Manitowoc NEO 310 Manual

Restoring Ice Machine
to Service
Manitowoc recommends a Factory Authorized Service company or Distributor Authorized Service Dealer perform
thorough preventative maintenance prior to restoring service of the Manitowoc ice machine, storage bin or
dispenser. Section 4 (Maintenance) of the Installation, Operation and Maintenance manual should be followed to
ensure proper cleaning and sanitizing steps are completed.
Water system components including the water inlet valve, water pump and dump valve may require removal for
inspection or replacement depending on the potable water quality and the length of time the components had no
use. Water cooled ice machines may require the condenser be cleaned and the refrigeration water regulating valve
evaluated for proper performance. Air-cooled condensers should be cleaned. This is also a good time to replace
water filtration, replenish AuCS chemical and replace the Luminice bulb if these Manitowoc accessories are used.
RESTORING TO SERVICE PROCEDURES
1. Make sure ice machine
is off.
2. Empty ice bin, if not
already empty.
Use an ice scoop to remove
all ice from the bin.
3. Start a cleaning cycle
Press the Clean button for 3
seconds.
2110 SOUTH 26TH STREET, MANITOWOC, WI 54220
Subject: NEO Model Ice Machines
AIR-COOLED & WATER-COOLED ICE MACHINES
MANITOWOC ICE
WWW.MANITOWOCICE.COM
4. Add Manitowoc cleaner
Water will flow down the
drain and then refill. Wait
until the water trough refills,
then add 150 ml (5 oz) of
Manitowoc ice machine
cleaner part number 9405463
to the water trough
5. Turn off the ice
machine
Wait until the clean cycle is
complete (approximately 22
minutes) then press the On/
Off button.
6. Disconnect main
power at the service
disconnect or breaker
and remove power cord
from wall outlet
WARNING
n
Do not begin cleaning the
ice machine until all sources
of line voltage power have
been disconnected.
Document Number: MII_SB_0036 04/20
800 545 5720
1 of 8
