional capability, therefore invalidating liability for resulting damage.
- Page 3 Installation conditions Mini telescopic Maxi telescopic dome shaft + Teleskop-Domschacht Teleskop-Domschacht dome shaft Telescopic with cast iron lid Mini Maxi / Guss Coverage heights with telescopic dome shaft in 455-655 455-755 green areas. Maximum coverage heights with intermediate section and telescopic dome shaft.
- Page 4 Technical data 340 (Mini) 440 (Maxi) Hges Hges Htot Htot Tank 1500 L 3000 L 5000 L 7500 L Art. No. 390000 390001 390002 390005 Weight 82 kg 180 kg 250 kg 360 kg 2100 mm 2450 mm...
- Page 5 Tank structure Water connector box internal (optional) PE cover for telescopic dome shaft Telescopic dome shaft (can be inclined by 5°) Profile seal Tank dome Installation and assembly Subsoil Covering layer ...
- Page 6 Installation and assembly Construction site Under all circumstances, the following points must be clarified prior to installation: The structural suitability of the ground according to DIN 18196 Maximum groundwater levels which occur and drainage capability of the subsoil Types of load which occur, e.g.
- Page 7 The apertures must be drilled to the corresponding size using only the GRAF special crown bit. It must be ensured that the distance between the tanks is at least 500 mm. The pipes must project at least 200 mm into the tanks.
- Page 8 Assembling the and telescopic dome shaft Assembling the telescopic dome shaft „A“ The telescopic dome shaft enables infinite adaptation of the tank to given site surfaces with earth coverage of between 455 mm and 655 mm (Mini telescopic dome shaft) or 455 mm and 755 mm (Maxi telescopic dome shaft).
- Page 9 GRAF SARL – 45, Route d´Ernolsheim – F-67120 Dachstein Gare – Tel.: 0033/388497310 – Fax: 0033/388493280 GRAF Iberica – C/Marquès Caldes de Montbui, 114 baixos – ES-17003 Girona – Tel.: +34/972 913 767 – Fax: +34/972 913 766 GRAF Ltd – Maidstone, Kent – UK-ME16 8Ry – Phone: +44 (0) 16 22 68 65 50...
- Page 11 22 / 39...
