ASROCK 6U8X-EGS2 SYN Quick Installation Manual

*15G065350000AR*
P/N: 15G065350000AR
Quick Installation Guide
6U8X-EGS2 SYN
The User's Manual is available for download from the ASRock Rack's official website at http://
www.asrockrack.com.
Take note of the following precautions before installing the components or change any settings.
1. Unplug the power cord from the wall socket before touching any components.
2. To avoid damaging the components due to static electricity, NEVER place the components
directly on the carpet or the like. Also remember to use a grounded wrist strap or touch a safety
grounded object before installation.
3. Hold components by the edges and do not touch the ICs.
4. Whenever uninstalling any components, place them on a grounded anti-static pad or in the bag
that comes with the components.
5. When placing screws into the screw holes to secure any components to the barebone, please
do not over-tighten the screws! Doing so may damage both components and barebone.
2 Internal Features
2
1
3 4
No. Description
Upper: 4+4 CRPS
1
Lower: 8 HHHL PCIe5.0 x16
Upper:
2 FHHL PCIe5.0 x16
2 Rear I/O panel
Lower:
6 PWM 80x80mm rear fans
3 System fan (FAN11)
4 System fan (FAN12)
5 System fan (FAN13)
5 System Front Panel
1
1
4
4
No. Description
1 8 Hot-swap 2.5" NVMe (PCIe5.0 x4) drive bays
2 2 Hot-swap 2.5" NVMe (PCIe4.0 x4)/SATA drive bays
3 2 Hot-swap 2.5" SATA drive bays
4 Front I/O panel
(depends on the specification of the server board)
5 10 PWM 80x80mm front fans
2
1
7
5 6
8
9
No. Description
6 System fan (FAN14)
7 System fan (FAN15)
8 Server board
Upper:
8 Hot-swap 2.5" NVMe (PCIe5.0 x4) drive bays
2 Hot-swap 2.5" NVMe (PCIe4.0 x4)/SATA drive bays
9
2 Hot-swap 2.5" SATA drive bays
Front I/O panel
(depends on the specification of the server board)
Lower: 10 PWM 80x80mm front fans
2 3
2 3
5
5
www.asrockrack.com
1 Replace Server Board
Carefully unplug all cables and release
1
screws on the server board to remove
them from the barebone.
Align the replaced server board with the
2
mounting holes .
A f f i x t he screws clock w ise into t he
3
mounting holes in all of the corners of
the server board.
Do not over-tighten the screws.
Front I/O Panel
3
1 2 3 4
1 2 3 4
UID
No. Description
1 Type-A (USB3.2 Gen1) ports (USB3_1_2)
2 Type-A (USB3.2 Gen1) ports (USB3_3_4)
3 VGA port
4 UID button w/ LED
5 Power button w/ LED
6 Reset button
4 Rear I/O Panel
1
5 6
No. Description
1 2 RJ45 (1GbE) LAN ports (LAN1, LAN2)
2 VGA port
3 IPMI LAN port
4 2 Type-A (USB3.2 Gen1) ports
5 UID button w/ LED
6 System Rear Panel
1 2
1 2
3
3
4
4
No. Description
1 Rear I/O panel
2 2 FHHL PCIe5.0 x16
3 4+4 CRPS
6U8X-EGS2 SYN H100 6U8X-EGS2 SYN H200
5 6 7 8 9 10
5 6 7 8 9 10
NMI
No. Description
7 NMI button
Upper: Hard drive activity LED
8
Lower: System fault LED
9 IPMI LAN port
10 RJ45 (1GbE) LAN port (LAN1)
11 RJ45 (1GbE) LAN port (LAN2)
2
7 8 9 10
No. Description
6 Power button w/ LED
7 Reset button
8 NMI button
9 Hard drive activity LED
10 System fault LED
2
2
3
3
4
4
5
5
No. Description
4 8 HHHL PCIe5.0 x16
5 6 PWM 80x80mm rear fans
11
11
3
4
