Operator's manual for Attachment
Operator's
Operator's
Operator's
Product number:
Please read this manual carefully before using the equipment, and follow all
instructions.
Keep this manual for later reference.
manual for Attachment
manual for Attachment
manual for Attachment
Log splitter
300-700-series loaders:
200-series loaders:
Log splitter 2011 1
A2951
A21278
A21117
Advertisement
Table of Contents
Related Manuals for AVANT A2951
Summary of Contents for AVANT A2951
- Page 1 Operator’s manual for Attachment manual for Attachment manual for Attachment manual for Attachment Log splitter Product number: 300-700-series loaders: A2951 A21278 200-series loaders: A21117 Please read this manual carefully before using the equipment, and follow all instructions. Keep this manual for later reference.
-
Page 2: Table Of Contents
Log splitter 2011 1 CONTENTS 1. Foreword..........................3 2. Designed purpose of use ......................3 3. Safety instructions for the log splitter..................3 4. Technical specifications ......................4 5. Assembly of the log splitter ......................5 ..................5 5.1.Mounting the log splitter to the loader ..............6 5.2.Connecting and disconnecting the hydraulic fittings 6. -
Page 3: Foreword
3(12) 1. Foreword Avant Tecno Oy would like to thank you for your purchase of this AVANT attachment. It has been designed and manufactured on the basis of years of product development and experience. By familiarising yourself with this manual and following the instructions, you ascertain your safety and ensure the reliable operation and long service life of the equipment. -
Page 4: Technical Specifications
Log diameter, max: 400 mm Weight: 150 kg 250 kg Type of splitting wedge: Splits to 2 or 4 sections Feeding speed: Appr. 40 logs/min Maximum input of hydraulic 60 l/min, energy: 22,5 MPa (225 bar) Suitable AVANT loader: 200-sarja 300-700 300-700... -
Page 5: Assembly Of The Log Splitter
The attachment is mounted to the AVANT loader boom quick attach plate and the counterpart on the attachment. The locking is semi-automatic, but because the attachment plate of the log splitter is at relatively... -
Page 6: Connecting And Disconnecting The Hydraulic Fittings
6(12) Step 1: • Lift the quick attach plate locking pin / locking pins up and turn them backwards into the slot so that they are locked in the upper position. • Ensure that the hydraulic hoses are not in the way during installation. -
Page 7: Operation
7(12) In a 200-series equipment, the hose can be connected by pushing the fitting in the counterpart. When connecting and disconnecting the 200-series hydraulics quick couplings, you should pay attention to their locking. The locking prevents the female and male fittings from being disconnected from each other by accident when the attachment moves. -
Page 8: Adjusting The Stroke Length
8(12) Shut down the loader engine and release the residual pressure to prevent the splitting cylinder from moving during adjustments. If there are other persons at the work area also remove the keys from the ignition or disconnect a hydraulic fitting. 6.1.1. - Page 9 9(12) • Check that the log splitter is intact and that all obstacles have been removed from the working area before starting the work. • Check the correct operation of the controls by completing a few empty cycles with the splitter. The splitter should perform one splitting cycle only if the protective grille is closed, and after the cycle the cylinder should automatically return to its initial position and stop.
-
Page 10: Maintenance And Servicing
8. Warranty terms Avant Tecno Oy grants a warranty of one year (12 months) from the date of purchase for the attachment it manufactures. The warranty covers repair costs as follows: •... - Page 11 SFS-EN ISO 12100-1, SFS-EN ISO 12100-2, SFS-EN 982, SFS-EN 609-1 Kuvaus: Avant-kuormainten kanssa käytettävä hydraulinen puunhalkaisija Beskrivning: Hydraulisk vedklyv; arbetsredskap för Avant lastare Description: Hydraulic log splitter; attachment for Avant loaders Beschreibung: Hydraulische Holzspalter; Anbaugerät für Avant Radlader Mallit / Modeller / Models / Modellen: Avant 200 series...
