Owners Manual
4410 Bottle Filler Freeze Resistant Tubular Fountain
with 98836C Single Valve Control Assembly
INSTALLER
4410BFFR Fountains are among the easiest to install Fountains on the market today. To assure
you install these models easily and correctly, PLEASE READ THESE SIMPLE INSTRUCTIONS
BEFORE STARTING THE INSTALLATION. CHECK YOUR INSTALLATION FOR COMPLIANCE
WITH PLUMBING, ELECTRICAL, AND OTHER APPLICABLE CODES. After installation, leave these
instructions with the Fountain for future reference.
PAGE 1
98878C (Rev. C - 01/17)
